Spanning Tree Information Menu Screen
7.5.2

STA Port Information Screen

Screen Navigation Path
Password > Main Menu > Device Control Menu >Spanning Tree Information Menu > STA Port
Information
When to Use
To display current information about the STA Port. The parameters shown in
Table 7-9 are for port STA Information (Ports 1-12, Ports 13-24, Ports 25-36, or Ports 37-48).
NOTE: The actual number of ports varies depending on the module.
How to Access
Use the arrow keys to highlight the STA Port Information menu item on the Spanning Tree
Information Menu screen and press ENTER. The STA Port Information screen,
displays.
7-18 Device Control Menu Screens
Figure 7-9 and
Figure 7-9,
