By default, the following number lists are assigned for Allowed Denied Logic for each port type:
Port Type
FXS Ports
FXO Ports
SIP Trunks
You may retain these lists or configure any other Number list from 01 to 24.
• enable Allowed-Denied Logic on the port type—FXS, FXO, SIP—on which you want to apply this feature.
• configure the numbers you want to allow and the numbers you want to restrict in the default Allowed
Number List and Denied Number List assigned to the port.
For instructions, see the following topics under Basic Settings:
"Handling of Incoming Calls"
"Handling of Incoming Calls"
"Handling of Outgoing Calls"
If you do not want to use the default Number Lists assigned to the ports, you may select a different List
Number and configure it. In which case, you must select the List Number you configured as the Allowed
Number List/Denied Number List for the port.
Black Listed Callers
The Black Listed Callers feature enables you to block incoming calls from specific numbers and addresses on the
SIP Trunks. You can apply this feature on a Source Port only.
To use this feature,
• you must configure the numbers of unwanted callers in a Number List.
Make sure you have configured the full SIP URI (for example: 12345@abc.com) of the unwanted callers in
the Blacklisted Callers Number List.
• enable the Reject Calls from Blacklisted Callers check box on the SIP Trunks on which you want to
apply this feature.
• select the Number List you configured as Black Listed Callers Number List.
For instructions, see:
Now, whenever there is an incoming call on the SIP Trunk you have applied this feature, the SETU VFXTH will
match the number with the Blacklisted Callers' Number list you have assigned. If the number matches with any of
the numbers you have blacklisted, the system will reject the call.
By default, Number List 11 is assigned as the Black Listed Callers Number List for the SIP Trunks. You may retain
this list and configure all the numbers you want to black list in this list or you may configure different number lists for
different ports and assign the lists to the respective ports.
139
Default Allowed
Default Denied
Numbers List
Numbers List
List 05 List 06
List 01 List 02
List 07 List 08
on "SIP Trunks"
on "FXO Port"
on "FXS Port"
"Handling of Incoming Calls" in "SIP Trunks" topic under Basic Settings.
