Static Unicast Address Table Configuration Screen
Table 7-22 Static Unicast Address Table Screen Field Descriptions (Continued)
Use this field...
Status
(Lower right side of screen)
[Show]
[More]
[Set]
7-46
Device Control Menu Screens
To...
Select one of the following status settings that be associated
with the new VID, MAC and Port entries:
Permanent – This entry is currently in use and will remain so
after the next reset of the switch.
DeleteOnReset – This entry is currently in use and will
remain so until the next reset.
Lock Port – Enables the port locking mode. For details, refer
to
Section
11.15.1.
Unlock Port – Disables the port locking mode. For details,
refer to
Section
11.15.2.
Invalid – Removes the corresponding entry.
DeleteOnTimeOut – This entry is currently in use and will
remain so until it is aged out. (Refer to Aging Time in
Section
8.4.)
Other – This entry is currently in use, but the conditions
under which it will remain, differ from the preceding values.
See the static address table sorted on VID as the primary key
and MAC address as the secondary key.
Scroll through entries in the static address table.
Add the specified entry to the static address table, such as
shown in the following example:
VID: 1 MAC: 00-00-00-e8-34-22
Unit: 1 Port: 1
Status: Permanent
