Communication Ports
4.2 PoE Ports
Note
When more than two 40km or 80km SFP+ tranceivers are installed, the maximum
temperature at which the device can operate will be reduced to 75 °C (165°F).
LEDs
Each socket features an LED that indicates its link state.
Green (Solid)
Green (Blinking)
Off
Compatible SFP Transceivers
For more information about which SFP transceivers are compatible with the
RUGGEDCOM RST2228P, as well as instructions for ordering and installation/
removal, refer to the
support.industry.siemens.com/cs/ca/en/view/109482309].
Note
Only use SFP transceivers approved by Siemens for RUGGEDCOM products. Siemens
accepts no liability as a result of performance issues related in whole or in part to
third-party components.
4.2

PoE Ports

The RUGGEDCOM RST2228P supports up to twenty-four 10/100/1000 Mbps Power
over Ethernet (PoE) ports powered by an external power supply. Each port complies
with the IEEE 802.3af and IEEE 802.3at standards and features auto-sensing and
automatic power off when cables are removed.
The total allowable power budget for all ports is 500 W. If the external power supply
is less than the PoE power demand, to prevent exceeding the power budget, port
priorities can be set via the RUGGEDCOM ROS operating system to disable low
priority ports when demand is too high. Ports can also be enabled/disabled and
placed on a power schedule to conserve power. For more information, refer to the
RUGGEDCOM ROS Configuration Manual for the RUGGEDCOM RST2228P.
For information about connecting the external power supply, refer to
External PoE Power (Page
LEDs
Each port features an LED to indicates the state of the port.
34
State
RUGGEDCOM SFP Transceiver Catalog [https://
21)".
Description
Link established
Activity
No link detected
Installation Manual, 07/2021, C79000-G8976-1403-13
"Connecting
RUGGEDCOM RST2228P
