- Page 1 A U T O M A T I C / M A N U A L T R A N S M I S S I O N R E M O T E S T A R T E R Model: ASRF-3510 User Guide Designed & Engineered in Canada Doc#: 120710 Rev:1.5 © 2012 Directed. All Rights Reserved...
- Page 2 WARNING! It is the responsibility of the vehicle operator to ensure that their vehicle is parked in a safe and responsible manner. 1. a) Manual Transmission: When leaving the vehicle, it is the user’s responsibility to ensure that the gearshift lever is in the NEUTRAL position and the parking brake is engaged in order to avoid accidents upon remote starting.
-
Page 3: Table Of Contents
Table of Contents Government regulations ..................4 Introduction with SmartStart™ ................. 5 Using the Remote Control ................. 6 Vehicle Presets ....................7 Heater ....................... 7 Windshield Wipers & Radio & Headlights ............7 Arming and disarming the starter kill (if installed) .......... 8 Remote-Starting Your Vehicle ................ -
Page 4: Government Regulations
Government regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Introduction With Smartstart
With many advanced functions, this product will satisfy any one of your expectations from high-end commodity and security systems, without neglecting any standard feature commonly offered by entry-level starters. Certain conditions apply. See your authorised Directed Canada dealer. User Guide... -
Page 6: Using The Remote Control
Using the Remote Control Your remote starter is equipped with a 5-button multi-channel remote control. It can operate two independent vehicles equipped with a remote starter (see Multi- car operation section on page-23). The functions of the transmitter are as follows: 2-way LED remote LOCK: Locks the doors... -
Page 7: Vehicle Presets
1-way companion remote (where available) LOCK: Locks the doors and arms the STARTER KILL (if installed). UNLOCK: Unlocks the doors and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door Access is configured. TRUNK: Opens the TRUNK or activates the AUX 3 output. -
Page 8: Arming And Disarming The Starter Kill (If Installed)
them to remain ON even after remote starter shut down, resulting in a dead battery. Arming and disarming the starter kill (if installed) This added security feature will prevent the vehicle from starting with the Ignition key when the starter kill is armed. If the system was installed with the starter kill option, the vehicle will not be able to start with the key unless the system has been unlocked first or put into Valet Mode (page 13). -
Page 9: Remote-Starting Your Vehicle
Active Mode: To arm the Starter Kill: Press the button on the transmitter. The parking lights will flash once. The LED on the antenna will flash slowly. If remote door locks are installed, this will also lock the doors and arm the OEM-style alarm (if configured). - Page 10 To set the system to Ready Mode: If Ready Mode is enabled by remote If Ready Mode is enabled by handbrake 1. Ensure that all the doors, hood and trunk are closed. Make sure that the gear selector is in the neutral position. 2.
-
Page 11: Remote-Starting
Remote-starting Press the button for approximately 1 second and release. The remote will beep once. The remote will confirm the remote starter’s activation by beeping 3 times. If your vehicle does not start at the first attempt, the system will shut down, wait a few seconds and try to start the engine again. -
Page 12: Remote Trunk Release
To UNLOCK your doors and DISARM the system: Press and hold the button for approx. 1 sec. The remote will beep twice to confirm unlocking of the doors. Remote Trunk Release If your system was installed with the Remote Trunk Release option, you can open your trunk by pressing the button until the remote beeps once. -
Page 13: Valet Mode
If your vehicle has a manual transmission, Idle Mode can be activated through the same routine as that used for Ready Mode (page 9); at the last step, press button to lock the doors, arm the system and leave the engine running. NEW FEATURE –... - Page 14 To put the system into Valet Mode Using the KEY (Ignition Valet Mode): Insert the ignition key into the ignition switch. Within 10 sec., cycle the ignition key to the IGNITION/RUN and OFF positions 5 times until the parking lights flash 3 times. Turn the ignition OFF.
-
Page 15: Panic Mode
If someone has attempted to remote-start the vehicle while in Valet Mode; the parking lights will turn ON, then OFF, then flash twice. Panic Mode Note: Panic mode can only be activated if the horn has been adequately configured by the installer. In an emergency situation, you can activate panic mode by pressing and holding the AUX button until the horn starts honking. -
Page 16: Extended Run Time
While the button is still lit, press and hold the button until the remote beeps once, pause, then beeps twice. Release the button. Its LED will flash quickly. To enter Cold Weather Mode (1-way remote): Rapidly press AUX twice. The remote’s LED will start flashing. Press and hold until the parking lights will flash for 2 seconds, pause, and then flash 3 times. -
Page 17: Disable/Enable Led Flashing
Note: The extended run time procedure can only be carried out once per remote start. To stop the vehicle, at any moment, simply press and release the button. Example: If your remote car starter is programmed for a run time of 3 minutes and your vehicle has been running for 2 minutes already, pressing the button will reset the counter to zero and allow the engine to run for another cycle (in this... -
Page 18: Feature Confirmation Chart
Feature Confirmation Chart Feature LOCK UNLOCK TRUNK START/STOP Beep(s) Lock 3 flashes Unlock 3 flashes Trunk 3 flashes LED ON/OFF 3 flashes 3 flashes Start 3 flashes Running 3 flashes Stop 3 flashes Entering Cold 3 flashes Weather Mode Exiting Cold 3 flashes Weather Mode Home Valet... -
Page 19: Advanced Features: Installation-Programmable Options
Advanced Features: Installation- programmable Options The remote car starter was designed with flexibility and OEM integration in mind. With its programmable options, this unit can single-handedly control nearly any electrical system in your vehicle. Caution: The programming of your system should be left to a professional. Changing any one of the settings may affect the operation of your Remote Car Starter. -
Page 20: Engine Run Time
Swap start (2-way remote): If this feature is enabled; Press and release the AUX button. button on the transmitter will light up. While it is lit, press to remote start the car. The AUX 2 output can be activated by pressing the button. -
Page 21: Home Valet Mode
Press the button; this will lock the doors, arm the OEM-style alarm (if configured) and confirm that the vehicle is in Turbo Mode. The engine will shut down after 60 seconds. f your vehicle has a manual transmission, follow all steps of the Ready Mode routine (page 9) to activate Turbo Mode. -
Page 22: Aux 1
Turn ON then OFF; then Flash twice, pause; then Flash twice again. AUX 1 Note: This 500 mA negative Aux 1 output can be used for many different applications Priority door: This great feature allows the user to unlock solely the driver’s door with a single press of the button on the transmitter, and to unlock the other doors, if desired, by pressing the... -
Page 23: Multi-Car Operation
Multi-car Operation This option allows the owner of two vehicles, both equipped with the same Remote Car Starter model, to control both systems with a single remote control. To control the second vehicle: Press TRUNK + LOCK buttons simultaneously: --------------------LOCK Press TRUNK + UNLOCK simultaneously: ---------------------------UNLOCK Press TRUNK + START/STOP simultaneously: ---------------------START Press TRUNK + START/STOP simultaneously: ---------------------STOP... -
Page 24: Intrusion Codes Via Horn
Intrusion Codes via horn The system monitors the following: Doors Hood Ignition Note: If an intrusion has occurred the HORN will sound for a maximum of 1 minute. If an intrusion has occurred and pressed, the horn provides an intrusion code corresponding to the type of intrusion that occurred. -
Page 25: Status Request When The Engine Is Not Running
The second sequence of flashes (if applicable) denotes if the vehicle is Cold Weather mode, Home valet mode, or, Valet mode. If there is no second sequence transmission, then the vehicle is none of the 3 mentioned features (Cold weather mode, Home valet mode or Valet mode). -
Page 26: Status Request When The Engine Is Running
Status Request When the Engine is Running When the vehicle doors are locked: The LED # 1 will flash 3 times to denote that the vehicle’s doors are locked. When the vehicle doors are unlocked: The LED # 2 will flash 3 times to denote that the vehicle’s doors are unlocked. And: RUN TIME Beep(s... -
Page 27: Troubleshooting Poor Transmitting Range
Troubleshooting Poor Transmitting Range Many factors may affect the operating range of the transmitter. Some of these are: The condition of the battery in the transmitter. The operating environment (for example: downtown radio-frequency noise, airports, cellular phone towers…). ... -
Page 28: Diagnostics - Parking Light Flash Table
Diagnostics – Parking Light Flash Table Parking lights Description flashes Doors locked. Trunk released. Start signal received from the remote. Runtime has expired. Doors unlocked. 2 fast Valet mode is deactivated. 2 slow Shutdown by remote. -
Page 29: Battery Replacement
Battery Replacement The transmitter is powered by two lithium cells (CRXXXX). When the transmitter stops functioning, replace the batteries. Release the lock on the battery cover. Remove the battery cover. Remove the old batteries. Install two new lithium batteries (CRXXXX) into the transmitter with the positive (+) mark toward the battery cover.
