FUNCTIONAL DESCRIPTION

4 vertical lines (V), 4 horizontal lines (H) (360º), plumb down;
The line laser is designed for operation indoor and outdoor. Use the
detector for outdoor operation with the range up to 70 m;
Electronic compensator for the faster self-leveling ±3º;
The line laser begins to blink automatically, if the deviation from
horizontal plane is more than ±3º;
Fine adjustment mechanism helps to find the object;
The compensator blocks automatically, when the power is off. It protects
the compensator form vibrations during transportation.
2
FEATURES
1. Switchboard
2. Vertical laser windows
3. Horizontal laser windows
4. Carrying belt
5. Battery cover
6. Fine adjustment switch
7. Adjustable legs
8. Down point laser
mounting thread for tripod
9. Limb 360º
10. Connector for power unit

OPERATION

1. Take out the battery lid. According the sign " + ,-", insert batteries or
rechargeable batteries to the battery socket. Cover the battery lid.
3
KEYPAD
1. Power switch On/Off
2. Power LED
3. Detector mode
4. Detector LED
5. Vertical switch (V)
6. Bubble level
7. Horizontal switch (H)
8. Leveling indication LED
9. Tilt mode
