Motorola bp36s; mbp36s-2; mbp36s-3; mbp36s-4 digital video baby monitor


User's Guide
Digital Video Baby Monitor
Models: MBP36S, MBP36S-2, MBP36S-3, MBP36S-4
The features described in this User's Guide are subject to modifications without prior notice.


Table of Contents

Related Manuals for Motorola BP36S

Summary of Contents for Motorola BP36S

  • Page 1 User’s Guide Digital Video Baby Monitor Models: MBP36S, MBP36S-2, MBP36S-3, MBP36S-4 The features described in this User’s Guide are subject to modifications without prior notice.
  • Page 2 Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage.
  • Page 3: Parent Unit Menu Icons

    Overview of the Parent Unit POWER Display (LCD screen) Talk Key Up Key Press and hold to speak to your Normal Mode: Tilt Up baby Menu Mode: Up Power Adapter / Battery LED Down Key BLUE when mains adapter Normal Mode: Tilt Down power on.
  • Page 4: Overview Of Baby Unit

    Parent unit menu icons (cont’d) Volume Level Control (8 Levels) Zoom Level Control (1X, 2X) Brightness Level Control (8 Levels) Lullaby Control (5 Song Selections) Alarm Setting (6h, 4h, 2h, Off Temperature Reading (HH ºC / ºF or LL ºC / ºF) Icon &...
  • Page 5: Table Of Contents

    Table of contents 1. Safety Instructions ..................6 2. Getting Started..................8 Baby Unit Power Supply ................8 Parent Unit Battery Installation ..............8 Parent Unit Power Supply ................9 Registration (Pairing)................. 10 View Video Through TV................10 3. Using the Baby Monitor................11 Setting up....................
  • Page 6 1. Safety Instructions WARNING: Strangulation Hazard: Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 3ft (1m) away). Never use extension cords with AC Adapters. Only use the AC Adapters provided. Safety Instructions...
  • Page 7: Safety Instructions

    CAMERA SET UP & USE: ● Determine a location for the Baby Unit that will provide the best view of your baby in his/her crib. ● Place the BABY UNIT on a flat surface, such as a dresser, bureau, or shelf or mount the Unit to a wall securely using the keyhole slots under the stand.
  • Page 8 • Only use the chargers and power adapters provided. Do not use other chargers or power adapters as this may damage the device and battery pack. • Only insert a battery pack of the same type. • Do not touch the plug contacts with sharp or metal objects. CAUTION Risk of explosion if battery is replaced by an incorrect type.
  • Page 9: Getting Started

    2. Getting Started Baby Unit Power Supply 1. Connect the small plug of the power adapter to the baby unit (camera) and the other end to the electrical outlet. NOTE Only use the enclosed power adapter (5V DC / 1000mA). 2.
  • Page 10: Parent Unit Power Supply

    Parent Unit Power Supply IMPORTANT Installing the rechargeable battery pack and charging it fully before use is recommended. This will allow the unit to operate on battery in the event of a power failure. 1. Connect the small plug of the power adapter to the parent unit and the other end to the electrical outlet.
  • Page 11: Registration (Pairing)

    2. During power ON, when adapter is plugged in, the battery icon on screen's top right corner will show that the battery is charging. The Blue LED at the top left corner light up indicates adapter is plugged in. Registration (Pairing) The Baby monitor is pre-registered to your Parent Unit.
  • Page 12: Using The Baby Monitor

    3. Using the Baby Monitor Setting up • Place the baby unit in a convenient location (e.g. on a table) and point the camera lens towards the area you want to monitor. • Adjust the baby unit's head angle by rotating the camera up, down, left and right until you are satisfied with the image in the parent unit.
  • Page 13: Temperature Display (Hh °C / °F Or Ll °C / °F)

    Temperature Display (HH °C / °F or LL °C / °F) The temperature reading from the temperature sensor at the back of the Baby Unit will be displayed at the top of the LCD screen. The readings will turn RED if the temperature goes above 29°C / 84°F or below 14°C / 57°F.
  • Page 14: Parent Unit Menu Options

    4. Parent Unit Menu Options Volume 1. Press the button and the menu bar will pop up. < > 2. Press the LEFT button or button until is highlighted. 3. Press the UP button or DOWN button to select the desired volume level from level 0 ~ 8.
  • Page 15: Camera Control

    Camera Control 4.6.1 Add (pair) a camera 1. Press the button and the menu bar will pop up. < > 2. Press the LEFT button or RIGHT button until is highlighted, and del/add/view/scan menu will pop up. 3. Press the UP button or DOWN button to select , and press the OK...
  • Page 16: Delete A Camera

    4.6.4 Delete a camera 1. Press the button and the menu bar will pop up. < > 2. Press the LEFT button or RIGHT button until is highlighted, and del/add/view/scan menu will pop up. 3. Press the UP button or DOWN button to select , and press the OK button to confirm.
  • Page 17: Disposal Of The Device (Environment)

    5. Disposal of The Device (environment) At the end of the product lifecycle, you should not dispose of this product with normal household waste. Take this product to a collection point for the recycling of electrical and electronic equipment. The symbol on the product, user's guide and/or box indicates this.
  • Page 18: Cleaning

    6. Cleaning Clean the baby monitor with a slightly damp cloth or with an anti-static cloth. Never use cleaning agents or abrasive solvents. Cleaning and care • Do not clean any part of the product with thinners or other solvents and chemicals –- this may cause permanent damage to the product which is not covered by the warranty.
  • Page 19: Help

    7. Help Display No display • Try recharging or replacing the battery pack. • Reset the units. Disconnect the battery pack of the parent unit and unplug both the units' electrical power, then plug them back in. • Is the unit turned on? Press and hold the ON/OFF button on the parent unit to turn it ON.
  • Page 20 Interference Noise interference on your parent unit • Your baby and parent units may be too close. Move them farther apart. • Make sure there is at least 3 to 6 feet between the 2 units to avoid audio feedback. •...
  • Page 21: General Information

    To order a replacement battery pack, contact customer service. Consumer Products and Accessories Limited Warranty ("Warranty") Thank you for purchasing this Motorola branded product manufactured under license by Binatone Electronics International LTD ("BINATONE"). What Does this Warranty Cover? Subject to the exclusions contained below, BINATONE warrants that this Motorola branded product ("Product") or certified accessory ("Accessory") sold...
  • Page 23 (c) use of the Products or Accessories for commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of MOTOROLA or BINATONE, are excluded from coverage.
  • Page 24 Unauthorized Service or Modification. Defects or damages resulting from service, testing, adjustment, installation, maintenance, alteration, or modification in any way by someone other than MOTOROLA, BINATONE or its authorized service centres, are excluded from coverage. Altered Products. Products or Accessories with (a) serial numbers or date tags that have been removed, altered or obliterated;...
  • Page 25: Fcc And Ic Regulations

    FCC and IC regulations FCC Part l5 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 26 WARNING Changes or modifications, to this equipment not expressively approved by the party responsible for compliance could void the user’s authority to operate the equipment. The socket-outlet shall be installed near the equipment and shall be easily accessible. Industry Canada This device complies with Industry Canada licence-exempt RSS standard(s): Operation is subject to the following Two conditions:(1) this device may not cause interference, and (2) this device must accept any interference, including...
  • Page 27: Technical Specifications

    Technical Specifications Baby unit (Model: MBP36SBU) Frequency 2.4 GHz to 2.48 GHz Image sensor color CMOS 0.3M Pixels Lens f 2.5mm, F 2.8 IR LED 8 pcs Power Adapter: Ten Pao International Ltd. S006MU0500100; Input: 100-240V, 50/60HZ 300mA; Output: 5.0V, 1000mA Adapter: Kuantech Incorporated Company KSAS0050500100VUD;...
  • Page 28 Parent unit (Model: MBP36SPU) Frequency 2.4 GHz to 2.48 GHz Display 3.5" diagonal TFT LCD Display colors 16.7M color LCD Brightness control 8 steps Volume control 8 steps Power Adapter: Ten Pao International Ltd. S003IU0500060; Input: 100-240V, 50/60Hz 150mA; Output: 5.0V, 600mA Adapter: ShenZhen Frecom Electronic Co., LTD F05W-050060SPAU Input: 100-240V, 50/60Hz 150mA;...
  • Page 29 Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this product. MOTOROLA and the Stylized M Logo, are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners.
