Installing I/O Modules
3.11 Input Module, BSE-320
Schematics
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Screw Terminal nr.
1
2
3
4
5
6
7
8
9
10
INx-power supply
Common source to all inputs (+)
Rev. J, 2011-12-06,
Autronica Fire and Security AS
Signal
IN1
IN2
IN3
IN4
IN5
IN6
IN7
IN8
n.c.
