Using Multiple Microphones

Your Juno system is designed to receive up to 5 microphone signals at once*. Any combination
of Pass-Around and Pendant Microphones is possible. For example, use two Pendant Microphones
(one for a teacher and one for a teacher's aide) and three Pass-Around Microphones for students,
or one Pendant Microphone for a teacher and four Pass-Around Microphones for students.
Microphones must be on different channels or interference will occur. You can quickly
program them to properly operate on different channels.
NOTE: If you are using the ITM-02 Pendant Microphone with just one ISM-02 Pass-Around
Microphone, you probably don't need to program or set anything. The ITM-02 Pendant
Microphone is factory set to transmit on Juno channel A and the ISM-02 Pass-Around Microphone
is factory set to transmit on Juno channel B.
If you have the Channel Expansion Module installed in your Juno Tower and are using multiple
microphones, you must assign channels using the Microphone Settings software and set mic
switch positions so that each ITM-02 Pendant and ISM-02 Pass-Around Microphone transmits on
a unique channel. Use the Recommended Channel Setting guide below to program channels and
choose switch positions for your microphones.
Programming and switching the microphone channels
1. Use a USB cable to connect the
microphone to a computer with the
FrontRow Microphone Settings software
application** installed.
2. Open the Microphone Settings software
application.
3. Click the Microphone Settings button.
4. Click the Channel Assignments button.
5. Using the dropdown choices on the right,
assign the desired channels to the switch
positions (see guide below) and click OK.
Microphone 1
Switch Switch
Position Position
1 2
A B
*The Juno Tower comes standard with 2 channels. Add 3 additional channels with the optional Channel
Expansion Module.
** The Microphone Settings application is available at gofrontrow.com/guides-resources.
Recommended Channel Setting
Microphone 2
Switch Switch
Position Position
1 2
A B
Microphone 3
Switch Switch
Position Position
1 2
C D
46
Microphone 4
Switch Switch
Position Position
1 2
C D
Microphone 5
Switch Switch
Position Position
1 2
E C
