ADA INSTRUMENTS 6D SERVOLINER GREEN Operating Manual page 6

6
English
SLOPE FINE ADJUSTMENT MODE / AUTO LEVELING SWITCH OFF
1. Switch the line laser ON. Auto leveling function is activated. Press button
(9) to switch on/off the "slant / slope fine adjustment mode".
2. It is possible to set the inclination of the horizontal plane along the axis
X and Y.
3. Press and hold button H (7) to set the tilt angle of the horizontal plane
along the axis X down. Press and hold button V(5) to set the tilt angle of the
horizontal plane up.
4. Press button (3) to set the tilt angle along the axis Y.
5. Bi-Bi sound mentions that you've reached the limit of slope position.
4
TO CHECK THE ACCURACY OF LINE LASER
Set up the line laser between two walls, the distance is 5 m.Turn
on the Line Laser and mark the point of cross laser line on the wall.
Set up the line laser 0,5-0,7m away from the wall and make, as described
above, the same masrks. If the difference {a1-b2} and {b1-b2} is less then
the value of "accuracy" (see spesifications), there is no need in calibration.
Example: when you check the accuracy of Line Laser the difference
is {a1-a2}=5 mm and {b1-b2}=7 mm. The instrument's error: {b1-b2}-
{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.
If the accuracy of Line Laser isn't corresponding with claimed accuracy,
contact the authorized service center.
5
TO CHECK THE ACCURACY OF HORIZONTAL BEAM
Choose a wall and set laser 5M away from the wall. Turn on the laser and
cross laser line is marked A on the wall.Find another point M on the hori-
zontal line, the distance is around 2.5m. Swivel the laser, and another cross
point of cross laser line is marked B.
Please note the distance of B to A should be 5m. Measure the distance
between M to cross laser lune, if the difference is over 3mm, the laser is out
of calibration, please contact with seller to calibrate the laser.
