Evaluation Board User Guide

Bill of Materials

ITEM QTY REFERENCE
REQUIRED CIRCUIT COMPONNENTS
1 4 C1, C2, C5, C14
2 1 C3
3 2 C6, C8
4 1 C7
5 2 C15, C16
6 1 C19
7 4 C17, C29, C36, C37
8 2 L1, L2
9 1 U1
ADDITIONAL EVALUATION BOARD CIRCUIT COMPONENTS
1 1 C4
2 0 C9, C10
3 0 C11
C12, C13, C22, C24,
4 6 C30, C33
5 3 C18, C20, C21
7 1 C23
8 4 C25, C26, C27, C28
9 1 C31
10 3 C32, C34, C35
11 1 C38
12 2 C39, C40
13 1 C41
14 1 C42
15 1 D1
16 1 D2
17 1 FB1
18 1 L3
19 1 Q1
20 1 Q2
21 4 R2, R5, R8, R9
analog.com
PART DESCRIPTION
CAP., 0.1µF, X6S, 25V, 10%, 0201
CAP., 4.7µF, X6S, 25V, 10%, 0603
CAP., 10µF, X6S, 10V, 10%, 0603
CAP., 1µF, X7S, 10V, 10%, 0402
CAP., 10µF, X7S, 4V, 20%, 0603
CAP., 1µF, X7S, 10V, 10%, 0402
CAP., 100µF, X6S, 4V, 20%, 0805
IND., 0.40µH, 22.5A, 32.8mΩ
IC, 20A, 16V REGULATOR, LQFN-24
CAP., 100µF, ALUM, 35V, 20%
CAP., OPTION, 7343
CAP., OPTION, 0603
CAP., 10µF, X7S, 25V, 10%, 0805
CAP., 4.7µF, X5R, 25V, 10%, 0603
CAP., 1µF, X5R, 25V, 10%, 0603
CAP., 1µF, X5R, 25V, 10%, 0402
CAP., 0.1µF, X7R, 10V, 20%, 0603
CAP., 1µF, X7R, 6.3V, 10%, 0402
CAP., 1µF, X7R, 50V, 10%, 0603
CAP., 0.01µF, X7R,25V, 10%, 0603
CAP., 10µF, X7R, 10V, 10%, 0805
CAP., 1500pF, X7R, 25V, 10%, 0603
LED, GREEN, DIFFUSED, 0603
LED, RED, DIFFUSED, 0603
FERRITE BEAD, 100Ω@100MHz, 1812
IND., 0.47µH, 6.8A, 14mΩ
MOSFET, N-CH, 25V, 70A, Power-SO8
MOSFET, N-CH, 60V, 300mA, SOT-23-3
RES., 10kΩ, 1%, 1/10W, 0603
EVAL-LT7170-1-AZ
MANUFACTURER/PART NUMBER
TAIYO YUDEN, TMK063C6104KP-F
MURATA, GRM188C81E475KE11D
MURATA, ZRB18AC81A106KE01L
MURATA, GRM155C71A105KE11D
TDK, C1608X7S0G106M080AB
MURATA, GCM155C71A105KE38D
MURATA, GRM21BC80G107ME15L
COILCRAFT, XGL4030-401MEC
ANALOG DEVICES, LT7170RV-
1#TRPBF
PANASONIC, EEHZK1V101XP
MURATA, GRM21BC71E106KE11L
MURATA, GRM188R61E475KE15D
AVX, 06033D105KAT2A
MURATA, GRM155R61E105KA12D
AVX, 0603ZC104MAT2A
MURATA, GRM155R70J105KA12D
AVX, 06035C105KAT2A
AVX, 06033C103K4Z2A
AVX, 0805ZC106KAT2A
AVX, 06033C152KAT2A
BROADCOM INC., HSMG-C190
BROADCOM INC., HSMH-C190
WURTH ELEKTRONIK, 74279226101
WURTH ELEKTRONIK, 744373240047
NEXPERIA, PSMN5R4-25YLDX
VISHAY, 2N7002K-T1-GE3
VISHAY, CRCW060310K0FKEA
Rev. A 8 of 13
