- Page 1 Enterasys Matrix ® DFE-Platinum Series Hardware Installation Guide 7G4202-72 7G4282-49 P/N 9034095-03...
- Page 3 The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2008 Enterasys Networks, Inc. All rights reserved. Part Number: 9034095‐03 July 2008 ENTERASYS, ENTERASYS NETWORKS, ENTERASYS MATRIX, ENTERASYS NETSIGHT, LANVIEW, WEBVIEW, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and other countries. For a complete list of Enterasys trademarks, see http://www.enterasys.com/company/trademarks.aspx. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals Dokumentation im Internet: http://www.enterasys.com/support/manuals Notice...
-
Page 4: Regulatory Compliance Information
Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia de radio en cuyo caso puede ser requerido tomar medidas adecuadas. Klasse A ITE Anmerkung WARNHINWEIS: Dieses Produkt zählt zur Klasse A ( Industriebereich ). In Wohnbereichen kann es hierdurch zu Funkstörungen kommen, daher sollten angemessene Vorkehrungen zum Schutz getroffen werden. Product Safety This product complies with the following: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. Seguridad del Producto El producto de Enterasys cumple con lo siguiente: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. Produktsicherheit Dieses Produkt entspricht den folgenden Richtlinien: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. ... -
Page 5: Hazardous Substances
This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 2004/108/EC, EN 55022, EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität ( EMC ) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. This product complies with the requirements of European Directive, 2002/95/EC, Restriction of Hazardous Substances (RoHS) in Electrical and Electronic Equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic equipment (WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and that this product was placed on the European market after August 13, 2005, the date of enforcement for Directive 2002/96/EC. When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/support/ Customer Support at 353 61 705586 (Ireland). Electromagnetic Compatibility (EMC) Compatibilidad Electromágnetica (EMC) Hazardous Substances or contact Enterasys ... - Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
-
Page 7: Safety Information
VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Safety Information Class 1 Laser Transceivers The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow any user adjustment. Class 1 Laser ... -
Page 8: Declaration Of Conformity
Application of Council Directive(s): 2004/108/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road European Representative Address: Enterasys Networks, Ltd. Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC Equipment Type/Environment: Networking Equipment, for use in a Commercial Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. ENTERASYS NETWORKS, INC. FIRMWARE LICENSE AGREEMENT BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other ... - Page 9 (b) Incorporate the Program in whole or in part, in any other product or create derivative works based on the Program, in whole or in part. (c) Publish, disclose, copy reproduce or transmit the Program, in whole or in part. (d) Assign, sell, license, sublicense, rent, lease, encumber by way of security interest, pledge or otherwise transfer the Program, in whole or in part. (e) Remove any copyright, trademark, proprietary rights, disclaimer or warning notice included on or embedded in any part of the Program. APPLICABLE LAW. This Agreement shall be interpreted and governed under the laws and in the state and federal courts of the Commonwealth of Massachusetts without regard to its conflicts of laws provisions. You accept the personal jurisdiction and venue of the Commonwealth of Massachusetts courts. None of the 1980 United Nations Convention on the Limitation Period in the International Sale of Goods, and the Uniform Computer Information Transactions Act shall apply to this Agreement. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain technical products to certain countries, unless a license to export the product is obtained from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S. Export Administration Regulations, You agree that You are a civil end user of the Program and agree that You will use the Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Section 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Cambodia, Cuba, Georgia, Iraq, Kazakhstan, Laos, Libya, Macau, Moldova, Mongolia, North Korea, the People’s Republic of China, Russia, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be designated by the United States Government), (ii) export to Country Groups D:1 or E:2 (as defined herein) the direct product of the Program or the technology, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List, or (iii) if the direct product of the technology is a complete plant or any major component of a plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed solely at private ...
- Page 10 OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion. 13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid, illegal or unenforceable, the validity, legality and enforceability of any of the remaining provisions shall not in any way be affected or impaired thereby, and that provision shall be reformed, construed and enforced to the maximum extent permissible. Any such invalidity, illegality, or unenforceability in any jurisdiction shall not invalidate or render illegal or unenforceable such provision in any other jurisdiction. 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program. viii...
-
Page 11: Table Of Contents
7G4202-72 ... 1-4 7G4282-49 ... 1-4 Management ... 1-4 Switch Configuration Using WebView ... 1-4 Switch Configuration Using CLI Commands ... 1-4 Secure Networks Policy Support ... 1-4 Standards Compatibility ... 1-5 LANVIEW Diagnostic LEDs ... 1-5 Chapter 2: Network Requirements Link Aggregation ... - Page 12 Troubleshooting Checklist ... 4-4 Overview of DFE-Platinum Module Shutdown Procedure ... 4-6 Recommended Shutdown Procedure Using OFFLINE/RESET Switch ... 4-7 Last Resort Shutdown Procedure Using OFFLINE/RESET Switch ... 4-7 Appendix A: Specifications DFE-Platinum Module Specifications ...A-1 COM Port Pinout Assignments ...A-2 Regulatory Compliance ...A-3...
-
Page 13: About This Guide
This guide provides an overview, installation and troubleshooting instructions, and specifications for the Enterasys Matrix For information about the CLI (Command Line Interface) set of commands used to configure and manage the DFE modules, refer to the Enterasys Matrix DFE‐Platinum Series Configuration Guide. Note: In this guide, the following terms are used: • DFE refers to Distributed Forwarding Engine series of modules. • DFE module or module refers to both the 7G4202-72 and 7G4282-49 modules. If the information applies to only one of the modules, the module is referred to by its model number (such as 7G4282-49). -
Page 14: How To Use This Guide
How to Use This Guide How to Use This Guide Read through this guide completely to familiarize yourself with its contents and to gain an understanding of the features and capabilities of the DFE modules. A general working knowledge of data communications networks is helpful when setting up these modules. This preface provides an overview of this guide and the DFE‐Platinum manual set, and a brief summary of each chapter; defines the conventions used in this document; and instructs how to obtain technical support from Enterasys Networks. To locate information about various subjects in this guide, refer to the following table: For... An overview of the DFE modules Network requirements that must be met before installing the DFE modules Instructions to install the DFE module hardware... -
Page 15: Conventions Used In This Guide
• Network load and frame size at the time of trouble (if known) www.enterasys.com/services/support/ 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/services/support/contact/ support@enterasys.com To expedite your message, type [SWITCHING] in the subject line. Conventions Used in This Guide DFE-Platinum Series Hardware Installation Guide xiii... - Page 16 Getting Help • The device history (for example, have you returned the device before, is this a recurring problem) • Any previous Return Material Authorization (RMA) numbers xiv About This Guide...
-
Page 17: Overview Of Dfe-Platinum Module Capabilities
This chapter provides an overview of the DFE‐Platinum module capabilities, and introduces the 7G4202‐72 and 7G4282‐49 modules. For information about... Overview of DFE-Platinum Module Capabilities DFE-Platinum Modules Connectivity Management Standards Compatibility Secure Networks Policy Support LANVIEW Diagnostic LEDs Overview of DFE-Platinum Module Capabilities The Platinum Distributed Forwarding Engine (DFE) is Enterasys Networks’ next generation of enterprise modules for the Matrix N‐Series and Matrix E7 switches. These DFE modules deliver high performance and flexibility to ensure comprehensive switching, routing, Quality of Service, security, and traffic containment. Key features include: • Superior performance and capacity to support more high‐bandwidth and latency sensitive applications • 10/100/1000 Base‐TX, 1000 Base‐SX/‐LX, and 10 Gigabit Ethernet connectivity • Integrated Services Design that reduces the number/type of modules required, simplifies ... -
Page 18: Dfe-Platinum Modules
DFE-Platinum Modules DFE-Platinum Modules This section provides an overview of DFE modules 7G4202‐72 and 7G4282‐49 (Figure Each of the fixed front panel ports can operate in either half‐duplex or full‐duplex mode of operation. The duplex mode can be determined by either auto‐negotiation or manual configuration. The DFE module ports can be configured to control traffic by limiting the rate of traffic accepted into the module and prioritizing traffic to expedite the flow of higher priority traffic through the module. The DFE module receives power and backplane connectivity when it is inserted into the Matrix N1, Matrix N3, Matrix N5, Matrix N7, or Matrix E7 chassis. The information concerning the DFE module features and how to configure them to a network is provided in the Enterasys Matrix DFE‐Platinum Series Configuration Guide. 7G4202-72 The 7G4202‐72 is an edge‐network switch with 72, 10BASE‐T/100BASE‐TX/1000BASE‐T ports via 72 front‐panel RJ45 connectors. 7G4282-49 The 7G4282‐49 is an edge‐network switch with 48, 10BASE‐T/100BASE‐TX/1000BASE‐T compliant ports by means of 48 fixed front‐panel RJ45 connectors and a slot for an optional network expansion module (NEM). 1-2 Introduction 1‐1). -
Page 19: 7G4202-72 And 7G4282-49 Modules
Figure 1-1 7G4202-72 and 7G4282-49 Modules 1 OFFLINE/RESET switch 2 RJ45 COM (Console Port) 3 CPU LED 4 MGMT LED 5 GROUP SELECT button Network Expansion Module (NEM) Option The 7G4282‐49 option slot provides access to an installed network expansion module. Refer to the Enterasys Networks web site for a current listing of the available NEMs. Specific installation instructions are shipped with each NEM. À Â Á Ã Ç È È... -
Page 20: Management
Connectivity Connectivity 7G4202-72 The 7G4202‐72 has 10BASE‐T/100BASE‐TX/1000BASE‐T compliant ports through 72, fixed RJ45 front panel connectors. 7G4282-49 The 7G4282‐49 (Figure connected through 48, fixed RJ45 front panel connectors. If a NEM is installed, additional connectors are also available, depending on the NEM model. Management Management of the module can be either in‐band or out‐of‐band. In‐band remote management is possible using Telnet, Enterasys Networks’ NetSight application. Out‐of‐band management is provided through the RJ45 COM (Communication) port on the front panel using a VT100 terminal or a VT100 terminal emulator. Switch Configuration Using WebView Enterasys Networks’ HTTP‐based Web management application (WebView) is an intuitive web tool for simple management tasks. Switch Configuration Using CLI Commands The CLI commands enable you to perform more complete switch configuration management tasks. For CLI command set information and how to configure the module, refer to the Enterasys Matrix DFE‐Platinum Series Configuration Guide. Secure Networks Policy Support Policy Enabled Networking manages the allocation of networking infrastructure resources in a secure and effective manner. Using Secure Networks Policy, an IT Administrator can predictably assign appropriate resources to the Users, Applications, and Services that use the network; while blocking or containing access for inappropriate or potentially dangerous network traffic. Using this technology it is possible, for the first time, to align IT services with the needs of specific users ... -
Page 21: Standards Compatibility
• Network Services are logical groups of Classification Rules that identify specific networked applications or services. Users may be permitted or denied access to these services based on their role within the organization. Priority and bandwidth rate limiting may also be controlled using Network Services. • Behavioral Profiles (or roles) are used to assign Network Services to groups of users who share common needs–for example Executive Managers, Human Resources Personnel, or Guest Users. Access, resources, and security restrictions are applied as appropriate to each Behavioral Profile. A variety of authentication methods including 802.1X, EAP‐TLS, EAP‐ TTLS, and PEAP may be used to classify and authorize each individual user; and the IT Administrator may also define a Behavioral Profile to apply in the absence of an authentication framework. Standards Compatibility The DFE modules are fully compliant with the IEEE 802.3‐2002, 802.3ae‐2002, 802.1D‐1998, and 802.1Q‐1998 standards. The DFE module provides IEEE 802.1D‐1998 Spanning Tree Algorithm (STA) support to enhance the overall reliability of the network and protect against “loop” conditions. LANVIEW Diagnostic LEDs LANVIEW diagnostic LEDs serve as an important troubleshooting aid by providing an easy way to observe the status of individual ports and overall network operations. Standards Compatibility DFE-Platinum Series Hardware Installation Guide 1-5... - Page 22 LANVIEW Diagnostic LEDs 1-6 Introduction...
-
Page 23: Chapter 2: Network Requirements
10BASE-T Network 100BASE-TX Network 1000BASE-T Network Note: The Enterasys Matrix DFE-Platinum Series Configuration Guide and the Cabling Guide referred to in the following sections can be found on the Enterasys Networks World Wide Web site: http://www.enterasys.com/support/manuals Refer to Link Aggregation Link Aggregation is a method of grouping multiple physical ports on a network device into one ... -
Page 24: 10Base-T Network
10BASE-T Network 10BASE-T Network When connecting a 10BASE‐T segment to any of the fixed front panel ports of the 7G4202‐72 or 7G4282‐49, ensure that the network meets the Ethernet network requirements of the IEEE 802.3‐2002 standard for 10BASE‐T. Refer to the Cabling Guide for details. Note: If a port is to operate at 100 Mbps, Category 5 cabling must be used. Category 3 cabling does not meet 100 Mbps specifications. For 10 Mbps operation only, Category 3 or Category 5 cabling can be used. -
Page 25: Important Notice
Electrical Hazard: Only qualified personnel should perform installation procedures. Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion. Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Read the Release Notes shipped with the DFE-Platinum module to check for any exceptions to the supported features and operation documented in this guide. -
Page 26: Unpacking The Dfe-Platinum Module
This Installation Guide Customer Release Notes Remove the tape seal on the non‐conductive bag to remove the DFE module. Perform a visual inspection of the DFE module for any signs of physical damage. Contact Enterasys Networks if there are any signs of damage. Refer to “Getting Help” on page xiii for details. Installing Optional Network Expansion Modules (NEMs) Note: Install any optional equipment before proceeding to Rules” on page 3-2 for an explanation of the rules to install different series modules in a Matrix E7 chassis. -
Page 27: Module Placement And Rules
The FTM bridging modules have connections to both FTM1 and FTM2 backplanes, which enables them to switch frames between the two backplanes and all modules in the 6C107 chassis. However, the older first (6x1xx), second (6x2xx), and third (6x3xx) generation modules are still managed using their own Local Management and are not subject to management by the DFE‐Platinum module management entity. The Matrix N1 (7C111), Matrix N3 (7C103), Matrix N5 (7C105‐P), and Matrix N7 (7C107) chassis have only FTM2 connections and support only DFE modules. The Matrix N5 chassis also has backplane power connections to support DFE PoE modules. Module Placement and Rules The DFE‐Platinum modules can be installed in a Matrix Placement,” below, for placement rules), Matrix N1, Matrix N3, Matrix N5, or Matrix N7 chassis. The Matrix N1, Matrix N3, Matrix N5, and Matrix N7 chassis support only DFE modules and there are no particular rules for installing modules. Matrix E7 Chassis, Module Placement Depending on the modules being installed in the Matrix E7 chassis and to help ensure proper operation, consider the following examples and rules for module placement in the chassis. Figure 3‐1 shows five examples of chassis module placement. These examples are described below along with the applicable module placement rule. Figure 3-1... - Page 28 Backplane Connections and Installation Rules Example 3 (Figure Shows chassis slots 1 through 5 populated with first and second generation modules (6x1xx and 6x2xx). If a 6x1xx or 6x2xx series module is installed in slot 6 or 7, it will operate in standalone mode (no backplane connectivity). Like the 6x3xx modules, the 6x1xx and 6x2xx modules operate as individual modules with separate IP addresses, and each one is configured using Local Management. Rule: The 6x1xx and 6x2xx modules can communicate with each other when they are installed in chassis slots 1 through 5 in the Matrix E7 chassis. If installed in slot 6 or 7, they operate in standalone mode. Example 4 (Figure Shows chassis slots 1 through 5 populated with a mix of 6x1xx, 6x2xx, and 6x3xx modules and only third generation modules in slots 6 and 7. In this module arrangement, the 6x3xx module provides a proxy bridge, which enables the 6x1xx and 6x2xx modules to communicate with 6x3xx modules in slot 6 or 7. If more than one 6x3xx module is installed in slots 1 to 5, the module in the lowest numbered slot performs the proxy function for slots 6 and 7. Therefore, if a 6x3xx module is already performing the proxy function, and another 6x3xx module is inserted into a lower numbered slot, connectivity will be temporarily interrupted, as the new board takes over the proxy function. When a 6x3xx module in a lower numbered slot is removed, and there is a 6x3xx module in a higher numbered slot, communication is not interrupted. For Local Management, plugging the Local Management connection into the 6x3xx modules will allow management connections to all 6x1xx, 6x2xx, and 6x3xx modules. If the Local Management connection is to a 6x1xx or 6x2xx board, only the modules in the first five slots will be recognized by the management client. Rule: There must be at least one 6x3xx module in slots 1 through 5 to enable communications between the 6x1xx, 6x2xx, and 6x3xx modules. Example 5 (Figure Shows chassis slots 1 and 5 populated with 6x1xx, 6x2xx modules, respectively; slots 2 through 4 with DFE‐Platinum modules without a bridging module; and slots 6 and 7 with 6x3xx modules. ...
-
Page 29: Installing Module Into Matrix E7 Or Matrix N7 Chassis
éstos podrían dañarse. To install a DFE‐Platinum module into a Matrix E7 or Matrix N7 chassis, proceed directly to “Preparation” on page 3‐5 to start the installation process. Preparation Remove the blank panel covering the slot in which the module will be installed. All other slots must remain covered to ensure proper airflow for cooling. (Save the blank plate in the event you need to remove the module.) Remove the module from the shipping box. (Save the box and packing materials in the event the module needs to be reshipped.) Locate the antistatic wrist strap shipped with the chassis. Attach the antistatic wrist strap to your wrist and plug the cable from the antistatic wrist strap into the ESD grounding receptacle at the upper right corner of the chassis. Remove the module from the plastic bag. (Save the bag in the event the module must be reshipped.) Observe all precautions to prevent damage from Electrostatic Discharge (ESD). Examine the module for damage. If any damage exists, DO NOT install the module. Immediately contact Enterasys Networks. Refer to “Getting Help” on page xiii. Installing Module into Matrix E7 or Matrix N7 Chassis DFE-Platinum Series Hardware Installation Guide 3-5... -
Page 30: Installation
Installing Module into Matrix E7 or Matrix N7 Chassis Installation To install the module, refer to Figure Caution: To prevent damaging the backplane connectors in the following step, take care that the module slides in straight and properly engages the backplane connectors. Ensure that the top lever lines up with the desired slot number located on the front panel of the chassis. - Page 31 Figure 3-2 Installing Module into Matrix E7 or Matrix N7 Chassis (E7 shown) Æ Ã Card guides Slot number 1 (Left-most slot is 1.) Module card Metal back panel Á SERIES Â À Upper/lower locking tabs (in proper open position) Upper/lower locking tab (in closed position) Backplane connectors (power and FTM2) Installing Module into Matrix E7 or Matrix N7 Chassis...
-
Page 32: Installing Module Into Matrix N1, N3, Or N5 Chassis
Installing Module into Matrix N1, N3, or N5 Chassis Installing Module into Matrix N1, N3, or N5 Chassis Caution: Failure to observe static safety precautions could cause damage to the DFE module. Follow static safety handling rules and wear the antistatic wrist strap. Do not cut the non-conductive bag to remove the module. -
Page 33: Connecting To The Network
Link Aggregation to operate properly. Before connecting the cables, refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for the configuration information. For details on how to obtain manuals,... -
Page 34: Connecting A Twisted Pair Segment To The Dfe-Platinum Module
Connecting to the Network Figure 3-4 Connecting a Twisted Pair Segment to the DFE-Platinum Module 1 RJ45 connector 2 RJ45 port connector (port 1) Verify that a link exists by checking that the port RX (Receive) LED is ON (flashing amber, blinking green, or solid green). If the RX LED is OFF and the TX (Transmit) LED is not blinking amber, perform the following steps until it is on: To view the receive and transmit activity on a group of segments, press the GROUP SELECT button (see Figure 7G4202‐72, or Groups 1 through 5 on the 7G4282‐49). Each time the GROUP SELECT button is pressed, a GROUP LED lights up in sequence, indicating which Group is selected. The receive and transmit activity for that group of segments is then indicated by the RX and TX LEDs for each segment. b. Verify that the cabling being used is Category 5 UTP with an impedance between 85 and 111 ohms. For the port to operate at 100 or 1000 Mbps, Category 5 cabling must be used and installed properly. Verify that the device at the other end of the twisted pair segment is on and properly connected to the segment. -
Page 35: Crossover Four-Wire Cable Rj45 Pinouts, Connections Between Hub Devices
Figure 3-5 Crossover Four-Wire Cable RJ45 Pinouts, Connections Between Hub Devices À Ã 1 RJ45 device port Other device port Figure 3-6 Four-Wire Crossover Cable RJ45 Pinouts, Connections Between Hub Devices À Ã 1 RJ45 device port Other device port Figure 3-7 Eight-Wire Crossover Cable RJ45 Pinouts, Connections Between Hub Devices À... -
Page 36: Connecting To Com Port For Local Management
Figure 3-8 Eight-Wire Straight-Through Cable RJ45 Pinouts, Connections Between Switches and End-User Devices 1 RJ45 device port 2 Other device port Ensure that the twisted pair connection meets the dB loss and cable specifications outlined in the Cabling Guide. Refer to “Related Documents” on page xii for information on obtaining this document. If a link is still not established, contact Enterasys Networks. Refer to “Getting Help” on page xiii for details. Repeat steps 1 through 3 above, until all connections have been made. Connecting to COM Port for Local Management This section describes how to install a UTP straight‐through cable with RJ45 connectors and optional adapters to connect a PC, a VT series terminal, or a modem to an Enterasys Networks module to access Local Management. This section also provides the pinout assignments of the ... -
Page 37: Connecting To An Ibm Pc Or Compatible Device
Connecting to an IBM PC or Compatible Device To connect an IBM PC or compatible device, running the VT terminal emulation, to an Enterasys Networks module COM port (Figure Connect the RJ45 connector at one end of a UTP straight‐through cable to the communications COM port on the Enterasys Networks module. (The COM port is also known as a Console port.) Plug the RJ45 connector at the other end of the UTP straight‐through cable into an RJ45‐to‐ DB9 adapter . Connect the RJ45‐to‐DB9 adapter to the communications port on the IBM PC. Turn on the PC and configure your VT emulation package with the following parameters: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the startup screen will display. Refer to the appropriate Enterasys Matrix DFE‐Platinum Series Configuration Guide for further information. Figure 3-9 Connecting an IBM PC or Compatible 1 UTP straight-through cable with RJ45 connectors 2 RJ45 COM port 3‐9), proceed as follows:... -
Page 38: Connecting To A Vt Series Terminal
Connecting to COM Port for Local Management Connecting to a VT Series Terminal To connect a VT Series terminal to an Enterasys Networks DFE‐Platinum module COM port (Figure 3‐10), use a UTP straight‐through cable with RJ45 connectors and an RJ45‐to‐DB25 female adapter, and proceed as follows: Connect the RJ45 connector at one end of the UTP straight‐through cable to the COM port on the Enterasys Networks module. Plug the RJ45 connector at the other end of the UTP straight‐through cable into the RJ45‐to‐ DB25 female adapter. Connect the RJ45‐to‐DB25 adapter to the port labeled COMM on the VT terminal. Turn on the terminal and access the Setup Directory. Set the following parameters on your terminal: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Local Management password screen will display. Refer to the Enterasys Matrix DFE‐Platinum Series Configuration Guide for further information. Figure 3-10 Connecting a VT Series Terminal... -
Page 39: Connecting To A Modem
Connecting to Modem Connecting to a Modem To connect a modem to an Enterasys straight‐through cable with RJ45 connectors and an RJ45‐to‐DB25 male adapter, and proceed as follows: Connect the RJ45 connector at one end of the UTP straight‐through cable to the COM port of the module. Plug the RJ45 connector at the other end of the UTP straight‐through cable into the RJ45‐to‐ DB25 modem adapter. Connect the RJ45‐to‐DB25 adapter to the communications port on the modem. Turn on the modem. With a PC connected to a remote modem, you can configure the switch remotely. To accomplish this, you must configure your PC VT emulation package with the following parameters. Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Local Management password screen will display. Refer to the Enterasys Matrix DFE‐Platinum Series Configuration Guide for further information. Figure 3-11 Connecting to a Modem Å 1 UTP straight-through cable with RJ45 connectors... -
Page 40: Adapter Wiring And Signal Assignments
Connecting to COM Port for Local Management Adapter Wiring and Signal Assignments RJ45 RJ45 3-16 Installation COM Port Adapter Wiring and Signal Diagram Conductor Blue Green Orange Yellow VT Series Port Adapter Wiring and Signal Diagram DB25 Conductor Blue Yellow Green Orange Pin Out Descriptions... -
Page 41: Completing The Installation
Only access; rw for Read-Write access; and admin for super-user access to all modifiable parameters. The default password is set to blank (press Enter). For information on changing these default passwords, refer to Chapter 3 in the Enterasys Matrix DFE-Platinum Series Configuration Guide... -
Page 42: Dfe Startup Screen Example (Matrix N7 Chassis)
Command Line Interface Enterasys Networks, Inc. 50 Minuteman Rd. Andover, MA 01810-1008 U.S.A. Phone: E-mail: support@enterasys.com WWW: (c) Copyright Enterasys Networks, Inc. 2003 Chassis Serial Number: Chassis Firmware Revision: xx.xx.xx Matrix N7(su)-> 3-18 Installation 3‐12. The startup screen, Figure +1 978 684 1000 http://www.enterasys.com... -
Page 43: Completing The Installation Of A Dfe-Platinum Module In An Existing System
For information on the set password and set system login commands, refer to Chapter 3 in the Enterasys Matrix DFE-Platinum Series Configuration Guide The DFE module is now ready to be configured. For information about setting the IP address and ... - Page 44 Completing the Installation Pin Out Descriptions 3-20 Installation...
-
Page 45: Chapter 4: Troubleshooting
This chapter provides information concerning the following: For information about... Using LANVIEW Troubleshooting Checklist Overview of DFE-Platinum Module Shutdown Procedure Recommended Shutdown Procedure Using OFFLINE/RESET Switch Last Resort Shutdown Procedure Using OFFLINE/RESET Switch Unless otherwise noted, the following information applies to all DFE modules. Using LANVIEW The modules use a built‐in visual diagnostic and status monitoring system called LANVIEW. The LANVIEW LEDs (Figure network problems. About the Management (MGMT) LED The MGMT LED (shown in Figure Module to control the management functions for all DFE modules in the chassis. The Management ... -
Page 46: Lanview Leds
Using LANVIEW Figure 4-1 LANVIEW LEDs 1 MGMT LED Table 4‐1 describes the LED indications and provides recommended actions as appropriate. The terms flashing, blinking, and solid used in • Flashing indicates an LED is flashing randomly. • Blinking indicates an LED is flashing at a steady rate (approximately 50% on, 50% off). •... - Page 47 None. Contact Enterasys Networks for technical support. If it is known that the port should be active and is not, contact Enterasys Networks for technical support. None. None, unless there is a high rate of activity. In this case, check for network configuration problems or a defective device.
-
Page 48: Troubleshooting Checklist
Refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for the IP address assignment procedure. Port is disabled. Enable port. Refer to the Enterasys Matrix DFE- Platinum Series Configuration Guide for instructions to enable/disable ports. Host Port policy and/or Verify that a management VLAN exists and that it is management VLAN is associated with the Host Port. - Page 49 Recommended Action Reenter the lost parameters as necessary. Refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for the instructions to configure the device. If the problem continues, contact Enterasys Networks for technical support. DFE-Platinum Series Hardware Installation Guide 4-5...
-
Page 50: Overview Of Dfe-Platinum Module Shutdown Procedure
The DFE module interdependent and operate under a single IP address as a single, distributed switch system (hardware, databases, and persistent storage). In this operating environment, the DFE module must shut down in an orderly fashion to ensure that the other modules in the system and other devices on the network are notified of the impending change. The devices can then make intelligent decisions and stabilize the network before the change is made; thereby increasing network availability. You can shut down a DFE module in an operating system using the in Figure 4‐2. There are two procedures to shut down a DFE module. • “Recommended Shutdown Procedure Using OFFLINE/RESET Switch” (page 4‐7) • “Last Resort Shutdown Procedure Using OFFLINE/RESET Switch” (page 4‐7) Figure 4-2 OFFLINE/RESET Switch 1 OFFLINE/RESET switch (in similar location on all DFE modules) 4-6 Troubleshooting installed in a Matrix E7, Matrix N3, Matrix N5, or Matrix N7 chassis are OFFLINE/RESET switch À shown ... -
Page 51: Recommended Shutdown Procedure Using Offline/Reset Switch
Note: The only safe time to pull a alternately flashing amber/off. Otherwise, system operation will be interrupted. Last Resort Shutdown Procedure Using OFFLINE/RESET Switch Caution: This method of shutting down a DFE module is not recommended except as a last resort, because all processes currently running on the module will be interrupted resulting in loss of frames. - Page 52 Overview of DFE-Platinum Module Shutdown Procedure 4-8 Troubleshooting...
-
Page 53: Appendix A: Specifications
This appendix provides information about the following: For information about... DFE-Platinum Module Specifications COM Port Pinout Assignments Regulatory Compliance Enterasys Networks reserves the right to change the specifications at any time without notice. DFE-Platinum Module Specifications Table A‐1 provides the I/O ports, processors and memory, physical, and environmental module specifications for the 7G4202‐72 and 7G4282‐49. Unless noted differently, the specifications apply to both DFE modules. Table A-1 Specifications Item 7G4202-72 Ports Ports 1 through 72 7G4282-49 Ports Ports 1 through 48 Option Slot... -
Page 54: Com Port Pinout Assignments
Net: 4.10 kg (9.0 lb) (one module without packaging) For the MTBF hours for these products, refer to the MTBF web site at http://www.enterasys.com/support/mtbf/ 5°C to 40°C (41°F to 104°F) -30°C to 73°C (-22°F to 164°F) 5% to 90% (non-condensing) -
Page 55: Regulatory Compliance
Regulatory Compliance The 7G4202‐72 and 7G4282‐49 meet the safety and electromagnetic compatibility (EMC) requirements listed in Table Table A-3 Compliance Standards Regulatory Compliance Safety Electromagnetic Compatibility (EMC) A‐3: Standards UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000-3-2, EN 61000-3-3, EN 55024, AS/NZS CISPR 22, VCCI V-3.. - Page 56 Regulatory Compliance A-4 Specifications...
-
Page 57: Appendix B: Mode Switch Bank Settings And Optional Installations
Caution: Read the appropriate sections to be fully aware of the consequences when changing switch settings. Only qualified personnel should change switch settings. Precaución: Si desea modificar la configuración del interruptor, lea las secciones correspondientes para saber cuál será el resultado de hacerlo. -
Page 58: Memory Locations And Replacement Procedures
Switch 8 – Clear Admin Password. Changing the position of this switch clears the admin password, and restores the factory default password on the next power‐up of the module. Once the module resets, you can either use the factory default settings or reenter your own password. Note: Do not change the position of Switch 8 unless it is necessary to reset the admin password to its factory default setting. Figure B-1 Mode Switch Location on 7G4202-72 and 7G4282-49 1 Mode switch pack is in the same location on both DFE-Platinum modules (7G4202-72 shown) Memory Locations and Replacement Procedures In the event that the Dual In‐Line Memory Module (DIMM) or DRAM Single In‐line Memory ... -
Page 59: Location Of Dram Simm And Dimm Memory Modules
Location of DRAM SIMM and DIMM Memory Modules Figure B‐2 and Figure B‐3 show the locations of the DRAM SIMM and DIMM on the each main board of the 7G4202‐72 and the 7G4282‐49, respectively. Figure B-2 Memory Module Locations on the 7G4202-72 DIMM 1. This is not considered a field replaceable unit on the 7G4202-72. Figure B-3 Memory Module Locations on the 7G4282-49 1 DIMM Memory Locations and Replacement Procedures 2 DRAM SIMM... -
Page 60: Dimm Replacement Procedure (7G4282-49 Only
DIMM Replacement Procedure (7G4282-49 only) Note: The following DIMM replacement instructions apply to the 7G4282-49 only. The DIMM is not considered a field replaceable part on the 7G4202-72. Contact Enterasys Networks support if this part fails and needs a replacement. -
Page 61: Removing The Existing Dimm From 7G4282-49
Figure B-5 Removing the Existing DIMM from 7G4282-49 1 Connector arms Rotate the DRAM SIMM upwards, then remove it from the connector fingers. Installing the DIMM on 7G4282-49 Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic equipment. Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precauciones de seguridad para evitar descargas de electricidad estática. -
Page 62: Dram Simm Replacement Procedure For 7G4202-72 Or 7G4282-49
Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precauciones de seguridad para evitar descargas de electricidad estática. To install a DRAM SIMM, refer to Figure Push the connector arms away from the DRAM SIMM enough to insert the DRAM SIMM into the connector contacts. Insert the DRAM SIMM straight down between the connector contacts enough for the tabs on the connector arms to align with the two DRAM SIMM alignment notches. Push the DRAM SIMM down into the connector contacts. Then rotate the two connector arms toward the DRAM SIMM to lock it into place. B-6 Mode Switch Bank Settings and Optional Installations Á À Â 2 DRAM SIMM Connector contacts B‐8 and proceed as follows: B‐2. B‐7, enough to ... -
Page 63: Installing The Dram Simm On 7G4202-72 Or 7G4282-49
Figure B-8 Installing the DRAM SIMM on 7G4202-72 or 7G4282-49 Ã À 1 Connector arms 2 DRAM SIMM Memory Locations and Replacement Procedures Á Ã À Â 3 Connector contacts 4 Alignment notches (2) DFE-Platinum Series Hardware Installation Guide B-7... - Page 64 Memory Locations and Replacement Procedures B-8 Mode Switch Bank Settings and Optional Installations...
-
Page 65: Index
Required tools Index Safety requirements SIMMs installing DRAM location Specifications Platinum DFE module Standards compatibility Technical support contatacting Enterasys for xiii Transmit LEDs viewing of Troubleshooting checklist for Unpacking the module User Personalized Networks (UPN) See Secure Networks Policy Support. - Page 66 Index-2...
