Setup and Placement

Your Juno Tower will perform best when you place it:
• Even with either the front or rear edge of the main listening area (i.e. where students sit)
and
• With the speaker facing the center of the listening area (see Top View below).
Choose the location that allows connection to the teaching computer (4m USB cable provided)
and other audio sources (e.g. DVD player)
You can either mount the Juno Tower on a wall using a standard 100mm VESA mount
(recommended) or simply place it on a table using the stand provided. In any case, the bottom
edge of the Tower should be at least 4.5 feet (1.3m) from the floor.
If wall mounting, angle the tower down to point at the center of the listening area.
NOTE: For wall mounting instructions, please see the Juno Installation Guide available at
gofrontrow.com/guides-resources
Top View
Listening Area
Side View
Listening Area
4.5 ft
(1.3m)
minimum
4
