- Page 1 MANUAL ENGLISH Single WDP-1 Ordercode: 50756 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Single WDP-1 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Connection with the mains............................3 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Overview ..................................5 HTP (Highest Takes Precedence) ..........................6 Installation ................................... -
Page 3: Warning
Your shipment includes: • Showtec Single WDP-1 with a power cable (1 m) Remote dimming fader with a power cable (1,9 m) •... -
Page 4: Operating Determinations
The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature. If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely • (preferably in the original packing material), and return it to your Showtec dealer for service. -
Page 5: Return Procedure
Single WDP-1 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 6: Description Of The Device
Features The Showtec Single WDP-1 is a 1-channel DMX dimmer/switch with a built-in wireless DMX receiver. It is possible to mount the Single WDP-1 to any wall, truss or a fixture which makes it suitable for any location. Input voltage: 230V AC, 50Hz •... -
Page 7: Htp (Highest Takes Precedence)
DMX input. Installation Remove all packing materials from the Single WDP-1. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 8: Set Up And Operation
Fig. 03 Unlinking It is possible that, before being able to use the Single WDP-1, you will need to unlink it first. There are 2 ways of unlinking the Single WDP-1: via transmitter or via the Single WDP-1. 01) Via transmitter: Follow the instructions from your transmitter’s user manual on how to unlink the devices. -
Page 9: Control Panel
If not, the problem may be: • The XLR cable from the controller is not connected with the input of the Single WDP-1. • The controller is switched off or defective, the cable or connector is detective, or the signal wires are swapped in the input connector. -
Page 10: Main Menu Options
Single WDP-1 Main Menu Options 1. Remote control/Manual control 2. DMX Addressing (Fun1) 3. Dimmer/Switch (Fun1) 4. Dimmer Limit (Fun1) 5. WDP Control (Fun1) 6. Dimmer Preset (Fun2) 7. Full On (Fun2) 1. Remote Control/Manual Control 01) Press the MENU button until the display shows... -
Page 11: Full On (Fun2)
03) If both appear to be O.K., plug the unit in again. 04) If you are unable to determine the cause of the problem, do not open the Single WDP-1, as this may damage the unit and the warranty will become void. -
Page 12: Product Specification
Single WDP-1 Product Specification Model: Showtec Single WDP-1 Input voltage: 230V AC, 50Hz Fuse: F10L/250V Dimensions: 100 x 95 x 273 mm (LxWxH) Weight: 1,4 kg Operation Signal input: 3-pin DMX IN Signal output: 3-pin DMX OUT Output: 10A Schuko... -
Page 13: Notes
Single WDP-1 Notes Ordercode: 50756... - Page 14 Single WDP-1 Ordercode: 50756...
- Page 15 Single WDP-1 Ordercode: 50756...
- Page 16 ©2016 Showtec...
