Internal Cable Connections

2. Internal Cable Connections

2.1 Introduction

The Fire Alarm Control Panel / Controller is customized according to each
specific delivery. Most of the internal cabling is already done (see Cable
Connections - Overview), as the control panel will always be delivered from
the factory with the mandatory internal I/O modules; Power Module BSS-310
and the Communication Module BSL-310 installed.
In addition to a description of the location of the fuses and internal cable
connections overview, this chapter covers the following:
 Connecting the Power Supply & Battery Charger
 Connecting the Battery
 Connecting the network cables (AUTROLON)
 Connections for Temperature Compensated Battery Charging

2.2 Before Connecting Cables

 Before connecting cables, make sure that the mains power is not
!
 Remove the fuses F1 and F2 on the Power Supply (refer to
POWER OFF!
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Voltage (when external battery connection is used)
connected.
illustration in the subsequent chapter).
Do not replace the fuses until commissioning of the system.
Rev. J, 2011-12-06,
Autronica Fire and Security AS
