- Page 1 MANUAL ENGLISH Energetic Ordercode: 43165 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Energetic Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................5 Laser safety for a Class 3R Laser Product ......................... 5 Rigging .................................... 7 Connection with the mains ............................7 Return Procedure ................................8 Claims ....................................8 Description of the device .............................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Energetic ● IEC power cable (1,5 m) ●... - Page 4 Energetic Before the initial start-up, please make sure that there is no damage caused by transportation. Should there be any, consult your dealer and do not use the device. To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes contained in this manual.
- Page 5 ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Operating Determinations
Energetic Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light output and the illuminated surface must be bigger than 1 meter. - Page 7 Energetic Product Classification and Manufacturing Label Identification Laser Classification Class 3R Cooling Cooling fans and TE Cooling Laser medium Wavelength 650 nm / Red (Laser Diode) ; Output >100mW Wavelength 532 nm / Green (Laser Diode); Output >30mW Output 130mW The legal requirements for using laser entertainment products vary from country to country.
-
Page 8: Rigging
Energetic Rigging Please follow the European and national guidelines concerning rigging, trussing and all other safety issues. Do not attempt the installation yourself ! Always let the installation be carried out by an authorized dealer ! Procedure: ● If the Energetic is lowered from the ceiling or high joists, professional trussing systems have to be used. ●... -
Page 9: Return Procedure
Energetic Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.com and request an RMA prior to shipping the... -
Page 10: Description Of The Device
Energetic Description of the device Features The Energetic is a light effect with high output and great effects. It is equipped with laser, strobe and LED effects. ● Input voltage: 100-240V AC, 50/60Hz ● Power consumption: 30W ● DMX channels: 2 or 9 channels ●... -
Page 11: Frontside
Energetic Frontside Fig. 02 Mounting bracket 05) Laser Cooling fan 06) IR eye Strobe 07) Adjustment screw LEDs Backside Fig. 03 Sound sensitivity control 14) 3-pin DMX signal connector OUT Built-in Microphone 15) 3-pin DMX signal connector IN Safety eye 16) Remote control plug Ground/earth connection 17) Interlock... -
Page 12: Installation
Energetic Installation Remove all packing materials from the Energetic. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty. -
Page 13: Control Modes
Energetic Exclusion of liability Be aware that in some countries, there are additional regulations, regarding the use of laser devices. Therefore, we strongly advise you to verify your national laws with your authorities: We do not take any responsibility for eventual discrepancies, changes or adaptions regarding lawful use of laser devices. Fig. -
Page 14: Multiple Energetics (Master/Slave Control)
Energetic Multiple Energetics (Master/Slave control) 01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-p XLR cable to connect the Energetics and other devices. The pins: 1. -
Page 15: Multiple Energetics (Dmx Control)
Energetic Multiple Energetics (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the Energetics and other devices. 04) Link the units as shown in Fig. -
Page 16: Fixture Linking
Energetic Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 17: Control Panel
Energetic Control Panel DMX LED indicator LED display Slave LED indicator Auto LED indicator MODE button UP button DOWN button ENTER button Sound LED indicator Fig. 08 Control Mode The fixtures are individually addressed on a data-link and connected to the controller. The fixtures respond to the DMX signal from the controller. -
Page 18: Menu Overview
Energetic Menu Overview The Energetic will only show its version number at start-up ! Main Menu Options Auto Run Programs Sound-controlled Mode Static Color Mode Slave Mode DMX Channels / DMX Address Slave Mode System Settings Ordercode: 43165... -
Page 19: Auto Run Programs
Energetic 1. Auto Run Programs With this menu you can start several Auto Run Programs. 01) Press the Menu button until the display shows 02) Press the Enter button to open the menu. 03) Press the Up and Down buttons to choose between 7 built-in programs 04) Choose the desired built-in program and press the Enter button to confirm. -
Page 20: System Settings
Energetic 6. System Settings With this menu you can set several system functions. 01) Press the Menu button until the display shows 02) Press the Enter button to open this menu. 03) Press the Up and Down buttons to choose between 3 settings: 04) Press the Enter button to open this menu. -
Page 21: Remote Control
Energetic Remote Control Use remote control max. 5m from device. Note: buttons have no function Button Function Description On / Off Press the ON/OFF button for 2 seconds to activate the different modes except the Slave mode. Auto program mode Press the button to activate the Auto program. -
Page 22: Dmx Channels
Energetic DMX Channels 2 channels Channel 1 – Built-in Programs Not functional 10-44 LEDs/laser/strobe 45-79 LEDs/strobe 80-114 LEDs/laser 115-149 Laser/strobe 150-184 LEDs 185-219 Strobe 220-255 Laser Channel 2 – Built-in Program Speed Programs CH1 must be set between 10-255 0-250 Gradual speed adjustment, from slow to fast 251-255 Sound-controlled... - Page 23 Energetic Channel 4 – Strobe CH3 must be set between 6-255 Not functional 6-255 Strobe flash frequency, from low to high frequency Channel 5 – Motor Rotation Not functional 1-127 Motor indexing 128-255 Shake effect, from slow to fast Channel 6 – Strobe Patterns Not functional 10-19 Pattern 1, from slow to fast...
-
Page 24: Maintenance
Energetic Maintenance The Energetic requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and a soft cloth. -
Page 25: Troubleshooting
01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The laser. Return the Energetic to your Showtec dealer. 03) The LEDs and strobe LEDs. Return the Energetic to your Showtec dealer. 04) The fuse. Replace the fuse. See page 23 for replacing the fuse. - Page 26 Energetic Problem Probable cause(s) Solution No power to the fixture • Check if power is switched on and One or more cables are plugged in fixtures do not function at all Primary fuse blown. • Replace fuse. Fixtures reset The controller is not connected. •...
-
Page 27: Product Specifications
Energetic Product Specifications Model: Showtec Energetic Input voltage: 100-240V AC, 50/60Hz Power consumption: 30W (full output) DMX linking: 30 pcs Power linking @110V 30 pcs Power linking @240V 61 pcs Fuse: T1L/250V Dimensions: 260 x 190 x 188 mm (LxWxH) -
Page 28: Dimensions
Energetic Dimensions Ordercode: 43165... -
Page 29: Notes
Energetic Notes Ordercode: 43165... - Page 30 Energetic Ordercode: 43165...
- Page 31 Energetic Ordercode: 43165...
- Page 32 ©2020 Showtec...
