802.1P Configuration Menu

7.10.2 802.1P Port Traffic Class Information

Screen Navigation Path
Password > Main Menu > Device Control Menu > 802.1P Configuration Menu > 802.1P Port
Traffic Class Information
When to Use
To view the current mapping of the Traffic Class-to-priority for each port, which can include both
physical and virtual ports. This switch provides two priority levels with weighted fair queuing for
port egress. This means that any frames with a default or user priority from 0~3 are sent to the low
priority queue "0" while those from 4~7 are sent to the high priority queue "1" as shown in
Figure 7-16.
How to Access
Use the arrow keys to highlight the 802.1P Port Traffic Class Information menu item on the
802.1P Configuration Menu screen and press ENTER. The 802.1P Port Traffic Class Information
screen, Figure 7-16, displays.
Device Control Menu Screens 7-33
