Glass Replacement - Wren Kitchens INFINITY PLUS Standard Drawer Manual

GLASS OUT
Step 2.
Insert the glass into the rear slot of
the side panel and rotate the glass
parallel to the side of the drawer.
CLICK
A CLICK will be heard once the glass is
correctly located within the side panel
of the drawer.
For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev1
GLASS
REPLACEMENT
Step 3.
Slide the glass forward into the front slot of the drawer
side, so that both ends of the glass are encapsulated
within the side panel.
FRONTALS
INFINITY PLUS
Attachment
Step 1.
Fully press the rear fixing clip in.
GLASS REMOVAL:
To remove the glass, reverse the
installation process. Press the rear
fixing clip in, then slide the glass
backwards, towards the rear of the
drawer. Once fully back the glass will
be free to slide out on an angle from
the side panel.
Guide
Page 4
