English
THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT
HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN,
COMPLETE SET WITHOUT GIVING PRIOR WARNING.
APPLICATION
ADA 400 HV Servo / ROTARY 400 HV - G Servo is a rotating laser level with
electronic compensator on servodrives. It has been designed for use in
most areas of application: laying foundations, erection of walls, partitions
and a fence, laying sloped water and sewerage lines, laying flooring, instal-
lation of suspended ceilings; laying of communications, etc.

SPECIFICATIONS

Horizontal/Vertical/plumb up
accuracy .......................................................± 0.15mm/m
Plumb down accuracy.............................± 1.5 mm/m
Self-leveling range .........................................±5°
Tilt Angle Range along Х/Y axis ................±5°
Dust/water protection ................................IP65
Recommended working range
(diameter)........................................................400 m diameter with laser detector
Laser source.....................................................635 нм (400 HV SERVO)
520 nm (400 HV-G SERVO)
Laser class........................................................II
Tripod mount ................................................ 2х5/8"
