LGA pad
ConnectCore 8X signal name i.MX 8X pad name*
name
E20
SAI0_TXD
E21
SAI0_RXD
E22
SPI0_SDI
E23
SAI0_TXC
E24
SAI1_RXC
E25
SAI1_RXFS
SAI0_TXD
SAI0_RXD
SPI0_SDI
SAI0_TXC
SAI1_RXC
SAI1_RXFS
Multiplexing
Power Group
ALT0: SAI0_TXD
VDD_SPI_SAI
ALT1: SAI1_RXC
ALT2: SPI1_SDO
ALT3: LCDIF_D18
ALT4: GPIO0_IO25
ALT0: SAI0_RXD
VDD_SPI_SAI
ALT1: SAI1_RXFS
ALT2: SPI1_CS0
ALT3: LCDIF_D20
ALT4: GPIO0_IO27
ALT0: SPI0_SDI
VDD_SPI_SAI
ALT1: SAI0_TXD
ALT2: M40_TPM0_CH0
ALT3: M40_GPIO0_IO02
ALT4: GPIO1_IO05
ALT0: SAI0_TXC
VDD_SPI_SAI
ALT1: SAI1_TXD
ALT2: SPI1_SDI
ALT3: LCDIF_D19
ALT4: GPIO0_IO26
ALT0: SAI1_RXC
VDD_SPI_SAI
ALT1: SAI1_TXC
ALT2:
ALT3: LCDIF_D22
ALT4: GPIO0_IO30
ALT0: SAI1_RXFS
VDD_SPI_SAI
ALT1: SAI1_TXFS
ALT2:
ALT3: LCDIF_D23
ALT4: GPIO0_IO31
