[ 2 ] Set Mainboard CMOS Setup
No changes are necessary in the Mainboard CMOS Setup for resources or
drive types. Since FastTrak66 is a PCI Plug-n-Play (PnP) device, the Interrupt
and Port address resources are automatically assigned by the Mainboard's PCI
PnP BIOS.
For the FastTrak66 to be the bootable IDE controller, confirm in the main-
board's Standard CMOS Setup that the drive types (for hard disk drives) are set
for "Not Installed" or "None". Or use "Boot to SCSI" option, if this setting is
available in the motherboard's BIOS. No changes are needed for CD-ROM dri-
ves that are attached to the mainboard IDE controller.
[ 3 ] Configuring FastBuild BIOS Setup
Drives types are identified as "Not Installed" or
"Boot to SCSI" (if available)
During bootup, the FastBuild BIOS appears on the screen and displays BIOS
version information.
1) Press <Ctrl-F> to enter the FastBuild utility.
2) Press <1> for Auto Setup.
• Under the "Optimize Array for" option, choose the "Performance", "Fault
Tolerance", or "Capacity".
• For the "Typical Application Usage" option, select the appropriate setting
with the <Space> key.
See Chapter 4 for details on FastBuild Configuration Setup.
3) Press <Ctrl-Y> to save and "Yes" to save and reboot the system. NOTE: the
disk array will be seen as one physical drive by the operating system.
Pagina 11
Quick Installation
11
Main Advanced Security Exit
System Date Jan 1 1999
System Time 09:00:00
Floppy Options Press Enter
Primary IDE Master Not Installed
Primary IDE Slave Not Installed
Secondary IDE Master Not Installed
Secondary IDE Slave Not Installed
Language English (US)
Boot Options Press Enter
Video Mode EGA / VGA
Mouse Installed
Base Memory 640KB
Extended Memory 31744KB
Bios Version 1.00.00.00
