Technical Data - Wilo -Zeox FIRST Installation And Operating Instructions Manual

English
Zeox FIRST H
S: Flange on suction side
D: Flange on discharge side
H: shaft end position
Standard: H2 S3 D0, other configurations on request.
5.2

Technical data

Pression maximale
Maximum operating pressure:
(Including suction pressure)
Maximum suction pressure:
Temperature range
Liquid temperature:
Max ambient temperature:
Max liquid density:
Max solids content:
Electrical data
Max speed:
Motor efficiency :
Motor Protection index :
Insulation class :
Frequency:
Electrical voltage:
26
See pump rating plate
Zeox FIRST H: 16 bar
Zeox FIRST V: 6 bar
-5 to +90 °C
+40 °C
3
1000 kg/m
3
40 g/m
See rating plate
Motor according to IEC 60034-30
IP 55
155
See rating plate
WILO SE 11/2014
