THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT
HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN, COMPLETE
SET WITHOUT GIVING PRIOR WARNING.
APPLICATION
Line laser ADA 6D SERVOLINER / ADA 6D SERVOLINER GREEN is designed
to check the horizontal and vertical position of the surfaces of the elements
of building structures and also to transfer the angle of inclination of the
structural part to similar parts during construction and installation works.

SPECIFICATIONS

Laser beam
Light sources
Laser safety class
Accuracy
Self-leveling range
Working range
(with detector)
Rotation/Fine adjustment
Power supply
Mounting thread
Operating temperature
Weight
Size
Dust / water protection
6D SERVOLINER
4 lines (H 360º), 4 lines (V 270º), 1 dot (plumb down)
635nm
20 (70m)
Li-battery 12.6V, 2600mAh/8xAA 1,5V/charger
6D SERVOLINER GREEN
520nm
2, <1 mWt
±1mm/10m
±3°
40 (70m)
360°
5/8"
-10°C ~ +40°C
1.5 kg
Ø 152x220 mm
IP54
3
