LGA pad
ConnectCore 8X signal name i.MX 8X pad name*
name
AK23
GND
AK24
MIPI_CSI0_I2C0_SDA
AK25
MIPI_CSI0_I2C0_SCL
AK26
CSI_RESET
AK27
CSI_EN
AK28
CSI_HSYNC
AL2
3V3
AL3
3V3
AL4
GND
-
MIPI_CSI0_I2C0_SDA
MIPI_CSI0_I2C0_SCL
CSI_RESET
CSI_EN
CSI_HSYNC
-
-
-
Multiplexing
Power Group
-
-
ALT0: MIPI_CSI0_I2C0_SDA
1V8
ALT1: MIPI_CSI0_GPIO0_IO03
ALT2:
ALT3:
ALT4: GPIO3_IO06
ALT0: MIPI_CSI0_I2C0_SCL
1V8
ALT1: MIPI_CSI0_GPIO0_IO02
ALT2:
ALT3:
ALT4: GPIO3_IO05
ALT0: CSI_RESET
VDD_CSI
ALT1: CSI_I2C_SDA
ALT2: I2C3_SDA
ALT3: SPI1_CS0
ALT4: GPIO3_IO03
ALT0: CSI_EN
VDD_CSI
ALT1: CSI_I2C_SCL
ALT2: I2C3_SCL
ALT3: SPI1_SDI
ALT4: GPIO3_IO02
ALT0: CSI_HSYNC
VDD_CSI
ALT1: CSI_D00
ALT2: SAI3_RXFS
ALT3: TAMPER_IN3
ALT4:
-
3V3
-
3V3
-
-
