Chapter 1

6. Reconnect the printer cable to the back of the terminal.

7. Reconnect the power cable and run a printer test by pressing the key sequence: Function, 8,

2, Enter.

ARNING

Do not stick any sharp objects inside the printer. This can result in permanent damage to the

printer or the printer guide.

8 8IVQMREPW

Step-by-Step

To remove the printer mechanism:

1. Disconnect the power from the T77 terminal.

2. Remove the paper from the terminal, and leave the paper cover open.

3. Open the cover. Using both hands, locate the levers on the back of the T77 terminal and

push them away from you in a downward motion stopping at a 45-degree angle.

4. Carefully remove the modular printer by pulling the printer mechanism away from you.

(MWTPE]

To perform a display test, press the key sequence: Function, 8, 3, Enter. The terminal displays two

lines of 20 blocks.

If anything else displays, send the terminal to Hypercom, via an RMA, for additional testing and if

necessary, repairs.

1-24

T7 Series Troubleshooting Manual

940114-020
