THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT
HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN,
COMPLETE SET WITHOUT GIVING PRIOR WARNING.
APPLICATION
Line Laser ADA CUBE MINI GREEN is designed to check the horizontal and
vertical position of the surfaces of the elements of building structures and
also to transfer the angle of inclination of the structural part to similar
parts during construction and installation works.

SPECIFICATIONS

Leveling Range................................... self-leveling, ±3°
Accuracy.............................................. ±2mm/10m
Working range with /
without detector............................... 70 m / 20 m
Power Supply...................................... 2xAA Batteries Alkaline
Operation time................................... Approx. 15 hours
Laser Source, laser class.................. 1x520nm, 2
Tripod thread...................................... 1/4"
Operating temperature.................... -10°C +45°C
Dimensions.......................................... 65х65х45 mm
Weight................................................... 190g

LASER LINES

1
FEATURES
2
1. laser emitting window
2. battery cover
3. compensator switch
4. tripod mount 1/4"
3
