1.

Introduction

Thank you for your interest in the CY8CPROTO-064B0S3 PSoC 64 "Secure Boot" Prototyping Kit.
The PSoC 64 "Secure Boot" Prototyping Kit enables you to evaluate and develop your applications
using the PSoC 64 Line of Secured MCUs (hereafter called "PSoC 64").
PSoC 64 is a high-performance, ultra-low-power and secure MCU platform, purpose-built for IoT
applications. The
functionality. This line provides an isolated root of trust (RoT) with true attestation and provisioning
services. In addition, these MCUs deliver a pre-configured secure execution environment which
supports system software of various IoT platforms and provides secure provisioning, key storage,
and firmware management.
The CY8CPROTO-064B0S3 "Secure Boot" Prototyping Kit carries a PSoC 64 device
(CYB06445LQI-S3D42). In addition, the board features an onboard programmer/debugger
(KitProg3), a 512-Mbit Semper™ NOR flash (S25HL512T), a micro-B connector for USB device
interface, two user LEDs and one user push button. The board supports operating voltages of 1.8 V,
2.5 V and 3.3 V.
You can use ModusToolbox
software is a set of tools that enable you to integrate Cypress devices into your existing development
methodology.
If you are new to PSoC 6 MCU and ModusToolbox software, refer to the application note
- Getting Started with PSoC 6 MCU on ModusToolbox
and help you create your own design using the ModusToolbox software.
1.1

Kit Contents

The CY8CPROTO-064B0S3 package has the following contents.
3 × PSoC 64 "Secure Boot" Prototyping Board
■
USB Type-A to Micro-B cable
■
Quick Start Guide (printed on the kit package)
■
This kit contains 3 identical boards which can be provisioned with keys and policies for evaluation.
Once the kit is provisioned with a specific set of keys/policies, it will be bound to them unless re-
provisioned. The 3 boards give you the flexibility to experiment with different policies or keys. Inspect
the contents of the kit; if you find any part missing, contact your nearest Cypress sales office for help:
www.cypress.com/support.
CY8CPROTO-064B0S3 PSoC 64 "Secure Boot" Prototyping Kit Guide, Doc. # 002-29505 Rev. *B
PSoC 64 based on the PSoC 6 MCU platform, features out-of-the-box security
®
software to develop and debug your PSoC 64 projects.
to help you familiarize with the PSoC 6 MCU
ModusToolbox
AN228571
