EventDOT 15 Q4
Turn off the first device from the power switch (14).
Connect the second device to your computer or smartphone.
Repeat steps 2–4 to connect and configure the rest of the devices.
Note:
The number of devices, that you can connect and control at the same time via Wi-Fi, depends on the
bandwidth of the router and on the total number of all connected devices.

Wi-Fi LED Indicator Statuses

The Wi-Fi LED indicator (08) has the following statuses:
● Always on:
● Flashing (100 ms): poor Wi-Fi signal
● Flashing (200 ms): connecting to router
● Flashing (500 ms): initiating Wi-Fi signal
● Off:

Supported Control Protocols

The EventDOT 15 Q4 supports DMX via Art-Net and sACN.
Art-Net is a protocol that uses TCP/IP to transfer large amount of DMX-512 data over an Ethernet network.
Art-Net 4 can support up to 32768 universes. Art-Net™ Designed by and Copyright Artistic Licence
Holdings Ltd.
sACN (streaming Architecture for Control Networks), also known as ANSI E1.31, is a protocol for sending
DMX-512 data over IP networks developed by ESTA (Entertainment Services and Technology Association).
It supports up to 63999 universes and uses multicasting.

DMX Addressing

In a setup with multiple devices, make sure that you set the DMX starting address of each device
correctly. The EventDOT 15 Q4 has 6 personalities: 1, 2, 4, 5, 6, and 9 channels.
Product code: 44011
good Wi-Fi signal
no signal or in hotspot mode (see 6.3. Hotspot Mode on page 19)
17
Fig. 18
