Button Panel; Specifications - ADA INSTRUMENTS TOPLINER 3-360 GREEN Operating Manual

4
English
3

BUTTON PANEL

• Tilt LED (1) Indicator lights up in the intermediate position of the com-
pensator lock.
• Detector LED (2) Indicator lights up when press Detector button.
• Power LED (3) Indicator lights up when power is on. Indicator blinks when
power is low.
• Horizontal switch (H) (4)
• Detector switch (5)

SPECIFICATIONS

Laser ........................................................... 2V1H (360° laser)
Light sources ........................................... 532nm
Laser safety class ................................... Class 2, <1mW
Accuracy ................................................... ±3 mm/10 m
Self-leveling range ................................. ±4.5°
Operating range with/without receiver ...... radius 40/70m (with detector)
Rotation/Fine adjustment .................. 360 °/ ±10° (with Rotation base)
Power source .......................................... Li battery set
Operation time ....................................... Approx. 5-8 hours, if everything is on
Tripod thread .......................................... 1/4 " and 5/8 "
Operating temperature ..................... -10°C +40°C
Weight ....................................................... 0.9 kg (with Rotation base)
Size .........................................130mm ×60mm ×160 mm (with Rotation base )
*depends on illumination
