Installing I/O Modules
3.9 Output Module, BSJ-310
Schematics
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Screw Terminal no.
1
2
3
4
5
6
7
8
9
10
Front view when mounted on rail
+ Output
Terminal 9
+24V
Output 1
Maximum 100 mA
Output 8
+ 24V
Output 9
Output 1-8
0V_BAT
Rev. J, 2011-12-06,
Autronica Fire and Security AS
Signal
OC1
OC2
OC3
OC4
OC5
OC6
OC7
OC8
24 VBAT Output
Chassis
Screw
terminal 10
Screw
terminal 1
External terminal list
