UG-380

BILL OF MATERIALS

Table 1.
Reference Designator
AGND
C1, C4, C10, C18, C25, C44, C45, C46,
C53, C54,C55, C57, C58, C59, C60, C61
C2, C3, C15, C16, C52, C56, C76
C5
C6, C17, C19, C20, C37
C7, C29, C31, C70, C73, C75
C8, C28, C66, C77
C9
C11, C12, C39, C49
C13
C14, C67
C30, C32
C21
C22, C23
C24
C26, C27
C40, C41, C48, C51
C42, C43
C47, C50
C64, C65
C68, C69
C71, C74
C72
D1, D6
D2
D3
D4
GND
L1, L2
L3
R1, R2, R13, R29, R31, R35, R37, R48,
R51, R52, R56, R58, R61
R3, R5, R6, R8, R10, R14, R18, R22, R25,
R36, R42, R43, R46, R47, R53, R54, R55,
R57, R60, R64, R65
R4
R7, R38
R9, R34
R11
R12
R15, R16, R17, R19
R20, R21
R23, R24, R33
R26, R27, R28
R30
R32
R39, R49, R50
Value Description
Black test point
0.1 µF 16 V, X7R ceramic capacitor
10 pF 50 V NP0 ceramic capacitor
Do not insert 50 V NP0 ceramic capacitor
100 pF 50 V C0G ceramic capacitor
1 µF Capacitor, ceramic, 1.0 µF, 50 V, X5R,
0805
1 µF Capacitor, 0603, 1 µF, 10 V, X5R
Do not insert TAJ-A capacitor location, not inserted
1 nF 50 V NP0 ceramic capacitor
120 nF 50 V X7R SMD ceramic capacitor
4.7 nF 50 V X7R SMD ceramic capacitor
Do not insert 16 V X5R ceramic capacitor
6.8 nF 50 V NPO SMD ceramic capacitor
Do not insert 6.3 V tantalum capacitor (TAJ-A case)
120 pF 50 V NP0 ceramic capacitor
12 pF 50 V NPO SMD ceramic capacitor
22 µF 6.3 V tantalum capacitor (TAJ-A case)
1 nF Ceramic capacitor, 1000 pF, 50 V, C0G
0402
1 µF Ceramic capacitor, 1.0 µF, 25 V, X5R
0805
1 µF 16 V X5R ceramic capacitor
33 pF 50 V C0G ceramic capacitor
68 pF 50 V C0G ceramic capacitor
1.2 nF 50 V X7R ceramic capacitor
Green LED
7.5 V Zener diode, 7.5 V, 300 mW
Red LED
Schottky diode, 0.75 A forward
Black 4 mm banana socket
27 nH Coilcraft 0402CS SMD Inductor
47 nH Coilcraft 0402CS SMD inductor
0 Ω SMD resistor
Do not insert 0603 resistor location, not inserted
5.1 kΩ SMD resistor
1 kΩ SMD resistor
75 Ω SMD resistor
150 Ω 0402 SMD resistor
210 kΩ SMD resistor
10 kΩ SMD resistor
68 Ω 0402 SMD resistor
51 Ω 0402 SMD resistor
18 Ω 0402 SMD resistor
1 Ω SMD resistor
64.9 kΩ SMD resistor
2.2 kΩ SMD resistor
Rev. 0 | Page 22 of 24
Evaluation Board User Guide
Manufacturer/Part Number
Vero 20-2137
Kemet C0402C104K4RAC
AVX 04025U100GAT2A
N/A
Murata GRM1555C1H101JD01D
Taiyo/Yuden GRM32RR71H105KA01L
Murata GRM188R61A105KA61D
N/A
AVX 06035A102JAT2A
KEMET C0603C124K5RACTU
Kemet C0603C472K5RAC
N/A
Kemet C0603C682J5GACTU
N/A
AVX 04025A121JAT2A
Phycomp 2238 867 15129
AVX, TAJA226K006R
Murata GRM1555C1H102JA01D
Taiyo/Yuden TMK107BJ105KA-T
Kemet C0603C105K4PAC-TU
Murata GRM1555C1H330JZ01D
Murata GRM1555C1H680JZ01D
Murata GRM155R71H122KA01D
Avago Technologies, HSMG-C170
Fairchild BZX84C7V5
Avago Technologies HSMS-C170
Diodes Inc. BAT750-7-F
Deltron 571-0100-01
Coilcraft 0402CS-27NX-LU
Coilcraft 0402CS-47NX-LU
Multicomp MC 0.063W 0603 0R
N/A
Multicomp MC 0.063W 0603 5k1
Multicomp MC 0.063W 0603 1K
CRCW060375R0FKEA
Multicomp MC 0.0625W 0402 1% 150R
Multicomp MC 0.063W 0603 210k
Multicomp MC 0.063W 0603 10K
Multicomp MC 0.0625W 0402 1% 68R
Multicomp MC 0.063W 0402 51R
Multicomp MC 0.0625W 0402 1% 18R
YAGEO (PHYCOMP) RC0603FR-071RL
Multicomp MC 0.063W 0603 68k
Multicomp MC 0.063W 0603 2k2
