Specifications
For specifications on the available copper Ethernet ports, refer to
Port Specifications (Page
4.2

PoE Ports

The RUGGEDCOM RST916P features Power-over-Ethernet (PoE) ports (ports 1 to 10)
powered by an external power supply. Each port complies with the IEEE 802.3af, IEEE
802.3at, and IEEE 802.3bt standards.
The total allowable power budget for all ports is 420 W. If the external power supply
provides less than the PoE power demand, to prevent exceeding the power budget,
port priorities can be set via the RUGGEDCOM ROS operating system to disable low
priority ports when demand is too high. Ports can also be enabled/disabled and
placed on a power schedule to conserve power. For more information, refer to the
RUGGEDCOM ROS Configuration Manual for the RUGGEDCOM RST916P.
For information about connecting the external power supply, refer to
Power (Page
LEDs
Each PoE port features an LED that indicates the power state of the port and link
status.
Green
Green
Yellow
Yellow
—
Specifications
For specifications on the available PoE ports, refer to
(Page
4.3

SFP Transceivers

The RUGGEDCOM RST916P supports up to four Small Form-Factor Pluggable (SFP)
transceiver sockets, which are compatible with a wide array of SFP transceivers
available from Siemens.
RUGGEDCOM RST916P
Installation Manual, 04/2021, C79000-G8976-1489-01
29)".
14)".
Color
27)".
State
Solid
Blinking
Solid
Blinking
—
Communication Ports
4.2 PoE Ports
"Copper Ethernet
"Connecting
Description
Link established
Link activity
PoE supplied, link established
PoE supplied, link activity
No link detected, no power, or
port disabled
"PoE Output Specifications
