ADT-09 Series Motion Control Card
http://www.adtechcn.com
Figure below shows the way the output port of the solid-state relay is
connected. Pay attention to the polarity of the control terminal of the solid-state
relay.
LOAD
Solid state relay
-
INPUT
+
DC24V
J7
Solid state relay connection
36
