Summary of Contents for Enterasys Matrix 7H4284-49

  • Page 1 Enterasys Matrix ® DFE-Platinum Series Hardware Installation Guide 7H4284-49 P/N 9033904-04...
  • Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
  • Page 4: Regulatory Compliance Information

    Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux  appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le  ministère des Communications du Canada. Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference  in which case the user may be required to take adequate measures.  Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar  interferencia de radio en cuyo caso puede ser requerido tomar medidas adecuadas. Klasse A ITE Anmerkung WARNHINWEIS: Dieses Produkt zählt zur Klasse A ( Industriebereich ). In Wohnbereichen kann es  hierdurch zu Funkstörungen kommen, daher sollten angemessene Vorkehrungen zum Schutz getroffen  werden.  Product Safety This product complies with the following: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950,  EN 60825, 21 CFR 1040.10. Seguridad del Producto El producto de Enterasys cumple con lo siguiente: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950,  IEC 60950, EN 60825, 21 CFR 1040.10.
  • Page 5: Hazardous Substances

    Dieses Produkt entspricht den folgenden Richtlinien: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950,  IEC 60950, EN 60825, 21 CFR 1040.10.  ELECTROMAGNETIC COMPATIBILITY (EMC) This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN  61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3.  Compatibilidad Electromágnetica (EMC) Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 2004/108/EC, EN  55022, EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität ( EMC ) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN  55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3.  This product complies with the requirements of European Directive, 2002/95/EC, Restriction of Hazardous  Substances (RoHS) in Electrical and Electronic Equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic  equipment (WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and  that this product was placed on the European market after August 13, 2005, the date of enforcement for  Directive 2002/96/EC.
  • Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
  • Page 7 VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by  Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio  disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case  the user may be required to take adequate measures.
  • Page 8 SAFETY INFORMATION CLASS 1 LASER TRANSCEIVERS The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control  loop eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow  any user adjustment. Class 1 Laser transceivers comply with the following safety standards: • 21 CFR 1040.10 and 1040.11 U.S. Department of Health and Human Services (FDA). • IEC Publication 825 (International Electrotechnical Commission). • CENELEC EN 60825 (European Committee for Electrotechnical Standardization). When operating within their performance limitations, laser transceiver output meets the Class 1 accessible  emission limit of all three standards. Class 1 levels of laser radiation are not considered hazardous. When the connector is in place, all laser radiation remains within the fiber. The maximum amount of radiant  ‐6 power exiting the fiber (under normal conditions) is ‐12.6 dBm or 55 x 10  watts.
  • Page 9: Declaration Of Conformity

    Application of Council Directive(s): 2004/108/EC European Representative Address: Enterasys Networks, Ltd. Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC Equipment Type/Environment: Networking Equipment, for use in a  Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above  directives. Declaration of Conformity 2006/95/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England EN 55022 EN 61000‐3‐2 EN 61000‐3‐3 EN 55024 EC Directive 2006/95/EC EN 60950 EN 60825 Commercial  or Light Industrial Environment.
  • Page 10 ENTERASYS NETWORKS, INC. FIRMWARE LICENSE AGREEMENT BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc.,  on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and  obligations with respect to the Enterasys software program/firmware (including any accompanying  documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting  or inconsistent terms and conditions appearing on any purchase order or other document submitted by You.  “Affiliate” means any person, partnership, corporation, limited liability company, other form of enterprise  that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under  common control with the party specified. This Agreement constitutes the entire understanding between the  parties, with respect to the subject matter of this Agreement. The Program may be contained in firmware,  chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE  AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN  ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE  DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE  TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE  DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE  TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT,  ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN  THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS  FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS,  LEGAL DEPARTMENT AT (978) 684‐1000.
  • Page 11 APPLICABLE LAW. This Agreement shall be interpreted and governed under the laws and in the state  and federal courts of the Commonwealth of Massachusetts without regard to its conflicts of laws provisions.  You accept the personal jurisdiction and venue of the Commonwealth of Massachusetts courts. None of the  1980 United Nations Convention on the Limitation Period in the International Sale of Goods, and the Uniform  Computer Information Transactions Act shall apply to this Agreement. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by  agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or  diversion of certain technical products to certain countries, unless a license to export the product is obtained  from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting  party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S.  Export Administration Regulations, You agree that You are a civil end user of the Program and agree that You  will use the Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S.  Export Administration Regulations, in addition to the restriction on transfer set forth in Section 1 or 2 of this  Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or  technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus,  Cambodia, Cuba, Georgia, Iraq, Kazakhstan, Laos, Libya, Macau, Moldova, Mongolia, North Korea, the  People’s Republic of China, Russia, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other  countries as may be designated by the United States Government), (ii) export to Country Groups D:1 or E:2  (as defined herein) the direct product of the Program or the technology, if such foreign produced direct  product is subject to national security controls as identified on the U.S. Commerce Control List, or (iii) if the  direct product of the technology is a complete plant or any major component of a plant, export to Country  Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such foreign produced  direct product is subject to national security controls as identified on the U.S. Commerce Control List or is  subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed  solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in  accordance with section 52.227‐19 (a) through (d) of the Commercial Computer Software‐Restricted Rights  Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its  suppliers. For Department of Defense units, the Program is considered commercial computer software in  accordance with DFARS section 227.7202‐3 and its successors, and use, duplication, or disclosure by the U.S.  Government is subject to restrictions set forth herein. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES EXPRESSLY PROVIDED TO  YOU IN WRITING BY ENTERASYS, ENTERASYS DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR  IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, ...
  • Page 12 OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree  that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You  agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All  right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not  specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement  by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate,  and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this  Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or  obligations under this Agreement, except that You may assign this Agreement to any person or entity which  acquires substantially all of Your stock assets. Enterasys may assign this Agreement in its sole discretion. This  Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted  transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or  sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must  be in writing and will not be construed as a waiver of any subsequent breach of such term or condition.  Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your  breach or prevent enforcement on any other occasion. 13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid, illegal or  unenforceable, the validity, legality and enforceability of any of the remaining provisions shall not in any way  be affected or impaired thereby, and that provision shall be reformed, construed and enforced to the  maximum extent permissible. Any such invalidity, illegality, or unenforceability in any jurisdiction shall not  invalidate or render illegal or unenforceable such provision in any other jurisdiction. 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the  terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of  the Program and shall return to Enterasys the Program and all copies of the Program.
  • Page 13: Table Of Contents

    Installing DFE Module into Matrix E7 or N7 Chassis ... 3-6 3.4.1 3.4.2 Installing Module into Matrix N1, N3, or N5 Chassis... 3-9 Switch Configuration Using WebView... 1-4 Switch Configuration Using CLI Commands... 1-4 FTM1 and FTM2 Connectivity... 3-3 Module Placement and Rules ... 3-3 Preparation ... 3-6 Installation... 3-7...
  • Page 14 Overview of DFE Module Shutdown Procedure... 4-7 4.3.1 4.3.2 SPECIFICATIONS DFE Module Specifications ...A-1 COM Port Pinout Assignments ...A-3 Regulatory Compliance...A-3 MODE SWITCH BANK SETTINGS AND OPTIONAL INSTALLATIONS Required Tools...B-1 Setting the Mode Switches...B-2 Memory Locations and Replacement Procedures ...B-3 B.3.1 B.3.2 B.3.3...
  • Page 15: Figures

    Matrix DFE Startup Screen Example (N7 Chassis)... 3-21 LANVIEW LEDs ... 4-2 OFFLINE/RESET Button ... 4-8 Mode Switch Location on 7H4284-49 ... B-3 DIMM and DRAM SIMM Locations on 7H4284-49... B-4 NEM Removal and DRAM SIMM Connector Location on the 7H4284-49 ... B-6 Removing the Existing DRAM SIMM...
  • Page 16: Tables

    Tables Table 7H4284-49 Specifications ... A-1 COM Port Pin Assignments ... A-3 Compliance Standards... A-3 Tables Page...
  • Page 17: Important Notice

    7H4284-49 DFE-Platinum module. For information about the CLI (Command Line Interface) set of commands used to configure and manage the DFE modules, refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide. Note: In this guide, the following terms are used: •...
  • Page 18: How To Use This Guide

    This preface provides an overview of this guide and the DFE module Series manual set, and a brief summary of each chapter; defines the conventions used in this document; and instructs how to obtain technical support from Enterasys Networks. To locate information about various subjects in this guide, refer to the following table: For...
  • Page 19: Document Conventions

    DOCUMENT CONVENTIONS This guide uses the following conventions: Note: Calls the reader’s attention to any item of information that may be of special importance. Caution: Contains information essential to avoid damage to the equipment. Precaución: Contiene información esencial para prevenir dañar el equipo. Achtung: Verweißt auf wichtige Informationen zum Schutz gegen Beschädigungen.
  • Page 20: Getting Help

    Getting Help GETTING HELP For additional support related to the modules or this document, contact Enterasys Networks using one of the following methods: World Wide Web www.enterasys.com/services/support/ Phone 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/services/support/contact/...
  • Page 21: Introduction

    7H4284-49 module. Overview of DFE-Platinum Module Capabilities The Platinum Distributed Forwarding Engine (DFE) is Enterasys Networks’ next generation of enterprise modules for the Matrix N-Series and Matrix E7 switches. These DFE modules deliver high performance and flexibility to ensure comprehensive switching, routing, Quality of Service, security, and traffic containment.
  • Page 22: The Dfe-Platinum Module

    This section provides an overview of the 7H4284-49 DFE-Platinum module (Figure 1-1). For information about features of the module and how to configure it, refer to the Enterasys Matrix DFE-Platinum Series Module Hardware Installation Guide. 7H4284-49 The 7H4284-49 DFE module has 48, 100BASE-FX compliant ports, via fixed front panel MT-RJ connectors and a slot for an optional network expansion module (NEM).
  • Page 23 Figure 1-1 7H4284-49 DFE Module 1 OFFLINE/RESET switch 2 RJ45 COM (also known as Console Port) 3 CPU LED 4 MGMT LED 5 GROUP SELECT switch À Á Â Ã Ä Å Æ È Ç GROUP STATUS LEDs GROUP SELECT LEDs...
  • Page 24: Connectivity

    Switch Configuration Using CLI Commands The CLI commands enable you to perform more complete switch configuration management tasks. For CLI command set information and how to configure the module, refer to the Enterasys Matrix DFE-Platinum Series Module Hardware Installation Guide.
  • Page 25: Secure Networks Policy Support

    Classification Rules determine how specific traffic flows (identified by Layer 2, Layer 3, and Layer 4 information in the data packet) are treated by each Switch or Router. In general, Classification Rules are applied to the networking infrastructure at the network edge/ingress point.
  • Page 26 LANVIEW Diagnostic LEDs Introduction...
  • Page 27: Network Requirements

    Failure to do so will produce poor network performance. Note: The Enterasys Matrix DFE-Platinum Series Configuration Guide and the Cabling Guide referred to in the following sections can be found on the Enterasys Networks World Wide Web site: Refer to “Related Documents”...
  • Page 28: Module Placement In A Matrix E7 Chassis

    Module Placement in a Matrix E7 Chassis MODULE PLACEMENT IN A MATRIX E7 CHASSIS If you want to mix 6x1xxx, 6x2xxx, 6x3xxx, and 7H43xx-xx series modules in the same Matrix E7 chassis, it is necessary to have a 7H4382-25, 7H4382-49, 7H4383-49, or 7H4385-49 DFE module installed and also follow the module placement rules described in successfully bridge data traffic to some or all modules in the chassis.
  • Page 29: Installation

    Electrical Hazard: Only qualified personnel should perform installation procedures. Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion. Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. This chapter provides the instructions to install the 7H4284-49 DFE module. Follow the order of the sections listed below to correctly install the DFE module.
  • Page 30: Unpacking The Dfe Module

    Note: Install any optional equipment before proceeding to explanation of the rules to install different modules in a Matrix E7 chassis. Refer to your release notes or the Enterasys Networks web site for the latest available network expansion modules. A Phillips screwdriver is required to install an optional NEM into the 7H4284-49 DFE module.
  • Page 31: Backplane Connections And Installation Rules

    FTM bridging DFE module such as the 7H4382-25, 7H4382-49, 7H4383-49, or the 7H4385-49. Note: For more information about the 7H4382-25, 7H4382-49, 7H4383-49, and 7H4385-49 DFE modules, refer to the Enterasys Networks web site: http://www.enterasys.com/support/manuals The FTM bridging modules have connections to both FTM1 and FTM2 backplanes, which enables them to switch frames between the two backplanes and all modules in the 6C107 chassis.
  • Page 32: Examples, Module Placement In Matrix E7 Chassis

    Backplane Connections and Installation Rules Figure 3-1 Examples, Module Placement in Matrix E7 Chassis Example 1 (Figure 3-1, Shows the chassis fully populated with DFE modules (7xxxxx). These modules communicate with each other via the FTM2 chassis backplane and act as a single switching entity with one IP address.
  • Page 33 Example 4 (Figure 3-1, Shows chassis slots 1 through 5 populated with a mix of 6x1xx, 6x2xx, and 6x3xx modules and only third generation modules in slots 6 and 7. In this module arrangement, the 6x3xx module provides a proxy bridge, which enables the 6x1xx and 6x2xx modules to communicate with 6x3xx modules in slot 6 or 7.
  • Page 34: Installing Dfe Module Into Matrix E7 Or N7 Chassis

    4. Remove the module from the plastic bag. (Save the bag in the event the module must be reshipped.) Observe all precautions to prevent damage from Electrostatic Discharge (ESD). 5. Examine the module for damage. If any damage exists, DO NOT install the module. Immediately contact Enterasys Networks. Refer to Installation “Getting Help”...
  • Page 35: Installation

    3.4.2 Installation To install the module, refer to Caution: To prevent damaging the backplane connectors in the following step, take care that the module slides in straight and properly engages the backplane connectors. Ensure that the top lever lines up with the desired slot number located on the front panel of the chassis.
  • Page 36: Installing Module Into Matrix E7 Or Matrix N7 Chassis (E7 Shown)

    Installing DFE Module into Matrix E7 or N7 Chassis 5. If the chassis in which the module is installed was powered down for the installation, turn the power supplies on. Check to see that the module CPU LED settles at solid green after a few minutes.
  • Page 37: Installing Module Into Matrix N1, N3, Or N5 Chassis

    INSTALLING MODULE INTO MATRIX N1, N3, OR N5 CHASSIS Caution: Failure to observe static safety precautions could cause damage to the DFE module. Follow static safety handling rules and wear the antistatic wrist strap. Do not cut the non-conductive bag to remove the module. Sharp objects contacting the board or components can cause damage.
  • Page 38: Installing Module Into Matrix N1, N3, Or N5 Chassis (N3 Shown)

    Link Aggregation to operate properly. Before connecting the cables, refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for the configuration information. For details on how to obtain manuals, refer to the...
  • Page 39: Connecting Fiber-Optic Cables From 7H4284-49 To The Network

    3.6.1 Connecting Fiber-Optic Cables from 7H4284-49 to the Network This section provides the procedures to connect fiber-optic cables from the 100BASE-FX, MT-RJ front panel ports of the 7H4284-49 to the network or other devices. Each fiber-optic link consists of two fiber-optic strands within the cable: Transmit (TX) and Receive (RX). The transmit strand from a DFE module port connects to the receive port of a fiber-optic 100BASE-FX Ethernet device at the other end of the segment.
  • Page 40: Connecting A Fiber-Optic Segment To The Mt-Rj Front Panel Connector

    3-4) to step to the appropriate group. Each time the GROUP SELECT switch is pressed, the GROUP LED lights up in sequence, indicating which Group is selected. On the 7H4284-49, you can step to 1, 2, 3, or 4 for Groups 1 through 4. The receive and transmit activity for that group of segments is then indicated by the RX and TX LEDs for each segment.
  • Page 41: Connecting To Com Port For Local Management

    This section describes how to install a UTP cable with RJ45 connectors and optional adapters to connect a PC, a VT series terminal, or a modem to an Enterasys Networks module to access Local Management. This section also provides the pinout assignments of the adapters.
  • Page 42 Transmit Bits Parity Stop Bit 4. When these parameters are set, the Local Management password screen will display. Refer to the appropriate Enterasys Matrix DFE-Platinum Series Configuration Guide for further information. Figure 3-5 Connecting an IBM PC or Compatible Ã...
  • Page 43: Connecting To A Vt Series Terminal

    UTP straight-through cable with RJ45 connectors and an optional RJ45-to-DB25 female adapter, and proceed as follows: 1. Connect the RJ45 connector at one end of the cable to the COM port on the Enterasys Networks module. 2. Plug the RJ45 connector at the other end of the cable into the RJ45-to-DB25 female adapter.
  • Page 44: Connecting To A Modem

    2 RJ45 COM port 3.7.4 Connecting to a Modem To connect a modem to an Enterasys Networks DFE module COM port straight-through cable with RJ45 connectors and an optional RJ45-to-DB25 male adapter, and proceed as follows: 1. Connect the RJ45 connector at one end of the cable to the COM port of the DFE module.
  • Page 45: Connecting To A Modem

    5. With a PC connected to a remote modem, you can configure the switch remotely. To accomplish this, you must configure your PC VT emulation package with the following parameters. Parameter Mode Transmit Bits Parity Stop Bit 6. When these parameters are set, the Local Management password screen will display. Refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for further information.
  • Page 46: Adapter Wiring And Signal Assignments

    Connecting to COM Port for Local Management 3.7.5 Adapter Wiring and Signal Assignments COM Port Adapter Wiring and Signal Diagram RJ45 Conductor Blue Green Orange Yellow VT Series Port Adapter Wiring and Signal Diagram RJ45 Conductor Blue Yellow Green Orange 3-18 Installation Signal...
  • Page 47: Completing The Installation

    In a new system of DFE modules, one of the installed DFE modules will become the management module on chassis power up, and all DFE modules will automatically be set to the factory default values. A complete list of the factory default values are provided in Chapter 3 of the Enterasys Matrix DFE-Platinum Series Configuration Guide.
  • Page 48 The Enterasys Matrix DFE-Platinum Series Configuration Guide is available online at: http://www.enterasys.com/support/manuals If you require assistance, contact Enterasys Networks using one of the methods described in “Getting Help” on page xviii.
  • Page 49: Completing The Installation Of A Dfe Module In An Existing System

    If you need to change any settings, you can connect a terminal to the local console port as described in Section 3.7 to access system management, or use a Telnet connection to access the DFE module system management as described in Chapter 3 of the Enterasys Matrix DFE-Platinum Series Configuration Guide. xxxxxxxxxxxx Completing the Installation...
  • Page 50 Completing the Installation 3-22 Installation...
  • Page 51: Troubleshooting

    This chapter provides information concerning the following: • Using LANVIEW (Section • Troubleshooting Checklist • DFE Module Shutdown Procedures (Special Instructions) Recommended Shutdown Procedure Using OFFLINE/RESET Button Last Resort Shutdown Procedure Using OFFLINE/RESET Button Unless otherwise noted, the following information applies to all DFE modules. USING LANVIEW The modules use a built-in visual diagnostic and status monitoring system called LANVIEW.
  • Page 52 Using LANVIEW Figure 4-1 LANVIEW LEDs 1 MGMT LED Table 4-1 describes the LED indications and provides recommended actions as appropriate. Note: The terms used in Flashing indicates an LED is flashing randomly. Blinking indicates an LED is flashing at a steady rate (approximately 50% on, 50% off). Solid indicates a steady LED light.
  • Page 53 60 seconds before automatically restarting. Recommended Action Ensure chassis has adequate power. None. If the LED remains amber for several minutes, contact Enterasys Networks for technical support. None. None. None. None. This state is activated when the OFFLINE/RESET button is pressed for less than 1 second to start the process of an orderly shutdown.
  • Page 54 None. Contact Enterasys Networks for technical support. If it is known that the port should be active and is not, contact Enterasys Networks for technical support. None. None, unless there is a high rate of activity. In this case, check for network configuration problems or a defective device.
  • Page 55: Troubleshooting Checklist

    Recommended Action Ensure that the module was installed properly according to the installation instructions in Chapter chassis is providing power. Refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for proper setup procedures. Refer to Appendix A pinouts. If possible, attempt to download the image to the module again.
  • Page 56 Recommended Action Refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for the IP address assignment procedure. Enable port. Refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for instructions to enable/disable ports. Verify that a management VLAN exists and that it is associated with the Host Port.
  • Page 57: Overview Of Dfe Module Shutdown Procedure

    The DFE modules installed in a Matrix E7, Matrix N3, or Matrix N7 chassis are interdependent and operate under a single IP address as a single, distributed switch system (hardware, databases, and persistent storage). In this operating environment, the DFE module must shut down in an orderly fashion to ensure that the other modules in the system and other devices on the network are notified of the impending change.
  • Page 58: Recommended Shutdown Procedure Using Offline/Reset Button

    Overview of DFE Module Shutdown Procedure Figure 4-2 OFFLINE/RESET Button 1 OFFLINE/RESET button 4.3.1 Recommended Shutdown Procedure Using OFFLINE/RESET Button Caution: Do not pull any DFE module out of an operating chassis before it has completed its shutdown routine. Precaución: No retire los módulos DFE del chasis en funcionamiento hasta que no se haya terminado con la rutina de apagado.
  • Page 59: Last Resort Shutdown Procedure Using Offline/Reset Button

    4.3.2 Last Resort Shutdown Procedure Using OFFLINE/RESET Button Caution: This method of shutting down a DFE module is not recommended except as a last resort, because all processes currently running on the module will be interrupted resulting in loss of frames. Precaución: No se recomienda utilizar este método para apagar los módulos DFE.
  • Page 60 Overview of DFE Module Shutdown Procedure 4-10 Troubleshooting...
  • Page 61: A.1 Dfe Module Specifications

    • COM port pinout assignment • Regulatory compliance Enterasys Networks reserves the right to change the specifications at any time without notice. DFE MODULE SPECIFICATIONS Table A-1 provides the I/O ports, processors and memory, physical, and environmental specifications for the 7H4284-49 DFE module.
  • Page 62 4.10 kg (9.0 lb) (one module without packaging) For the MTBF hours for these products, refer to the MTBF web site at URL http://www.enterasys.com/support/mtbf/ 5°C to 40°C (41°F to 104°F) -30°C to 73°C (-22°F to 164°F) 5% to 90% (non-condensing)
  • Page 63: A.3 Regulatory Compliance

    COM PORT PINOUT ASSIGNMENTS The COM port is a serial communications port that supports Local Management. the COM port pin assignments. Table A-2 COM Port Pin Assignments Signal Name Transmit Data (XMT) Clear to Send (CTS) Data Set Ready (DSR) Receive Data (RCV) Signal Ground (GND) Request to Send (RTS)
  • Page 64 Regulatory Compliance Specifications...
  • Page 65: B.1 Required Tools

    Precaución: Para llevar a cabo los procedimientos especificados en el apéndice deberá utilizar una pulsera antiestática. Esta pulsera sirve para minimizar los efectos de las descargas de electricidad estática. Mode Switch Bank Settings and Optional Installations B.1) Mode Switch Bank Settings and Optional Installations (Section B.2) (Section B.3)
  • Page 66: Setting The Mode Switches

    Once the module resets, you can either use the factory default settings or reenter your own password. Note: Do not change the position of Switch 8 unless it is necessary to reset the admin password to its factory default setting.
  • Page 67: Memory Locations And Replacement Procedures

    Memory Locations and Replacement Procedures Figure B-1 Mode Switch Location on 7H4284-49 À 1 Mode switch pack (switches shown in factory settings, all off) MEMORY LOCATIONS AND REPLACEMENT PROCEDURES In the event that the Dual In-line Memory Module (DIMM) or DRAM Single In-line Memory Module (SIMM) (FLASH memory) needs to be replaced, the following sections describe how to locate, access, and replace these memory modules.
  • Page 68: Dimm And Simm Locations

    DIMM and DRAM SIMM on the main board. Figure B-2 DIMM and DRAM SIMM Locations on 7H4284-49 Â Á À 1 DRAM SIMM 2 DIMM 3 Main PC board Mode Switch Bank Settings and Optional Installations...
  • Page 69: Dram Simm Replacement Procedure

    Remove and save the two screws attaching the NEM to the front panel. b. Lift the NEM straight up and off the two module connectors on the main PC board. Memory Locations and Replacement Procedures Mode Switch Bank Settings and Optional Installations Figure B-3 Figure B-4...
  • Page 70: B-3 Nem Removal And Dram Simm Connector Location On The 7H4284-49

    Note: The ejector arms on this connector are not spring loaded, so they will remain in the open position until manually closed. 3. Remove the module from the connector. Mode Switch Bank Settings and Optional Installations  à 4 DFE module front panel...
  • Page 71: B-4 Removing The Existing Dram Simm

    2. Push the DRAM SIMM further into the connector until the two alignment notches and the tabs on the two connector arms lock the DRAM SIMM into place. Memory Locations and Replacement Procedures À Â 2 Memory module Figure B-5 and proceed as follows: Mode Switch Bank Settings and Optional Installations Á À Connector...
  • Page 72: B-5 Installing The Dram Simm

    DIMM. If you have questions concerning the replacement of the DIMM, refer to “Getting Help” on page xviii for details on how to contact Enterasys Networks. Removing the DIMM Note: To access and remove a DIMM, you may need to remove the optional network expansion module (NEM), if one is installed in your DFE module.
  • Page 73: B-6 Removing The Existing Dimm

    Then release the two connector arms to lock the DIMM into place. Memory Locations and Replacement Procedures À Â 2 DIMM Figure B-7 and proceed as follows: Mode Switch Bank Settings and Optional Installations Figure B-6, and simultaneously lift Á À Connector fingers...
  • Page 74: B-7 Installing The Dimm

    Memory Locations and Replacement Procedures Figure B-7 Installing the DIMM 1 DIMM 2 Connector fingers B-10 Mode Switch Bank Settings and Optional Installations à  Á 3 Connector arms 4 Alignment notches (2) À à Â...
  • Page 75 Numerics 100BASE-TX requirements 2-1, 7H4284-49 introduction to Cable specifications 100BASE-TX network 2-1, CLI command introduction to COM port pin assignments for COM port connections what is needed 3-13 Connecting to the network 3-10, Connectivity DFE module and network expansion module introduction to 1-2, Conventions list of document...
  • Page 76 Shutdown procedure last resort procedure using offline/reset switch recommended procedure using offline/reset switch for Specifications DFE module Standards compatibility Technical support contacting Enterasys for xviii Transmit LEDs viewing of Troubleshooting checklist for Unpacking the module User Personalized Networks (UPN) See Secure Networks Policy Support.
