MANUAL
ENGLISH
Galactic Beam G40
V1
Ordercode: 51315
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GALACTIC BEAM G40 V1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SHOWTEC GALACTIC BEAM G40 V1

  • Page 1 MANUAL ENGLISH Galactic Beam G40 Ordercode: 51315 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    Galactic Beam G40 Table of contents Warning ....................................2 Safety Instructions ................................. 3 Operating Determinations ............................4 Laser safety for a Class 3B Laser Product ......................... 5 Rigging .................................... 6 Connection with the mains............................7 Return Procedure ................................7 Claims ....................................7 Description of the device ..............................
  • Page 3: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Galactic Beam G40 with IEC powercable 1,75m ● Remote plug and 2 key ●...
  • Page 4: Safety Instructions

    Galactic Beam G40 Safety Instructions Every person involved with the installation, operation and maintenance of this device has to: ● be qualified ● follow the instructions of this manual Before your initial start-up, please make sure that there is no damage caused by transportation. Should there be any, consult your dealer and do not use the device.
  • Page 5: Operating Determinations

     If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
  • Page 6: Laser Safety For A Class 3B Laser Product

    Galactic Beam G40 Laser safety for a Class 3B Laser Product CAUTION: AVOID EXPOSURE TO BEAM: Avoid direct eye contact with laser light. Never intentionally expose your eyes or others to direct laser radiation. Compliance Statement Your Galactic Laser has been designed to comply with FDA and IEC Standards for it classification. The Galactic is a Class IIIB laser product.
  • Page 7: Rigging

    Galactic Beam G40 Proper Usage Safety and Compliance Information According to FDA Regulations you should operate this product as stated on the left. Rigging Please follow the European and national guidelines concerning rigging, trussing and all other safety issues. Do not attempt the installation yourself ! Always let the installation be carried out by an authorized dealer ! Procedure: ●...
  • Page 8: Connection With The Mains

    Galactic Beam G40 Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER FASE BLUE BLACK SILVER...
  • Page 9: Description Of The Device

    Galactic Beam G40 Description of the device Features The Showtec Galactic Beam G40 is a laser effect with high output and great effects. ● 40mW Green Fatbeam Laser ● Strong solid beam ● By using fat-beam technology we are able to use 40mW laser and still be compliance to IEC-60825 ●...
  • Page 10: Backside

    Galactic Beam G40 Backside Fig. 02 01) ON/OFF 02) Fuse 1 A/250V 03) IEC Powerconnector 04) Lock On/Off 05) 3-pin DMX signal connector (OUT) 06) 3-pin DMX signal connector (IN) 07) Remote Control 08) LCD Display + Menu Buttons 09) Cooling Fan 10) Built-in Microphone NOTE: Knowledge of DMX is required to fully utilize this unit.
  • Page 11: Installation

    Galactic Beam G40 Installation Remove all packing materials from the Galactic. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty.
  • Page 12: Set Up And Operation

    Galactic Beam G40 Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connect the device to the main power supply.
  • Page 13: Control Modes

    Galactic Beam G40 Control Modes There are 4 modes: Auto run (visual effects) Sound-controlled Master/Slave DMX512 One Galactic Auto run (visual effects) 01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141).
  • Page 14: Multiple Galactics (Dmx Control)

    Galactic Beam G40 Multiple Galactics (DMX Control) 01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Plug the end of the electric mains power cord into a proper electric power supply socket. 04) Use a 3-p XLR cable to connect the Galactics and other devices.
  • Page 15: Fixture Linking

    Galactic Beam G40 Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.
  • Page 16: Control Panel

    Galactic Beam G40 Control Panel LED Display Func button Up Button Down Button Enter Button Fig. 05 Control Mode The fixtures are individually addressed on a data-link and connected to the controller. The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it, the controller will display the saved DMX address the next time.) DMX Addressing The control panel on the front side of the base allows you to assign the DMX fixture address, which is the...
  • Page 17: Menu Overview

    Galactic Beam G40 Menu Overview Ordercode: 51315...
  • Page 18: Main Menu Options

    Galactic Beam G40 Main Menu Options Automatic Show with Patterns and Solid Beams Automatic / Sound-active Moving Beams Fixed Beam Sound-active to Block Fixed Beam Sound-active to Beam Sensitivity Mode DMX address Master/Slave Mode Pattern Mirror Reverse Default Setting You can only change a certain setting when the display is blinking. If you can’t change a certain value, please press the Function-button once and then change the value.
  • Page 19: Sound-Active To Beam Off

    Galactic Beam G40 4. Sound-active to Beam OFF 01) Press the FUNC button, until the display shows 02) The Galactic Beam is now sound activated to Beam OFF. 5. Sensitivity Mode 01) Press the FUNC button, until the display shows 02) You can choose 10 different Audio Sensitivity levels.
  • Page 20: Dmx Channels

    Galactic Beam G40 DMX Channels 8 Channels Channel 1 – Built-in Programs 0-31 Laser OFF 32-63 AdS (Auto show with slow solid beam effect) 64-95 AdF (Auto show with fast solid beam effect) 96-127 Sdr (Sound activated random solid beam) 128-159 AUT (Automatic Show with Patterns and Solid Beams) 160-191...
  • Page 21: Patterns

    Galactic Beam G40 Patterns Ordercode: 51315...
  • Page 22: Maintenance

    Galactic Beam G40 Maintenance The Showtec Galactic requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply and then wipe the cover with a damp cloth. Wipe the front glass panel clean with glass cleaner and a soft cloth.
  • Page 23: Troubleshooting

    Response: Suspect three potential problem areas as: the power supply, the laser, the fuse. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The laser. Return the Galactic to your Showtec dealer. 03) The fuse. Replace the fuse. See page 21 for replacing the fuse.
  • Page 24 Galactic Beam G40 Problem Probable cause(s) Remedy One or more No power to the fixture. ● Check that power is switched on and fixtures are cables are plugged in. completely dead. Primary fuse blown. ● Replace fuse. Fixtures reset The controller is not connected. ●...
  • Page 25: Product Specification

    Galactic Beam G40 Product Specification Model: Showtec Galactic Beam G40 Input Voltage: AC 100-240V, 50/60Hz Continuous Power: 123W Fuse 1L / 250V Dimensions: 300 x 88 x 222 mm (LxWxH) Weight: 2,3 Kg Operation and Programming Signal pin OUT: pin 1 earth, pin 2 (-), pin 3 (+)
  • Page 26: Dimensions

    Galactic Beam G40 Dimensions Ordercode: 51315...
  • Page 27 Galactic Beam G40 Ordercode: 51315...
  • Page 28 ©2015 Showtec...
