- Page 1 Enterasys Matrix ® DFE-Platinum Series Hardware Installation Guide 7H4202-72 P/N 9033929-03...
- Page 3 Part Number: 9033929‐03 July 2008 ENTERASYS NETWORKS, ENTERASYS MATRIX, LANVIEW, MATRIX, ENTERASYS NETSIGHT, WEBVIEW, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and other countries. For a complete list of Enterasys trademarks, see http://www.enterasys.com/company/trademarks.aspx.
-
Page 4: Regulatory Compliance Information
Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia de radio en cuyo caso puede ser requerido tomar medidas adecuadas. Klasse A ITE Anmerkung WARNHINWEIS: Dieses Produkt zählt zur Klasse A ( Industriebereich ). In Wohnbereichen kann es hierdurch zu Funkstörungen kommen, daher sollten angemessene Vorkehrungen zum Schutz getroffen werden. Product Safety This product complies with the following: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. Seguridad del Producto El producto de Enterasys cumple con lo siguiente: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. Produktsicherheit Dieses Produkt entspricht den folgenden Richtlinien: UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. ... -
Page 5: Hazardous Substances
This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 2004/108/EC, EN 55022, EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität ( EMC ) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. This product complies with the requirements of European Directive, 2002/95/EC, Restriction of Hazardous Substances (RoHS) in Electrical and Electronic Equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic equipment (WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and that this product was placed on the European market after August 13, 2005, the date of enforcement for Directive 2002/96/EC. When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/support/ Electromagnetic Compatibility (EMC) Compatibilidad Electromágnetica (EMC) - Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
- Page 7 VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
-
Page 8: Safety Information
Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter. Application of Council Directive(s): 2004/108/EC European Representative Address: Enterasys Networks, Ltd. Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC Equipment Type/Environment: Networking Equipment, for use in a Commercial Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. Safety Information Class 1 Laser Transceivers Declaration of Conformity 2006/95/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England EN 55022 EN 61000‐3‐2 EN 61000‐3‐3 EN 55024 EC Directive 2006/95/EC EN 60950 EN 60825... - Page 9 ENTERASYS NETWORKS, INC. FIRMWARE LICENSE AGREEMENT BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program ...
- Page 10 APPLICABLE LAW. This Agreement shall be interpreted and governed under the laws and in the state and federal courts of the Commonwealth of Massachusetts without regard to its conflicts of laws provisions. You accept the personal jurisdiction and venue of the Commonwealth of Massachusetts courts. None of the 1980 United Nations Convention on the Limitation Period in the International Sale of Goods, and the Uniform Computer Information Transactions Act shall apply to this Agreement. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain technical products to certain countries, unless a license to export the product is obtained from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S. Export Administration Regulations, You agree that You are a civil end user of the Program and agree that You will use the Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Section 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Cambodia, Cuba, Georgia, Iraq, Kazakhstan, Laos, Libya, Macau, Moldova, Mongolia, North Korea, the People’s Republic of China, Russia, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be designated by the United States Government), (ii) export to Country Groups D:1 or E:2 (as defined herein) the direct product of the Program or the technology, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List, or (iii) if the direct product of the technology is a complete plant or any major component of a plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section 52.227‐19 (a) through (d) of the Commercial Computer Software‐Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Program is considered commercial computer software in accordance with DFARS section 227.7202‐3 and its successors, and use, duplication, or disclosure by the U.S. Government is subject to restrictions set forth herein. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES EXPRESSLY PROVIDED TO YOU IN WRITING BY ENTERASYS, ENTERASYS DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON‐INFRINGEMENT WITH RESPECT TO THE PROGRAM. IF IMPLIED WARRANTIES MAY NOT BE DISCLAIMED BY APPLICABLE LAW, THEN ANY IMPLIED WARRANTIES ARE LIMITED IN DURATION TO THIRTY (30) DAYS AFTER DELIVERY OF THE PROGRAM TO ...
- Page 11 OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion. 13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid, illegal or unenforceable, the validity, legality and enforceability of any of the remaining provisions shall not in any way be affected or impaired thereby, and that provision shall be reformed, construed and enforced to the maximum extent permissible. Any such invalidity, illegality, or unenforceability in any jurisdiction shall not invalidate or render illegal or unenforceable such provision in any other jurisdiction. 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program.
-
Page 13: Table Of Contents
Overview of DFE-Platinum Series Capabilities ...1-1 DFE-Platinum Module ...1-2 Connectivity ...1-4 Management ...1-4 Switch Configuration Using WebView ...1-4 Switch Configuration Using CLI Commands ...1-4 Standards Compatibility ...1-4 LANVIEW Diagnostic LEDs ...1-4 Chapter 2: Network Requirements 10BASE-T Network ...2-1 100BASE-TX Network ...2-2 Chapter 3: Installation Unpacking the DFE-Platinum Module ...3-2... - Page 14 Using LANVIEW ...4-1 Troubleshooting Checklist ...4-5 Overview of DFE-Platinum Module Shutdown Procedure ...4-7 Recommended Shutdown Procedure Using OFFLINE/RESET Switch ...4-8 Last Resort Shutdown Procedure Using OFFLINE/RESET Switch ...4-8 Appendix A: Specifications DFE-Platinum Module Specifications ... A-1 COM Port Pinout Assignments ... A-2 Regulatory Compliance ...
-
Page 15: About This Guide
This guide provides an overview, installation and troubleshooting instructions, and specifications for the Enterasys Matrix DFE‐Platinum 7H4202‐72. For information about the CLI (Command Line Interface) set of commands used to configure and manage the DFE‐Platinum module, refer to the Enterasys Matrix DFE‐Platinum Series Configuration Guide. Note: In this guide, DFE-Platinum module, unless otherwise noted, refers to the 7H4202-72. Depending on the firmware version used in the DFE-Platinum module, some features described in this document may not be supported. Refer to the Release Notes shipped with the DFE-Platinum module to determine which features are supported. -
Page 16: How To Use This Guide
Troubleshooting installation problems and diagnosing network/operational problems using the LANVIEW LEDs Specifications, environmental requirements, and physical properties of the DFE-Platinum module Instructions to set the mode switches when necessary Related Documents The manuals listed below can be obtained from the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the following site: http://www.enterasys.com/support/manuals • Enterasys Matrix DFE‐Platinum Series Configuration Guide provides information on how to use the Command Line Interface to set up and manage the DFE‐Platinum modules. • Cabling Guide provides information on dB loss and cable specifications. Unlike the Enterasys Matrix DFE‐Platinum Series Configuration Guide, the Cabling Guide is not listed alphabetically on the web site. Instead, it is listed under the Overview Guides link. -
Page 17: Conventions Used In This Guide
Conventions Used in This Guide The following conventions are used in this guide: blue type Indicates a hypertext link. When reading this document online, click the text in blue to go to the referenced figure, table, or section. Note: Calls the reader’s attention to any item of information that may be of special importance. -
Page 18: Getting Help
• The device history (for example, have you returned the device before, is this a recurring problem) • Any previous Return Material Authorization (RMA) numbers xvi About This Guide www.enterasys.com/services/support/ 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/services/support/contact/ support@enterasys.com To expedite your message, type [SWITCHING] in the subject line. -
Page 19: Chapter 1: Introduction
This chapter provides an overview of the DFE‐Platinum series modules capabilities, and introduces the 7H4202‐72 DFE‐Platinum module. Overview of DFE-Platinum Series Capabilities The Platinum Distributed Forwarding Engine (DFE) is Enterasys Networks’ next generation of enterprise modules for the Matrix N‐Series and Matrix E7 switches. These DFE modules deliver high performance and flexibility to ensure comprehensive switching, routing, Quality of Service, security, and traffic containment. Key features include: • Superior performance and capacity to support more high‐bandwidth and latency sensitive applications • 10/100/1000 Base‐TX and 10 Gigabit Ethernet connectivity • Integrated Services Design that reduces the number/type of modules required, simplifies network design, and lowers entry cost • Port‐ and User‐Based Policy and Multilayer Packet Classification that provides granular control and security for business‐critical applications • High‐availability services with stateful failover for services and management • Self‐learning configuration modules with increased reliability and fault tolerance that reduces configuration time and maximizes uptime • Network‐wide configuration, change, and inventory management that is easier to install, troubleshoot, and maintain • Reduced support and maintenance costs, and decreased configuration time • Support for a variety of converged applications including VoIP with Power‐over‐ Ethernet Introduction DFE-Platinum Series Hardware Installation Guide 1-1... -
Page 20: Dfe-Platinum Module
DFE-Platinum Module DFE-Platinum Module This section provides an overview of the 7H4202‐72 DFE‐Platinum module shown in Figure 1‐1. For information about the 7H4202‐72 features and how to configure them, refer to the Enterasys Matrix™ DFE‐Platinum Series Configuration Guide. 7H4202-72 The 7H4202‐72 DFE‐Platinum module has 72, 10BASE‐T/100BASE‐TX compliant ports, via fixed front panel RJ45 connectors. The 7H4202‐72 can be installed in a Matrix E7, Matrix N7, or Matrix N3 chassis. Each of the fixed front panel ports can operate in either half‐duplex or full‐duplex mode of operation. The duplex mode can be determined by either auto‐negotiation or manual configuration. The DFE‐Platinum module ports can be configured to control traffic by limiting the rate of traffic accepted into the module and prioritizing traffic to expedite the flow of higher priority traffic through the module in a secure manor. The DFE‐Platinum module receives power and backplane connectivity when it is inserted into the Matrix E7, Matrix N7, or Matrix N3 chassis. 1-2 Introduction... -
Page 21: 7H4202-72 Dfe-Platinum Module
Figure 1-1 7H4202-72 DFE-Platinum Module 1 OFFLINE/RESET switch 2 RJ45 COM (Console Port) 3 CPU LED 4 MGMT LED 5 Group 3, 20 Ports, 10/100 Mbps, via RJ45s À Á Â Ã Ä È Å Æ Ç 6 GROUP LEDs... -
Page 22: Connectivity
Connectivity Connectivity The 7H4202‐72 can support up to 72, 10BASE‐T/100BASE‐TX switched ports connected through 72 fixed front panel connectors. Management Management of the module can be either in‐band or out‐of‐band. In‐band remote management is possible using Telnet, Enterasys Networks’ NetSight application, or WebView™ application. Out‐of‐band management is provided through the RJ45 COM (Communication) port on the front panel using a VT100 terminal or a VT100 terminal emulator. Switch Configuration Using WebView Enterasys Networks’ HTTP‐based Web management application (WebView) is an intuitive web tool for simple management tasks. Switch Configuration Using CLI Commands The CLI commands enable you to perform more complete switch configuration management tasks. For CLI command set information and how to configure the module, refer to the Enterasys Matrix™ DFE‐Platinum Series Configuration Guide. Standards Compatibility The DFE‐Platinum modules are fully compliant with the IEEE 802.3‐2002, 802.3ae‐2002, 802.1D‐1998, and 802.1Q‐1998 standards. The DFE‐Platinum module provides IEEE 802.1D‐1998 Spanning Tree Algorithm (STA) support to enhance the overall reliability of the network and protect against “loop” conditions. LANVIEW Diagnostic LEDs LANVIEW diagnostic LEDs serve as an important troubleshooting aid by providing an easy way to observe the status of individual ports and overall network operations. 1-4 Introduction ®... -
Page 23: Chapter 2: Network Requirements
10BASE-T Network 100BASE-TX Network The network installation must meet the requirements to ensure satisfactory performance of this equipment. Failure to do so will produce poor network performance. Note: The Enterasys Matrix™ DFE-Platinum Series Configuration Guide and the Cabling Guide referred to in the following sections can be found on the Enterasys Networks World Wide Web site: Refer to 10BASE-T Network When connecting a 10BASE‐T segment to any of the module fixed front panel ports of the ... -
Page 24: 100Base-Tx Network
100BASE-TX Network 100BASE-TX Network Fixed front panel ports of the 7H4202‐72 provide a connection that supports Category 5 UTP cabling. The device at the other end of the twisted pair segment must meet IEEE 802.3‐2002 100BASE‐TX Fast Ethernet network requirements for the devices to operate at 100 Mbps. Refer to the Cabling Guide for details. Note: The fixed ports of the module support Category 5 UTP cabling with an impedance between 85 and 111 ohms for 100 Mbps operation. The module is capable of operating at either 10 or 100 Mbps. The module automatically senses the speed of the other device and adjusts its speed accordingly. -
Page 25: Important Notice
Electrical Hazard: Only qualified personnel should perform installation procedures. Riesgo Eléctrico: Solamente personal calificado debe realizar procedimientos de instalacion. Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Read the Release Notes shipped with the DFE-Platinum module to check for any exceptions to the supported features and operation documented in this guide. -
Page 26: Unpacking The Dfe-Platinum Module
Note: For more information about the 7H4382-25, 7H4382-49, or 7H4383-49, refer to the Enterasys Matrix DFE-Platinum 7H4382-25 Installation Guide (9033912-00 or later) or to the Enterasys Matrix DFE-Platinum Series (7H4382-49, 7H4383-49, 7G4270-12, 7G4202-30, 7H4203-72) Installation Guide (9033835-05 or later). For instructions to view... -
Page 27: Module Placement And Rules
The FTM bridging modules have connections to both FTM1 and FTM2 backplanes, which enables them to switch frames between the two backplanes and all modules in the 6C107 chassis. However, the older first (6x1xx), second (6x2xx), and third (6x3xx) generation modules are still managed using their own Local Management and are not subject to management by the DFE‐Platinum module management entity. The Matrix N3 (7C103) and Matrix N7 (7C107) chassis have only FTM2 connections to support DFE‐Platinum modules or DFE‐Gold modules (not discussed in this book). Note: The Matrix N3 (7C103) and Matrix N7 (7C107) chassis will support either DFE-Platinum modules or DFE-Gold modules, but not in the same chassis. Module Placement and Rules Note: The following module placement rules apply to the DFE-Platinum series modules only. -
Page 28: Examples, Module Placement In Matrix E7 Chassis
Backplane Connections and Installation Rules Figure 3-1 Examples, Module Placement in Matrix E7 Chassis Example 1 (Figure Shows the chassis fully populated with DFE‐Platinum modules (7x4xxx). These modules communicate with each other via the FTM2 chassis backplane and act as a single switching entity with one IP address. The DFE‐Platinum modules are configured using a Command Line Interface set of commands. Rule: DFE‐Platinum modules can be installed in any available chassis slot in the Matrix E7 chassis. Example 2 (Figure Shows the chassis fully populated with third generation modules (6x3xx). These modules can also be installed in any available chassis slot in the Matrix E7 chassis, but operate as individual modules with separate IP addresses. Each module is configured using Local Management. Rule: The 6x3xx modules can be installed in any available chassis slot in the Matrix E7 chassis. Example 3 (Figure Shows chassis slots 1 through 5 populated with first and second generation modules (6x1xx and 6x2xx). If a 6x1xx or 6x2xx series module is installed in slot 6 or 7, it will operate in standalone mode (no backplane connectivity). Like the 6x3xx modules, the 6x1xx and 6x2xx modules operate as individual modules with separate IP addresses, and each one is configured using Local Management. Rule: The 6x1xx and 6x2xx modules can communicate with each other when they are ... - Page 29 Example 4 (Figure 3-1, Shows chassis slots 1 through 5 populated with a mix of 6x1xx, 6x2xx, and 6x3xx modules and only third generation modules in slots 6 and 7. In this module arrangement, the 6x3xx module provides a proxy bridge, which enables the 6x1xx and 6x2xx modules to communicate with 6x3xx modules in slot 6 or 7. If more than one 6x3xx module is installed in slots 1 to 5, the module in the lowest numbered slot performs the proxy function for slots 6 and 7. Therefore, if a 6x3xx module is already performing the proxy function, and another 6x3xx module is inserted into a lower numbered slot, connectivity will be temporarily interrupted, as the new board takes over the proxy function. When a 6x3xx module in a lower numbered slot is removed, and there is a 6x3xx module in a higher numbered slot, communication is not interrupted. For Local Management, plugging the Local Management connection into the 6x3xx modules will allow management connections to all 6x1xx, 6x2xx, and 6x3xx modules. If the Local Management connection is to a 6x1xx or 6x2xx board, only the modules in the first five slots will be recognized by the management client. Rule: There must be at least one 6x3xx module in slots 1 through 5 to enable communications between the 6x1xx, 6x2xx, and 6x3xx modules. Example 5 (Figure 3-1, E) Shows chassis slots 1 and 5 populated with 6x1xx, 6x2xx modules, respectively; slots 2 through 4 with DFE‐Platinum modules without a bridging module; and slots 6 and 7 with 6x3xx modules. In this module arrangement, the 6x2xx module in slot 1 and the 6x2xx module in slot 5 can only communicate with each other, because there is no 6x3xx module in one of the first five slots to serve as the proxy bridge to communicate with the 6x3xx modules in slots 6 and 7. The 7x4xxx DFE‐Platinum modules in slots 2, 3, and 4 will operate under one IP address. Since there is no bridging module (7H4382‐25, 7H4382‐49, or 7H4383‐49), the DFE‐Platinum modules will not communicate with any other modules in the chassis. Rule: In this example, there must be at least one 6x3xx series module, and a DFE‐ Platinum bridging module (7H4382‐25, 7H4382‐49, or 7H4383‐49) in slots 1 through 5 to enable communications between all generations of modules in the chassis. Example 6 (Figure 3-1, F) The module arrangement in this example is similar to the one shown in Figure described in Example 5. The only difference is that a 7H4382‐49 bridging module is ...
-
Page 30: Installing Module Into A Matrix E7 Or Matrix N7 Chassis
No corte la bolsa antiestática para sacar el módulo. Tenga en cuenta que si algún objeto cortante entra en contacto con la placa o con los componentes, éstos podrían dañarse. To install a DFE‐Platinum module into a Matrix E7 or Matrix N7 chassis, proceed directly to “Preparation” on page 3‐6 to start the installation process. Preparation Remove the blank panel covering the chassis slot in which the module will be installed. All other slots must remain covered to ensure proper airflow for cooling. (Save the blank plate in the event you need to remove the module.) Remove the module from the shipping box. (Save the box and packing materials in the event the module needs to be reshipped.) Locate the antistatic wrist strap shipped with the chassis. Attach the antistatic wrist strap to your wrist and plug the cable from the antistatic wrist strap into the ESD grounding receptacle at the upper right corner of the chassis. Remove the module from the plastic bag. (Save the bag in the event the module must be reshipped.) Observe all precautions to prevent damage from Electrostatic Discharge (ESD). Examine the module for damage. If any damage exists, DO NOT install the module. Immediately contact Enterasys Networks. Refer to “LANVIEW diagnostic LEDs serve as an important troubleshooting aid by providing an easy way to observe the status of individual ports and overall network operations.” on page 1‐4. 3-6 Installation... -
Page 31: Installation
Installation To install the module, refer to Figure Caution: To prevent damaging the backplane connectors in the following step, take care that the module slides in straight and properly engages the backplane connectors. Ensure that the top lever lines up with the desired slot number located on the front panel of the chassis. -
Page 32: Installing Module Into A Matrix E7 Or N7 Chassis (Matrix E7 Shown)
Installing Module into a Matrix E7 or Matrix N7 Chassis Figure 3-2 Installing Module into a Matrix E7 or N7 Chassis (Matrix E7 shown) Ã 1 Card guides 2 Slot number 1 3 Module card 4 Metal back panel 3-8 Installation Á... -
Page 33: Installing Module Into Matrix N3 Chassis
Align the module card between the upper and lower card guides of the desired slot and slide it into the chassis, taking care that the module slides in straight. See Caution below. Caution: Due to the amount of force needed to properly seat the module connectors into the backplane connectors, it is best to apply force to the end of the levers to insert (or eject) the module. Otherwise, damage could result to the module and chassis. Precaución: Para colocar los conectores del módulo en los conectores del panel posterior correctamente es necesario hacer bastante fuerza, por ello, para insertar o quitar el módulo, se recomienda concentrar la fuerza en el extremo de las palancas. -
Page 34: Installing Module Into Matrix N3 Chassis
Installing Module into Matrix N3 Chassis To install a DFE‐Platinum module into the Matrix N3 chassis, the installation procedure described in “Installing Module into a Matrix E7 or Matrix N7 Chassis” on page 3‐6. slot (1 through 3). Caution: When setting the locking levers to the closed position, do not try to force the locking levers to the point that they touch the face of the front panel. Forcing the locking levers to this point could damage the module and chassis. -
Page 35: Connecting To The Network
Link Aggregation to operate properly. Before connecting the cables, refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for the configuration information. For details on how to obtain manuals, refer to page xiv. -
Page 36: Connecting A Twisted Pair Segment To The 7H4202-72
Connecting to the Network Figure 3-4 Connecting a Twisted Pair Segment to the 7H4202-72 1 RJ45 connector Verify that a link exists by checking that the port RX (Receive) LED is ON (flashing amber, blinking green, or solid green). If the RX LED is OFF and the TX (Transmit) LED is not blinking amber, perform the following steps until it is on: To view the receive and transmit activity on a group of segments, press the GROUP SELECT button (refer back to Figure (Groups 1 through 3). Each time the GROUP SELECT button is pressed, the GROUP LED lights up in sequence, indicating which Group is selected. The receive and transmit activity for that group of segments is then indicated by the RX and TX LEDs for each segment. b. Verify that the cabling being used is Category 5 UTP with an impedance between 85 and 111 ohms. If the port is to operate at 100 Mbps, category 5 cabling must be used. Verify that the device at the other end of the twisted pair segment is on and properly connected to the segment. d. Verify that the RJ45 connectors on the twisted pair segment have the proper pinouts and check the cable for continuity. Typically, a crossover cable is used between hub devices. A straight‐through cable is used to connect between switches or hub devices and an end user (computer). Refer to Figure Figure 3‐6 for four‐wire RJ45 connections. Refer to Figure 3‐7 and Figure eight‐wire RJ45 connections. -
Page 37: Crossover 4-Wire Cable Rj45 Pinouts, Connections Between Hub Devices
Figure 3-5 Crossover 4-Wire Cable RJ45 Pinouts, Connections Between Hub Devices À Ã 1 RJ45 device port 2 Other device port Figure 3-6 Straight-Through 4-Wire Cable RJ45 Pinouts, Connections Between Switches and End-User Devices À Ã 1 RJ45 device port 2 Other device port Â... -
Page 38: Crossover 8-Wire Cable Rj45 Pinouts, Connections Between Hub Devices
Connecting to the Network Figure 3-7 Crossover 8-Wire Cable RJ45 Pinouts, Connections Between Hub Devices 1 RJ45 device port 2 Other device port Figure 3-8 Straight-Through 8-Wire Cable RJ45 Pinouts, Connections Between Switches and End-User Devices 1 RJ45 device port 2 Other device port 3-14 Installation À... -
Page 39: Connecting To Com Port For Local Management
Ensure that the twisted pair connection meets the dB loss and cable specifications outlined in the Cabling Guide. Refer to “Related Documents” on page xiv for information on obtaining this document. If a link is not established, contact Enterasys Networks. Refer to “LANVIEW diagnostic LEDs serve as an important troubleshooting aid by providing an easy way to observe the status of individual ports and overall network operations.” on page 1‐4 for details. Repeat steps 1 through 3 above, until all connections have been made. Connecting to COM Port for Local Management This section describes how to install a UTP straight‐through cable with RJ45 connectors and optional adapters to connect a PC, a VT series terminal, or a modem to a DFE‐Platinum module. Note: You can connect to any DFE-Platinum module in the chassis to access local management for the DFE-Platinum system. This section also provides the pinout assignments of the adapters. -
Page 40: Connecting To An Ibm Pc Or Compatible Device
Connecting to COM Port for Local Management Connecting to an IBM PC or Compatible Device To connect an IBM PC or compatible device, running the VT terminal emulation, to an Enterasys Networks module COM port (Figure Connect the RJ45 connector at one end of a UTP straight‐through cable to the communications COM port on the Enterasys Networks module. (The COM port is also known as a Console port.) Plug the RJ45 connector at the other end of the UTP straight‐through cable into an RJ45‐to‐DB9 female adapter. Connect the RJ45‐to‐DB9 female adapter to the communications port on the IBM PC. Turn on the PC and configure your VT emulation package with the following parameters: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Local Management password screen will display. Refer to the appropriate Enterasys Matrix DFE‐Platinum Series Configuration Guide for further information. 3-16 Installation 3‐9), proceed as follows:... -
Page 41: Connecting To A Vt Series Terminal
Figure 3-9 Connecting to an IBM PC or Compatible à 1 UTP straight-through cable with RJ45 connectors 2 COM (console) port Connecting to a VT Series Terminal To connect a VT Series terminal to an Enterasys Networks DFE‐Platinum module COM port (Figure 3‐10), use a UTP straight‐through cable with RJ45 connectors and an RJ45‐to‐ DB25 female adapter, and proceed as follows: Connect the RJ45 connector at one end of the UTP straight‐through cable to the COM port on the Enterasys Networks module. Plug the RJ45 connector at the other end of the UTP straight‐through cable into the RJ45‐to‐DB25 female adapter. Connect the RJ45‐to‐DB25 adapter to the port labeled COMM on the VT terminal. Turn on the terminal and access the Setup Directory. Set the following parameters on your terminal:... -
Page 42: Connecting To A Modem
Connecting to COM Port for Local Management When these parameters are set, the Local Management password screen will display. Refer to the Enterasys Matrix DFE‐Platinum Series Configuration Guide for further information. Figure 3-10 Connecting to a VT Series Terminal 1 UTP straight-through cable with RJ45 connectors 2 RJ45 COM port Connecting to a Modem To connect a modem to an Enterasys Networks DFE‐Platinum module COM port (Figure 3‐11), use a UTP straight‐through cable with RJ45 connectors and an RJ45‐to‐DB25 male adapter, and proceed as follows: Connect the RJ45 connector at one end of the UTP straight‐through cable to the COM port of the DFE module. Plug the RJ45 connector at the other end of the UTP straight‐through cable into the RJ45‐to‐DB25 male adapter. -
Page 43: Connecting To A Modem
Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Local Management password screen will display. Refer to the Enterasys Matrix DFE‐Platinum Series Configuration Guide for further information. Figure 3-11 Connecting to a Modem Ä 1 UTP straight-through cable with RJ45 connectors 2 RJ45 COM port 3 RJ45-to-DB25 male adapter Connecting to COM Port for Local Management... -
Page 44: Adapter Wiring And Signal Assignments
Connecting to COM Port for Local Management Adapter Wiring and Signal Assignments RJ45 RJ45 3-20 Installation COM Port Adapter Wiring and Signal Diagram Conductor Blue Green Orange Yellow VT Series Port Adapter Wiring and Signal Diagram DB25 Conductor Blue Yellow Green Orange Signal... -
Page 45: Completing The Installation
Completing the Installation Completing the DFE‐Platinum module installation depends on if the module is being installed in: • a new DFE‐Platinum module system (refer to “Completing the Installation” on page 3‐21), or • an established, operating DFE‐Platinum module system (refer to “Completing the Installation in an Existing System” on page 3‐23). Completing the Installation of a New System In a new system of DFE‐Platinum modules, one of the installed DFE‐Platinum modules will become the management module on chassis power up, and all DFE‐Platinum modules will automatically be set to the factory default values. A complete list of the factory default values are provided in Chapter 3 of the Enterasys Matrix DFE‐Platinum Series Configuration Guide. After installing all DFE‐Platinum modules into the host chassis and making the connections to the network, proceed to the following First‐Time Log‐In Using a Console Port Connection procedure to access the module management startup screen from your PC, terminal, or modem connection. Modem Port Adapter Wiring and Signal Diagram DB25 Conductor Blue Orange Green Yellow... - Page 46 Read-Only access; rw for Read-Write access; and admin for super-user access to all modifiable parameters. The default password is set to blank. For information on changing these default passwords, refer to Chapter 3 in the Enterasys Matrix DFE-Platinum Series Configuration Guide.
-
Page 47: Completing The Installation In An Existing System
50 Minuteman Rd. Andover, MA 01810-1008 U.S.A. Phone: +1 978 684 1000 E-mail: support@enterasys.com WWW: http://www.enterasys.com (c) Copyright Enterasys Networks, Inc. 2003 Chassis Serial Number: Chassis Firmware Revision: xx.xx.xx Matrix N7(su)-> Completing the Installation in an Existing System In an established DFE‐Platinum module system, •... - Page 48 For information on the set password and set system login commands, refer to Chapter 3 in the Enterasys Matrix DFE-Platinum Series Configuration Guide.
-
Page 49: Chapter 4: Troubleshooting
This chapter provides information concerning the following: For information about... Using LANVIEW Troubleshooting Checklist Overview of DFE-Platinum Module Shutdown Procedure Recommended Shutdown Procedure Using OFFLINE/RESET Switch Last Resort Shutdown Procedure Using OFFLINE/RESET Switch Unless otherwise noted, the following information applies to all DFE‐Platinum modules. Using LANVIEW The modules use a built‐in visual diagnostic and status monitoring system called LANVIEW. The LANVIEW LEDs (Figure status to aid in diagnosing network problems. About the Management (MGMT) LED The MGMT LED (shown in Figure Management Module to control the management functions for all DFE‐Platinum modules ... -
Page 50: Lanview Leds
Using LANVIEW Viewing the Receive and Transmit Activity On the 7H4202‐72, you can view the receive and transmit activity on the RX and TX LEDs. However, only one group of 24 ports may be viewed at a time. To view the receive and transmit activity on a group of attached segments, press the GROUP SELECT button (see Figure through 3). Each time the GROUP SELECT button is pressed, a GROUP LED lights up in sequence, indicating which group is selected. The receive and transmit activity for that group of segments is then indicated by the RX and TX LEDs for each port. Figure shows Group 3 selected and the location of Group 3, port 1 RX and TX LEDs. Figure 4-1 LANVIEW LEDs 1 MGMT LED Table 4‐1 describes the LED indications and provides recommended actions as appropriate. Note: The terms used in Flashing indicates an LED is flashing randomly. Blinking indicates an LED is flashing at a steady rate (approximately 50% on, 50% off). Solid indicates a steady LED light. -
Page 51: Lanview Leds
Recommended Action None. None. None. Ensure chassis has adequate power. None. If the LED remains amber for several minutes, contact Enterasys Networks for technical support. None. None. None. None. This state is activated when the OFFLINE/RESET switch is pressed for less than 1 second to start the process of an orderly shutdown. - Page 52 None. Contact Enterasys Networks for technical support. If it is known that the port should be active and is not, contact Enterasys Networks for technical support. None. None, unless there is a high rate of activity. In this case, check for network configuration problems or a defective device.
-
Page 53: Troubleshooting Checklist
Loss of power. Ensure that the module was installed properly according to the installation instructions in Chapter power. Incorrect terminal setup. Refer to the Enterasys Matrix DFE-Platinum Series Configuration Guide for proper setup procedures. Improper console cable Refer to pinouts. - Page 54 Configuration Guide for the instructions to set the type of STA. Review the network design and delete unnecessary loops. If the problem continues, contact Enterasys Networks for technical support. Position of Mode switch Reenter the lost parameters as necessary. Refer...
-
Page 55: Overview Of Dfe-Platinum Module Shutdown Procedure
DFE‐Platinum modules installed in a Matrix N3, Matrix N7, or Matrix E7 chassis are interdependent and operate under a single IP address as a single, distributed switch system (hardware, databases, and persistent storage). In this operating environment, the DFE‐Platinum module must shut down in an orderly fashion to ensure that the other modules in the system and other devices on the network are notified of the impending change. The device(s) can then make intelligent decisions and stabilize the network before the change is made; thereby increasing network availability. You can shut down a DFE‐Platinum module in an operating system using the OFFLINE/ RESET switch shown in Figure DFE‐Platinum module. • Recommended shutdown procedure (page 4‐8) • Last resort shutdown procedure (not recommended) (page 4‐8) Figure 4-2 1 OFFLINE/RESET switch 4‐2. There are two procedures to shut down a OFFLINE/RESET Switch Overview of DFE-Platinum Module Shutdown Procedure À DFE-Platinum Series Hardware Installation Guide 4-7... -
Page 56: Recommended Shutdown Procedure Using Offline/Reset Switch
CPU LED is alternately flashing amber/off. Otherwise, system operation will be interrupted. Last Resort Shutdown Procedure Using OFFLINE/RESET Switch Caution: This method of shutting down a DFE-Platinum module is not recommended except as a last resort, because all processes currently running on the module will be interrupted resulting in loss of frames. -
Page 57: Appendix A: Specifications
This appendix provides information about the following: For information about... DFE-Platinum Module Specifications COM Port Pinout Assignments Regulatory Compliance Enterasys Networks reserves the right to change the specifications at any time without notice. DFE-Platinum Module Specifications Table A‐1 provides the I/O ports, processors and memory, physical, and environmental module specifications for 7H4202‐72. Table A-1 7H4202-72 Specifications Item Ports Ports 1 through 72 Processors/Memory Processor Dynamic Random Access Memory (DRAM) FLASH Memory Specifications... -
Page 58: Com Port Pinout Assignments
Net: 5.45 kg (12.0 lb) (one module without packaging) For the MTBF hours for these products, refer to the MTBF web site at http://www.enterasys.com/support/matrix/mtbf.cgi search for MTBF. 5°C to 40°C (41°F to 104°F) -30°C to 73°C (-22°F to 164°F) 5% to 90% (non-condensing) A‐2 for the COM port pin assignments. -
Page 59: Regulatory Compliance
Regulatory Compliance The 7H4202‐72 meets the safety and electromagnetic compatibility (EMC) requirements listed in Table Table A-3 Compliance Standards Regulatory Compliance Safety Electromagnetic Compatibility (EMC) A‐3: Standards UL 60950, CSA C22.2 No. 60950, 2006/95/EC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. 47 CFR Parts 2 and 15, CSA C108.8, 2004/108/EC, EN 55022, EN 61000-3-2, EN 61000-3-3, EN 55024, AS/NZS CISPR 22, VCCI V-3. - Page 60 Regulatory Compliance A-4 Specifications...
-
Page 61: Appendix B: Mode Switch Bank Settings
Switches 1 through 6 – For Enterasys Networks use only. • Switch 7 – Clear Persistent Data. Changing the position of this switch clears Persistent Data on the next power‐up of the module. All user‐entered parameters, such as the IP address, module names, etc., are reset to the factory default settings. Once the module resets, you can either use the factory default settings or reenter your own parameters. • Switch 8 – Clear Admin Password. Changing the position of this switch clears the admin password, and restores the factory default password on the next power‐up of the module. Once the module resets, you can either use the factory default settings or reenter your own password. Note: Do not change the position of Switch 8 unless it is necessary to reset the admin password to its factory default setting. DFE-Platinum Series Hardware Installation Guide B-1... -
Page 62: Mode Switch Location
Figure B-1 Mode Switch Location À 1 Mode switch bank B-2 Mode Switch Bank Settings... -
Page 63: Index
Matrix E7 or N7 chassis module installation into Matrix N3 chassis module installation into Module features Network connecting to 3-11 Network Requirements list of OFFLINE/RESET switch Pinout assignments console port Pinouts crossover 3-13, 3-14 straight-through 3-13, 3-14 Index Index-1... - Page 64 Receive LEDs viewing of Regulatory Compliance Related manuals obtaining RESET button. OFFLINE/RESET switch See Safety requirements Specifications DFE-Platinum series module Standards compatibility Transmit LEDs viewing of Troubleshooting checklist for Index-2 Unpacking the module Viewing Receive and Transmit Activity WebView instructions for...
