2. Getting Started
2.1
Indoor Camera Power Supply
1. Connect the small plug of the power adapter to the Indoor Camera
and the other end to the electrical outlet.
NOTE
Only use the enclosed power adapter (5.9V DC / 1000mA).
2. Slide the ON/OFF switch to the ON position. The power LED will
light up in green.
3. Slide the ON/OFF switch to the OFF position to turn the Indoor
Camera off.
2.2
Parent Unit Battery Installation
Black Red
1. Insert the wire tab of the rechargeable battery pack into the contact
slot as shown above and fit the battery pack into the compartment.
2. Replace the battery cover over the compartment and gently tighten the
screw in a clockwise direction using a small screw driver.
12
small screw driver
