- Page 1 MANUAL ENGLISH Stardrape White LED WhiteCloth V1 Ordercode: 40461W Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Stardrape White LED WhiteCloth Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains ............................6 Return Procedure ................................7 Claims ....................................7 Description of the device ..............................8 Overview .................................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec Stardrape White LED controller • IEC power cable (1,5 m) •... - Page 4 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Stardrape White LED WhiteCloth • The user is responsible for correct positioning and operating of the Stardrape. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. • This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to earth. - Page 6 Stardrape White LED WhiteCloth Stardrape Curtain One Stardrape – Wentex Multiple Stardrapes – Horizontal Installation Ordercode: 40461W...
-
Page 7: Connection With The Mains
Stardrape White LED WhiteCloth Multiple Stardrapes – Vertical Installation The Stardrape can be mounted to any kind of truss with hook and loop fasteners (Velcro) and/or tie- wraps/shock cords. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. -
Page 8: Return Procedure
Stardrape White LED WhiteCloth Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 9: Description Of The Device
Stardrape White LED WhiteCloth Description of the device Features The Stardrape White LED WhiteCloth is a star curtain system with high output and great effects. Curtain Light source: 360 x 5050 White LED Data connector: Fixed cable with a 5-pin female connector Curtain color: White Material: Flame retardant molton Assembly: Velcro and tie-wraps/shock cords... -
Page 10: Overview
Stardrape White LED WhiteCloth Overview Fig. 01 Ordercode: 40461W... -
Page 11: Controller
Stardrape White LED WhiteCloth Controller Fig. 02 01) IEC power connector 100-240V IN + Fuse F2AL/250V 02) Power switch ON/OFF 03) 3-pin DMX signal connector IN 04) 3-pin DMX signal connector OUT 05) 5-pin curtain connector 06) Ground/earth connection 07) 4-digit LED display + menu buttons 08) Air intake grill 09) Safety eye 10) Inclination screw... -
Page 12: Control Modes
Stardrape White LED WhiteCloth Control Modes There are 5 modes: • Built-in programs • Full Mode • Sound-controlled • Master/Slave • DMX-512 (8CH) One Stardrape (Built-in programs and Full Mode) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Plug the end of the electric mains power cord into a proper electric power supply socket. -
Page 13: Multiple Stardrapes (Dmx Control)
Stardrape White LED WhiteCloth Multiple Stardrapes (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the Stardrapes and other devices. 04) Link the units as shown in fig. -
Page 14: Fixture Linking
Stardrape White LED WhiteCloth Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 15: Control Panel
Stardrape White LED WhiteCloth The Stardrape can be operated with a controller in control mode or without the controller in stand-alone mode. Control Panel A) LED display MODE button C) ENTER button D) UP button DOWN button Fig. 05 Control Mode The fixtures are individually addressed on a data-link and connected to the controller. -
Page 16: Menu Overview
Stardrape White LED WhiteCloth Menu Overview Main Menu Options DMX-512 Mode and Master/Slave Mode Built-in programs Sound-controlled Mode Full Mode 1. DMX-512 Mode and Master/Slave Mode With this menu, you can set the DMX address. 01) Press the MODE button until the display shows 02) Press the ENTER button to open the menu. -
Page 17: Sound-Controlled Mode
Stardrape White LED WhiteCloth 08) Press the UP/DOWN buttons to increase/decrease the program speed. The adjustment range is between , from slow to fast. 3. Sound-controlled Mode With this menu, you can set Sound-controlled Mode. 01) Press the MODE button until the display shows 02) Sound-controlled Mode is now active and the device will react to the beat of the background music. -
Page 18: Maintenance
Stardrape White LED WhiteCloth Channel 6 – LED group 2 Dimmer must be set between 1-255 0-255 Gradual adjustment LED group 2, from 0-100% Channel 7 – LED group 3 Dimmer must be set between 1-255 0-255 Gradual adjustment LED group 3, from 0-100% Channel 8 –... -
Page 19: Troubleshooting
Suspect three potential problem areas as: the power supply, the LEDs, the fuse. 01) Power supply. Check if the controller is plugged into an appropriate power supply. 02) The LEDs. Return the Stardrape to your Showtec dealer. 03) The fuse. Replace the fuse. See page 17 for replacing the fuse. - Page 20 Stardrape White LED WhiteCloth Problem Probable cause(s) Solution No power to the fixture • Check if power is switched on and One or more cables are plugged in fixtures do not function at all Primary fuse blown • Replace fuse Fixtures reset The controller is not connected.
-
Page 21: Product Specifications
Stardrape White LED WhiteCloth Product Specifications Model: Showtec Stardrape White LED WhiteCloth Input Voltage: 100-240 VAC, 60/50Hz Power consumption: DMX linking: 30pcs Fuse: F2AL/250V Dimensions curtain: 3000 x 6000 mm (LxW) Weight curtain: 7,5 kg Dimensions controller: 250 x 265 x 62 mm (LxWxH) -
Page 22: Dimensions
Stardrape White LED WhiteCloth Dimensions Ordercode: 40461W... -
Page 23: Notes
Stardrape White LED WhiteCloth Notes Ordercode: 40461W... - Page 24 ©2015 Showtec...
