The following document contains information on Cypress products. The document has the series
name, product name, and ordering part numbering with the prefix "MB". However, Cypress will
offer these products to new and existing customers with the series name, product name, and
ordering part number with the prefix "CY".
How to Check the Ordering Part Number
1.
Go to www.cypress.com/pcn.
2.
Enter the keyword (for example, ordering part number) in the SEARCH PCNS field and click
Apply.
3.
Click the corresponding title from the search results.
4.
Download the Affected Parts List file, which has details of all changes
For More Information
Please contact your local sales office for additional information about Cypress products and
solutions.
About Cypress
Cypress is the leader in advanced embedded system solutions for the world's most innovative
automotive, industrial, smart home appliances, consumer electronics and medical products.
Cypress' microcontrollers, analog ICs, wireless and USB-based connectivity solutions and reliable,
high-performance memories help engineers design differentiated products and get them to market
first. Cypress is committed to providing customers with the best support and development
resources on the planet enabling them to disrupt markets by creating new product categories in
record time. To learn more, go to www.cypress.com.
Advertisement
Table of Contents
Related Manuals for Cypress F2MC-16FX Series
Summary of Contents for Cypress F2MC-16FX Series
- Page 1 The following document contains information on Cypress products. The document has the series name, product name, and ordering part numbering with the prefix “MB”. However, Cypress will offer these products to new and existing customers with the series name, product name, and ordering part number with the prefix “CY”.
- Page 2 MB96650/6A0/6C0 Evaluation Board 16-bit Microcontroller F2MC-16FX Family Operation Manual Doc. No. 002-04757 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): +1 408.943.2600 www.cypress.com...
- Page 3 Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
- Page 4 Preface This document indicates directions for use about the "MB96650/6A0/6C0 evaluation board" which is the evaluation environment of MB96650/6A0/6C0 series of a F MC-16FX-16bit microcontroller *1: Referred to MCU below. Using the product safely This manual contains important information for using this product safely. Be sure to read this manual before using the product, and to follow the directions given in this manual in order to use the product correctly.
- Page 5 Preface Target products The available products with this evaluation board are shown below. Series Product Number (not included Package suffix) MB96F653R, MB96F653A MB96F655R, MB96F655A MB96650 MB96F656R MB96F657R MB96F6A5R, MB96F6A5A MB966A0 MB96F6A6R MB96F6C5R, MB96F6C5A MB966C0 MB96F6C6R Caution of the product described in this manual The following precautions apply to the product described in this manual.
- Page 6 Preface Since the product contains many electronic components, keep it away from direct sunlight, high temperature, and high humidity to prevent condensation. Do not use or store the product where it is exposed to much dust or a strong magnetic or Damage electric field for an extended period of time.
-
Page 7: Table Of Contents
Contents Overview ..................................7 Function overview ..............................8 Block diagram ..............................10 Functional Details ................................ 11 Power supply settings ............................11 Sub clock settings ..............................13 UART ch.0 select jumper ............................. 15 Mode SW settings ............................... 16 OCD (On chip debugger) interface ........................18 MB96650/6A0/6C0 Power supply select jumper.................... -
Page 8: Overview
1. Overview The MB96650/6A0/6C0 Evaluation Board provides the evaluative environment of the MB96650/6A0/6C0 series MCU. The whole of the Evaluation Board is shown below. Figure1 MB96650/6A0/6C0 Evaluation Board MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A... -
Page 9: Function Overview
Overview 1.1 Function overview This board can mount MCU (with or without socket). The location of the main function is shown as follows. Figure2 MB96650/6A0/6C0 Evaluation Board function overview RS/USB monitor xtal Main/Sub connector (solder side) Main xtal Mode socket Main/Sub monitor connector... - Page 10 Overview Table1 MB96650/6A0/6C0 Evaluation Board function list Function Specification Remarks with socket MB96F650/6A0/6C0 NQPACK120SD with socket or direct mounted HQPACK120SD Main clock 4MHz Oscillator with socket Sub clock 32.768kHz External power supply External power supply connection pin connection (DC3.3V to 5.0V) OCD debugger(MB2100-01-E) OCD connector Connection...
-
Page 11: Block Diagram
Overview 1.2 Block diagram The block diagram of this board is shown below. Figure3 MB96650/6A0/6C0 Evaluation Board Block Diagram OCD connector 4MHz Main board DC12V→ ・DC5V 5.0V 32kHz ・DC3.3V (MB96650/ 3.3V 6A0/6C0) With Socket 120 MODE SW RS ch0 Monitor USART ch0 land USART ch1... -
Page 12: Functional Details
2. Functional Details The function details of this board are shown as follows. 2.1 Power supply settings Confirm the following jumpers are closed. (J2, J4, J5, J14, J26) Figure4 Power supply jumpers location AVCC AVSS VCC_MCU AVRL AVRH MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A... - Page 13 Functional Details Table2 Power supply jumpers function Jumper Function Setting [VCC_MCU] Short-circuit (default): ON Power supply for VCC pin Open: OFF [AVRH] Short-circuit (default): ON Power supply for AVRH pin Open: OFF [AVRL] Short-circuit (default): ON Power supply for AVRL pin Open: OFF [AVCC] Short-circuit (default): ON...
-
Page 14: Sub Clock Settings
Functional Details 2.2 Sub clock settings The sub clock connection can be set as follows by J7 and J24. The settings of these jumpers are shown below. Note: A sub clock oscillator is not mounted in default. (Xtal 32.768kHz) Figure5 Sub clock setting jumpers location MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. - Page 15 Functional Details Table3 J7 setting Setting X1A connection select X1A connect to sub clock (default) X1A connect to Q220 Table4 J24 setting Setting X0A connection select X0A connect to GND X0A connect to sub clock (default) X0A connect to Q219 MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc.
-
Page 16: Uart Ch.0 Select Jumper
Functional Details 2.3 UART ch.0 select jumper The connection destination of the UART ch.0 signal can be selected by J20/J21. These jumpers location and settings are shown below. Figure6 UART ch.0 select jumper location From right to left 1, 2, 3 J20:TX , J21:RX MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. -
Page 17: Mode Sw Settings
Functional Details Table5 J20, J21 setting Setting Function select RS232C (default) 2.4 Mode SW settings The selection of the operational mode of MCU can be set by SW1 as follows. The mode switch location and settings are shown below. Figure7 Mode SW location Mode SW MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. - Page 18 Functional Details bit1:MD , bit2:DEBUG Table6 Mode SW setting (SW1) Mode SW setting MB96650/6A0/6C0 : serial writer mode MB96650/6A0/6C0 : user mode (default) MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A...
-
Page 19: Ocd (On Chip Debugger) Interface
The OCD connector location and settings are shown below. Figure8 OCD cable connect location connector Figure9 How to connect OCD-E Turn the coaxial cable appended to Cypress OCD- E(MB2100-01-E) as shown in a left chart. MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A... -
Page 20: Mb96650/6A0/6C0 Power Supply Select Jumper
Functional Details 2.6 MB96650/6A0/6C0 Power supply select jumper The MB96650/6A0/6C0 evaluation board can select the power supply connection for each device by jumper. This setup should be carried out corresponding to the device. It will become a cause of failure if this setup is not appropriate. -
Page 21: Other Jumper Settings
Functional Details Table7 Power supply select jumper setting Jumper Function Setting MB966A0/6C0 GND MB966A0/6C0 should close (other should open) MB966C0 VCC MB966C0 should close (other should open) MB966A0 DVCC MB966A0 should close (other should open) MB966A0 DVCC MB966A0 should close (other should open) MB966A0 GND MB966A0 should close (other should open) Note: Make all the jumpers open for MB96650 use. -
Page 22: Signal Monitor
Functional Details Jumper Signal VCC_MCU : MCU power supply AVCC : analog power supply AVSS : analog ground AVRH : analog reference power supply high AVRL : analog reference power supply low 2.8 Signal monitor The correspondence of the signal monitor land and the MCU pin number is shown as follows. (Q numbers are equal to MCU pin numbers.) Table9 Monitor land list Pin No. - Page 23 Functional Details Pin No. Pin No. Pin No. Pin No. MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A...
-
Page 24: Main Board Connection
Functional Details 2.9 Main board connection The connection of MCU and I/O on the main board is shown below. General-purpose LED The correspondence table for the general-purpose LED mounted on the main board and the MCU pin number is shown below. - Page 25 Functional Details NMI SW The correspondence of NMI SW mounted on the main board and the MCU pin number is shown below. Table12 NMI switch MB96650/6A0/6C0 NMI SW Parts number Pin number Pin name Reset SW The correspondence of RESET SW mounted on the main board and the MCU pin number is shown below. Table13 RESET switch MB96650/6A0/6C0 Reset SW...
-
Page 26: Power - On
3. Power - ON Basically, this board cannot turn on the power supply alone. Mount on the main board(MB2198-760-E) and use it. 3.1 FOR TEST USE ONLY, External power supply connection pin The external power supply connection pin for test use is shown as follows. (VCC = 3.3V to 5.0V) When you connect an external power supply to this pin, and you use alone this board, short-circuit J22 (DVCC) and J23 (AVCC). -
Page 27: Power-On
Power - ON 3.2 Power-ON Follow the user's manual for the Main board(MB2198-760-E). MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A... -
Page 28: Circuit Diagram
4. Circuit Diagram MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A... -
Page 29: Recycling
5. Recycling Valid for European Union Countries: According to the European WEEE-Directive and its implementation into national laws we take this device back. For disposal please send the device to the following address: Fujitsu Semiconductor Europe GmbH Warehouse / Disposal Monzastraße 4a 63225 Langen Gültig für EU-Länder:... -
Page 30: China-Rohs Regulation
6. China-RoHS regulation Compliance with Administration on the Control of Pollution Caused by Electronic Information Products of the People’s Republic of China 这标记是按照2006年2月28日公布的[电子信息产品污染控制管理办法]以及 SJ/T11364-2006[电子信息产品污染控制标识要求]在中国销售的电子信息产品的环保 使用期限。如遵守关于这产品的安全或使用上的注意，在这期限内(从生产日期起算) 不会因产品中的有害物质漏到外部、或发生突然变异，而引起环境污染和对人体或财 产的重大影响。 产品中有毒有害物质或元素的名称及含量 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷线路板... -
Page 31: Revision History
Document Title: MB96650/6A0/6C0 Evaluation Board 16-bit Microcontroller F MC-16FX Family Operation Manual Document Number: 002-04757 Revision Issue Date Origin of Description of Change Change 11/06/2012 MITK Initila release 05/02/2016 MITK Migrated to Cypress format MB96650/6A0/6C0 Evaluation Board Operation Manual, Doc. No. 002-04757 Rev. *A...
