940Tm Pendant Microphone; Chapter 3 Features - FrontRow symbio User Manual

3

940TM Pendant Microphone

Features
1
5 6
7
6
front
2
3
4
bottom
8 9
back
6
11
1. Neck strap
2. Infrared emitter diodes
(
Do not block)
3. Indicator light
4. Mute button
(
Push to mute)
5. Channel selector
(Select Channel A or Channel B. Do not
have two microphones on the same
channel in the same room)
6. Dual microphone ports
(
Do not block)
7. Aux-in audio jack
(
Use aux-in audio adaptor cord to send
audio from a secondary audio source
such as an MP3 player, portable radio/
CD/tape player to the receiver)
8. External microphone jack (optional)
(
to connect a boom microphone)
6 10
9. Charge jack
10. On/off switch
11. Battery compartment
Accepts 1 AA (LR6) battery
NiMH rechargeable recommended
("silver sleeve", auto-sensing)
7
