Cypress CY8CKIT-002 Kit Manual

Psoc miniprog3 program and debug kit guide

Advertisement

Quick Links

CY8CKIT-002
®
PSoC
MiniProg3 Program and Debug
Kit Guide
Doc. # 001-59350 Rev. *I
Cypress Semiconductor
198 Champion Court
San Jose, CA 95134-1709
www.cypress.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CY8CKIT-002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cypress CY8CKIT-002

  • Page 1 CY8CKIT-002 ® PSoC MiniProg3 Program and Debug Kit Guide Doc. # 001-59350 Rev. *I Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 www.cypress.com...
  • Page 2 Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
  • Page 3: Table Of Contents

    3.1.6 Reference.......................12 Connectors ........................12 3.2.1 5-Pin Connector .....................12 3.2.2 10-Pin Connector ...................12 Power.........................13 3.3.1 Voltage Detection ...................14 A. Appendix Troubleshooting ......................15 Regulatory Compliance Information ................15 Revision History CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 4 CY8CKIT-002, as shipped from the factory, is verified to meet with requirements of CE as a Class A product. The CY8CKIT-002 boards are sensitive to electrostatic discharge (ESD).
  • Page 5: Introduction

    C Bridge for debugging I C serial connections and communicating with PSoC devices. Designed as a low-cost aid for developers to use in building their own systems around Cypress 8-bit and 32-bit PSoC devices, the MiniProg3 is included with the CY8CKIT-001 development kit and sold as a standalone kit, CY8CKIT-002.
  • Page 6: Debugging

    Click the File menu, and then click Open. Displays an equation: Times New Roman 2 + 2 = 4 Text in gray boxes Describes cautions or unique functionality of the product. CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 7: Installing Miniprog3

    The first MiniProg3 driver is automatically installed. Note: Remove the warning sticker before using MiniProg3. 3. Run PSoC Programmer: Select Start > All Programs > Cypress > PSoC Programmer <version> > PSoC Programmer <version>. When PSoC Programmer opens, the second MiniProg3 driver is automatically installed.
  • Page 8: Example Projects

    Example projects and documentation are included in the PSoC Programmer installation and are available in the PSoC Programmer installation directory: <Install_Directory>\Programmer\Examples The PSoC Programmer installation directory also includes documentation on how to use the programming interface: <Install_Directory>\Programmer\Documents CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 9: Miniprog3 Leds

    Middle - No Label (Yellow): Flashes briefly during the initial configuration of the device. If it stays ■ lit, this LED indicates that a configuration error has occurred. If this happens, disconnect the MiniProg3 from the USB port and then reconnect it. CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 10: Technical Description

    Table 3-1. Connectors / Communication Protocol Support Connector ISSP JTAG SWD and SWV 5-pin Supported Supported 10-pin Supported SWD and SWV a. SWV trace is available only with SWD debugging. CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 11: Interfaces

    Interfaces 3.1.1 ISSP In-System Serial Programming (ISSP) is a Cypress legacy interface used to program the PSoC 1 family of microcontrollers. MiniProg3 supports programming PSoC 1 devices through the 5-pin connector only. For more information about the ISSP interface, see the PSoC 1 Technical Reference Manual.
  • Page 12: Rx8

    The signal assignment is shown in Figure 3-3. When programming JTAG devices, note that MiniProg3 does not support nTRST pins. CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 13: Power

    This supply is limited to approximately 200 mA, and is protected against excess current draw. You can select 1.8 V, 2.5 V, 3.3 V, or 5 V for the power supply voltage. The 5-V CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 14: Voltage Detection

    3.3.1 Voltage Detection MiniProg3 can detect voltages in the range of 0 V to 5 V. Many of the Cypress software tools, such as PSoC Programmer and Bridge Control Panel, display this detected voltage in the application GUI. CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 15: Appendix

    (EMC) regulations. CISPR 22 - Emissions ■ EN 55022 Class A - Immunity (Europe) ■ CE - EMC Directive 2004/108/EC ■ CE Declaration of Conformity ■ CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
  • Page 16: Revision History

    Updated the title to CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide 5683812 04/07/2017 SRDS Added reference to PSoC 6 throughout the document. Added section “RX8” on page 5980454 11/30/2017 PMAD Sunset review; no content updates. CY8CKIT-002 PSoC® MiniProg3 Program and Debug Kit Guide, Doc. # 001-59350 Rev. *I...
