Siemens SIMATIC NET RUGGEDCOM RST2228P Installation Manual page 12

•
RUGGEDCOM RST2228P
Installation Manual, 07/2021, C79000-G8976-1403-13
Option 1
Status panel, alarm LED, ACO Button, CLP port and USB console port are located
on the front panel.
5
1
2
3 4
6
Status Panel
1
ACO Button
2
CLP Port
3
USB Console Port
4
PoE Power and Failsafe Alarm Relay Terminal Block
5
Power Terminal Block
6
SFP/SFP+ Transceiver Sockets
7
Media Modules
8
Chassis Ground Terminal
9
Figure 1.1 RUGGEDCOM RST2228P (Front Panel Orientation)
7
Introduction
1.2 Description
8
9
3
