2.7.8 Counter Output Destination

Y ou can choose the output destination of counter 0 and counter 1 by setting
"Output Destination control bits"- CTR0OutSet and CTR1OutSet.
Table 2.15: Counter Output Destination Control Bit
CTR0OutSet
CTR1OutSet

2.7.9 Counter Interrupt Flag

The interrupt flag bit is a flag indicating the status of an interrupt. It is a
readable/writable bit. To find the status of the interrupt, you have to read
the bit value; to clear the interrupt, you have to write "1" to this bit. This bit
must first be cleared to service the next coming interrupt. Besides, you can
choose if counter 0 or counter 1 generate interrupt signal by configuring
"CTR0IntSet" and "CTR1IntSet" control bit.
Table 2.16: Counter Interrupt Flag Control Bit
CTR0F, CTR1F
Read
Write
CTR0IntSet, CTR1IntSet
0
1
UNO-3072 User Manual
0 Output destination to "CTR0Out" status bit (Default)
1 Output destination to "CTR0Out" status bit and digital output
2 (DO2) channel
0 Output destination to "CTR1Out" status bit. (Default)
1 Output destination to "CTR1Out" status bit and digital output
3 (DO3) channel
0
1
0
1
Counter Interrupt Status
No interrupt
Interrupt occur
Don't care
Clear interrupt
Counter Interrupt Control
Disable (Default)
Enable
28
