Certification
6.1.9 Other Approvals
A copy of the Material Declaration is available online at
support.industry.siemens.com/cs/ww/en/view/109738831.
6.1.9

Other Approvals

This device meets the requirements of the following additional standards:
•
•
•
•
•
6.2

EMC and Environmental Type Tests

The RUGGEDCOM RST2228P has passed the following EMC and environmental tests.
EMC Type Test for IEC 61850-3
Note
•
•
•
IEC 61000-4-2
IEC 61000-4-3
46
IEC 61850-3
General Requirements
EN 50121-4
Railway Applications – Electromagnetic Compatibility – Emission and Immunity
of the Signaling and Telecommunications Apparatus
EN 50121-3-2
Railway applications – Electromagnetic compatibility – Part 3-2: Rolling stock –
Apparatus
EN 50155
Railway applications – Rolling stock – Electronic equipment
NEMA TS-2
Traffic Controller Assemblies with NTCIP Requirements
In the case of an all fiber port configuration, this product meets all Class 2
requirements. Otherwise, all Class 1 requirements are met for copper ports and
mixed fiber/copper ports.
If the unit contains copper ports, the IEC 61850-3 and IEEE 1613 conformance is
Class 1, during which disturbance errors may occur but recovery is automatic.
If the unit contains all fiber ports, the IEC 61850-3 and IEEE 1613 conformance is
Class 2, during which no disturbance errors will occur.
Test
ESD
Radiated RFI
Description
Enclosure Contact
Enclosure Air
Enclosure Ports
https://
Test Levels Severity Levels
± 8 kV
± 15 kV
20 V/m Note
RUGGEDCOM RST2228P
Installation Manual, 07/2021, C79000-G8976-1403-13
