Deep Drawer - Wren Kitchens INFINITY PLUS Standard Drawer Manual

Step 1.
Attach the frontal fixings to the draw front using 3 x
screws (B) per bottom bracket and 2 x
bracket using the spiked positions.
7 15/16"
6 5/8"

Deep Drawer

4 1/2"
2 7/8"
2 13/16"
1 1/2"
DRAWER FRONTAL
ADJUSTMENT
Loosen top 2
screws. Turn
bottom screw
to adjust drawer
frontal height, once
in desired position
re-tighten
the top 2
screws.
For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev1
DEEP DRAWER
Frontal Fixings
5/8"
screws (B) per top
5/8"
7 15/16"
6 5/8"
4 1/2"
2 7/8"
2 13/16"
1 1/2"
DRAWER REAR
ADJUSTMENT
Turn screw to adjust
rear elevation of
drawer.
FRONTALS
INFINITY PLUS
Step 2.
Attach the draw front by pushing the
frontal onto the sides, aligning the
mechanism with the fixings.
Attachment
Guide
B
B
B
B
B
