Electrode aging
The electrodes arc begins unstability when the external environment such as the temperature and
pressure changed greatly especially moving the machine from low altitude to high altitude. When
happened, users should take an electrode aging to stabilize the electrodes arc. The machine runs 5
times of huge electrodes arc when the user selects the electrodes aging and executes it.
Note: Please according prompts to operate, do not open the cover while electrodes aging.
Shut down the power.
Software upgrade
The user should insert the USB disk with upgrade file into USB interface before software upgrade.
When the software upgrade menu is selected and pressed, the machine will automatically complete
the upgrading. After upgrading, the user should restart the machine.

Common fault and solution

Phenomenon
Tip of "Please check fiber!"
Tip of "Please reload fiber"
Tip of "Fusion failed"
Electrodes do not discharge
Tip of "Please check L(R) end face"
Tip of "Resetting push motors"
Tip of "Please close cover"
Tip of "X(Y) Image Light Error"
Tip of "(L,R)Fiber On Error position!"
Tip of "Please Gap Again!"
Note: If the above-mentioned problems still exist after handling, please contact technical support.
OPERATION MANUAL OUTDOOR MULTIFUNCTION FUSION SPLICER FUSION SPLICER 5.7
Reason
1The fiber is broken. 2 No fiber is loaded. 3 The
fiber is far away from the Electrodes more than
2mm
The fiber is not completely loaded into the V
groove.
Fusion loss is very big or Fusion broken.
The electrodes are of dirty or damaged; Or
the high-voltage board is fault.
The end face of fiber is bad, or the fiber is
polluted, or the image is unclear.
The motor exceeds the range of operation
reset to the original Position
The cover is opened
Display lamp does not light or some other
reasons
The fiber is not completely loaded into the V
groove or fiber is dirty
The gap of fiber is un-fittable.
Handle
Making the fiber image into the screen after
loading the fiber.
Press the Reset key and reload the fiber in
correct position.
Clean the V groove and fiber press foot; Check
the fusion parameter and the motor overlap to
modify
Clean or replace the electrodes
Recut fiber or clean the V groove, or increase
the max endface value of fusion para.
Reload the fiber in correct position when
resetting completed.
Operate when cover closed.
Check the mirror ,lens or the image light
Reload fiber or recut fiber.
Take a gap process first.
