Description Of The Product; Description; Technical Data - Wilo -Isar BOOST5 Installation And Operating Instructions Manual

4

Description of the product

4.1

Description

4.2

Technical data

Maximum utilisation pressure
Maximum operating pressure
Maximum suction pressure
Maximum volume flow
Delivery head Max.
suction geodesic head
Start-up pressure
Temperature range
Fluid temperature
Ambient temperature
Electrical data
Voltage
Frequency
Power consumed
Rated current
Alarm relay contact
Installation and operating instructions • Wilo-Isar BOOST5 • Ed.03/12/2022
Supply from a well, water source, reservoir, city network,
For irrigation, sprinkling, pressure-boosting etc.
NOTICE
Local regulations must be observed for all drinking water ap-
plications.
WARNING
In Germany, this product must not be used in drinking water
applications. Connection to the municipal water supply net-
work is not authorised.
The WRAS certificate is available for all Wilo-Isar BOOST5 pressure-boosting systems.
• Compact, silent and high-performance pump system.
• Electric system offering smart and intuitive product control:
maintains constant system pressure by adjusting pump speed based on water demand,
controls hydraulic and electric operating parameters and protects the pump from anom-
alies.
Fig. 1
1. Main on/off switch
2. Gland
3. Control panel
4. Filler screw
5. Expansion tank screw
6. Vent screw
7. Drainage screw
8. Discharge connection bent
9. Suction connection bent
10. Power supply cable
11. Damping feet
12. Connection fixation valves
5.5 bar
4.5 bar
See plate
See plate
8 m
1 bar
0 °C to +40 °C
0 °C to +40 °C
1 ~ 230 V AC
50 Hz
See plate
See plate
Max 0.3 A at 230 V AC/Max 1 A at 30 V DC
en
11
