EventDOT 15 Q4

Setup Devices

In this section you can select the control mode of the device and change the name of the device.
From the dropdown menu in the Control Mode field you can select the control mode of the device. The
following options are available:
● Auto:
● Program:
● Static:
● Dimmer:
● DMX:
Note:
The name of the device in the Fixture Name field is set to 'EventDot'. You can change the name of the
device in this field.

Auto Mode

Select Auto from the dropdown menu in the Control Mode field.
Slide the Speed slider to change the speed of the auto program.
Slide the Strobe slider to add strobe effect.
Click Save to save the changes. A confirmation dialog box will pop up to confirm that the changes
are saved. The device will play continuously the built-in programs with the selected speed and
strobe frequency.
Click Ok to close the pop-up confirmation box.
Product code: 44011
In this mode you can play the built-in programs continuously, adjust the
speed and add strobe effect. See 6.8.2.1. Auto Mode on page 27 for more
information
In this mode you can play one of the 15 built-in programs: 8 color jump
programs and 7 color fade programs, adjust the speed and add strobe
effect. See 6.8.2.2. Built-in Programs on page 28 for more information
In this mode you can choose one of the static color presets. See 6.8.2.3.
Static Colors on page 29 for more information
In this mode you can adjust the LEDs intensity separately for the red, green,
blue and white colors. See 6.8.2.4. Dimming Mode on page 29 for more
information
In this mode you can configure the settings of the device and select one of
the 6 DMX personalities. See 6.8.2.5. DMX Mode on page 30 for more
information
