T W O - W A Y
6 - B U T T O N
T R A N S M I S S I O N
A note concerning the battery inside the transmitter:
Depending on your usage of the transmitter, the battery can last anywhere between 3 to 6 months. When the
battery is low, the transmitter will produce two beeps in a repetitive cycle. At that point you should replace
your battery with a new one. That is why we recommend that you keep a spare battery somewhere handy
such as the glove compartment.
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of
the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (EIRP) is not more than that required for successful
communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the
equipment
D1021
L C D
A U T O M A T I C / M A N U A L
R E M O T E
S T A R T E R
AS-3472TW
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle is parked
in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's responsibility
to ensure that the gearshift lever is in the NEUTRAL position and the parking
brake is engaged in order to avoid accidents upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to avoid
accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled or put
into valet mode before servicing.
2019-05-16
WARNING
- PGa -
Canada

Advertisement

Table of Contents
loading

Related Manuals for Directed AS-3472TW

Summary of Contents for Directed AS-3472TW

  • Page 1 T R A N S M I S S I O N R E M O T E S T A R T E R AS-3472TW User Guide WARNING It is the responsibility of the vehicle operator to ensure their vehicle is parked in a safe and responsible manner.

  • Page 2: Table Of Contents

    Table of Contents Government regulations ......................3 Introduction with SmartStart™ ..................3 Vehicle Presets .......................... 4 Heater ............................ 4 Windshield Wipers, Radio & Headlights ................... 4 Using the Transmitter........................ 4 LCD Transmitter basic confirmations ..................5 Basic Vehicle Operations ......................5 Backlight............................

  • Page 3: Government Regulations

    . Note: SmartStart™ must be professionally installed. For start/stop toggle and alarm notifications more information, see your nearest authorised Directed Canada dealer. With many advanced functions, this product will satisfy any one of your expectations from high-end commodity and security systems, without neglecting any standard feature commonly offered by entry-level starters.

  • Page 4: Vehicle Presets

    Vehicle Presets Heater When leaving the vehicle it is recommended to preset the accessory controls in preparation for the next remote start. Settings for the blower motor (fan), front and rear, should not be left on HIGH. It is recommended to leave the settings on LOW or MEDIUM instead. Windshield Wipers, Radio &...

  • Page 5: Lcd Transmitter Basic Confirmations

    The functions of the 1-way transmitter are as follows (optional): LOCK: Locks the doors and arms the STARTER KILL (if installed). UNLOCK: Unlocks the doors and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door Access is configured.

  • Page 6: Backlight

    Backlight Three different ways to use the backlight: Turning the backlight on for 3 seconds, press the for at least 1 second and • release. If the button is pressed and held for more than 5 seconds the backlight will stay ON •...
  • Page 7 Remote’s advanced functions and MENU Display Description Parking meter countdown This version of the countdown feature is particularly useful for keeping track of parking meter time: the user may quickly set up the countdown using the Parking Menu. The transmitter will beep once, 5min before the Parking countdown reaches 0 and beeps 6 times once the countdown expires.
  • Page 8 Within 3 seconds, press The LCD will display “Security” to confirm locking of the keypad. Press for about 1sec, to unlock the transmitter’s keypad. • Backlight color The backlight can be set to 8 different colors. COLOR to select MENU, then: Through Advanced Options, first press Choose COLOR and press Choose the desired color by pressing...

  • Page 9: Remote-Starting Your Vehicle

    Button Function: The order of LEVELS and MENU can be re-arranged using the Button Function Menu. Details on (page-18). F Button Function FBPRO FBPRO Function Button Programming Menu (15) 1 2 3 M Level 1, level 2, level 3, MENU 2 3 1 M Level 2, level 3, level 1, MENU Function Button...

  • Page 10: Remote-Starting

    interaction. to unlock the doors and shut down the engine; to shut down the engine without affecting the doors. WARNING: Engine runs until the WARNING: The vehicle is WARNING: Do not leave pre-programmed time not armed or locked down. your keys in the vehicle! expires.

  • Page 11: Remote Starter Features

    Passive mode: To arm the Starter Kill: • Press the button on the transmitter. • Let the Starter Kill arm automatically 1 minute (by default) or 3 minutes (if configured this way) after the ignition is turned OFF or once the last door is closed (if the doors are monitored). The LED on the antenna will flash quickly during the countdown preceding the activation •...

  • Page 12: Idle Mode

    Idle Mode Convenience feature: Idle Mode allows you to keep the engine running and the doors locked while you stop, for example, at a convenience store or for a short delivery. This feature allows you to let the remote starter take over control of the vehicle (i.e. no Key in the Ignition Switch) while the engine is running.

  • Page 13: Panic Mode

    To take the system out of Valet Mode Using the KEY (Ignition Valet Mode): Insert the ignition key into the ignition switch. Within 10 sec., turn the key to the IGNITION/RUN and OFF positions until parking lights flash twice. Turn the ignition OFF. The LED on the antenna will switch OFF indicating that the vehicle is now out of Valet mode.

  • Page 14: Extended Run Time

    To exit Cold Weather Mode, do any one of the following actions: • Open the hood. • Start the engine remotely. • Turn the ignition key to the IGNITION ON (RUN) position. • Or by using the remote as so: 2-way remote a.

  • Page 15: Ignition-Controlled Door Locks

    Ignition-controlled Door Locks This is an added security feature. If your Remote Car Starter was installed with the Ignition- Controlled Door Locks option, the doors will automatically lock as soon as the ignition key is turned to the IGNITION ON (RUN) position while the brakes are pressed. The remote car starter will also lock any door that was unlocked and opened (then closed) the next time the brake pedal is pressed (only when doors are monitored).

  • Page 16: Home Valet Tm " Mode

    The engine will shut down after 60 seconds. If your vehicle has a manual transmission, follow all steps of the Ready Mode routine (page-9) to activate Turbo Mode. At the last step, Press to lock the doors and have the engine shut down after 60 seconds; •...

  • Page 17: Aux 2

    AUX 2 2-way remote: If configured at installation, by default, press the Function button to select level 01 (“L-01”), then press the button to activate AUX 2. Refer to the multi-level features table for more details. 1-way remote: If configured at installation, press twice quickly on the AUX button, then once on the button while the LED is slowly flashing.

  • Page 18: Intrusion Codes Via Horn

    Intrusion Codes via horn The system monitors the following: Doors • Hood • Ignition • Note: If an intrusion has occurred the HORN will sound for a maximum of 1 minute If an intrusion has occurred and pressed, the horn provides an intrusion code corresponding to the type of intrusion that occurred.
  • Page 19 To control the Multi level features, refer to the tables below: FBPRO setting 1 *default FBPRO setting 2 FBPRO FBPRO Features Levels Features Levels setting setting Basic features Multicar operation Multicar operation Customize feature Customize feature Basic features MENU MENU MENU MENU FBPRO setting 3...

  • Page 20: Troubleshooting Transmitting Range

    Troubleshooting Transmitting Range Many factors may affect the operating range of the transmitter. Some of these are: • The condition of the battery in the transmitter. • The operating environment (for example: downtown radio-frequency noise, airports, cellular phone towers…) • Metal: any type of metal will affect operating range. This includes the metal in the car. •...
