3
English
THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT
HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN,
COMPLETE SET WITHOUT GIVING PRIOR WARNING.
APPLICATION
Line laser ADA 6D SERVOLINER GREEN is designed to check the horizontal
and vertical position of the surfaces of the elements of building structures
and also to transfer the angle of inclination of the structural part to simi-
lar parts during construction and installation works.

SPECIFICATIONS

Laser beam ...............................................4V4H1D
Light sources.............................................532nm
Laser safety class.....................................2
Accuracy ...................................................±1mm/10m
Self-leveling range...................................±3°
Working range (with detector).............radius 40/70m
Rotation/Fine adjustment ....................360°
Power supply............................................4 x AA batteries / Li-battery 3,7V
Service time ............................................ no more than 3 h with all lines ON
Mounting thread ....................................5/8» х 11
Operating temperature........................ -10°C ~ +40°C
Weight ......................................................1.2 kg
Size............................................................ Ø 135x220 mm
